Herreshoff #188601es [Canoe for #123p Ladoga]

Particulars

Name: [Canoe for #123p Ladoga]
Type: Canoe
Designed by: NGH
Contract: 1886-2 ?
Construction: Wood
LOA: 16' 0" (4.88m)
Rig: None (canoe)
Built for: King, George Gordon

See also:

#123p Ladoga (1885)

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.

Model

Model number: 14
Model location: H.M.M. Model Room East Wall

Vessels from this model:
2 built, modeled by NGH

#188601es [Canoe for #123p Ladoga] (1886)

#188404es Inezita [Inizita] (1884)

Original text on model:
"Built for G.G. King 1885-86 also INEZITA" (Source: Original handwritten annotation on model. Undated.)

Model Description:
"1885-86 built for G.G. King. Also Inezita." (Source: Bray, Maynard. 2004.)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.

Offsets

Offset booklet number(s): HH.4.016

Offset booklet contents:
#128, #250, #252, #253, #258, overhanging stern built on to #18[3] [#183p, canoe [#188601es] for G. G. King [various launches].

Offset Booklet(s) in Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. (Restricted access --- see curator.)

Drawings

Main drawing Dwg 028-002 [075-004] (HH.5.01998)

Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   Herreshoff #188601es [Canoe for #123p Ladoga] are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.

Dwg 028-002 [075-004] (HH.5.01998); Construction Dwg > 16 ft. Canoe - 6" Spaces, 14' Canoe - 5 1/4" Spaces, 12' Canoe - 4 1/2" Spaces (1886-02-13)

Source: Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. Haffenreffer-Herreshoff Collection. Together with: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997. Together with: Numerous additions and corrections by Claas van der Linde.
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.

Documents

Nathanael G. Herreshoff

"Nov[ember] 19th 1885.
Canoe for G.G. King, 14f long.
Length of model 16f on top.
Length of model extremes 16f 1 3/4"
Half Breadth 1-17-5.
Depth 1-5-1 1/2.
No. of frame spaces 32.
Deduct for timbers 0".
Deduct for planking 1/4".
Total [unreadable].
Use 10 1/2" rule for all for & aft measurements in King's canoe.
Frames taken from one end of model only, the other end being the same.
To be planked over moulds and timbers sprung in afterwards." (Source: Herreshoff, N.G. [Penciled note in Offset Booklet HH.4.016.] Haffenreffer-Herreshoff Collection, MIT Museum, Cambridge, MA.)

Images

Stebbins, Nathaniel L. "[Canoe for Ladoga] [#188601es.]" Photograph (cropped detail), negative no. 4146, 1892.

Further Image Information

Created by: Stebbins, Nathaniel L.
Image Caption: [The Ladoga's Canoe hanging from the davits of Ladoga #123p. Greatly enlarged cropped detail of a photo of Ladoga taken by N. L. Stebbins in 1892, six years after the canoe had been built. Photo taken during the Cruise of the New York Yacht Club on the 40nm run from New London to Newport.]
Negative Number: 4146
Image Date: 1892-8-4
Collection: Historic New England (SPNEA) Collection, GUSN 278150.
Image is copyrighted: No known copyright restrictions

Supplement

Research Note(s)

"This canoe was carried on George Gordon King's steamyacht Ladoga #123p which had been launched at HMCo in July 1885." (Source: van der Linde, Claas. January 30, 2009.)

"This vessel's contract date was estimated from the original plan date. Plan 28-2 (formerly 75-4) from which this boat was built was drawn 1886-02. #123p Ladoga (for which this vessel was built) was finished 1885-07. This boat's contract or building date is about 7 months after #123p Ladoga was finished." (Source: van der Linde, Claas. October 26, 2009.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
