Herreshoff #188901es [Yawl for #152p Cushing]

Particulars

Name: [Yawl for #152p Cushing]
Type: Yawlboat
Designed by: NGH
Finished: 1889-8 ?
Construction: Wood
LOA: 11' 0" (3.35m)
Beam: 5' (1.52m)
Rig: None (rowboat)
Built for: U.S. Navy

See also:

#189101es [Dinghy for #152p Cushing] (1891)

#152p Cushing (1890)

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.

Model

Model number: 417
Model location: H.M.M. Model Room West Wall Left

Vessels from this model:
1 built, modeled by NGH

#188901es [Yawl for #152p Cushing] (1889)

Original text on model:
"CUSHING's yawl scale 1/12 yawl for torpedo boat for 152" (Source: Original handwritten annotation on model. Undated.)

Model Description:
"Yawlboat for the torpedo boat Cushing of 1890." (Source: Bray, Maynard. 2004.)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.

Offsets

Offset booklet number(s): HH.4.021.2

Offset booklet contents:
#152 (yacht tender).

Offset Booklet(s) in Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. (Restricted access --- see curator.)

Drawings

Main drawing Dwg 028-005 [075-011] (HH.5.02001)

Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   Herreshoff #188901es [Yawl for #152p Cushing] are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.

Dwg 028-005 [075-011] (HH.5.02001); Construction Dwg > Rowboat for Torpedo Boat Str. 152 (1889-07-02)

Source: Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. Haffenreffer-Herreshoff Collection. Together with: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997. Together with: Numerous additions and corrections by Claas van der Linde.
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.

Documents

Archival Documents

"N/A"

"[Item Description:] HMCo Plan HH.5.02001 (028-005). Blueprint construction plan with plan view and inboard profile titled 'Row boat [#188901es] for Torpedo Boat St[eame]r 1[52] [#152p CUSHING]. Herreshoff Mfg. Co. Bristol, R.I. July [2, 1889]'. With list of particulars 'Length 11ft. Breadth 5ft. Depth 23in'." (Source: Herreshoff, N.G. (creator). Blueprint. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Acc. 2004.0001.0377. WRDT08, Folder 18, formerly MRDE08. 1889-07-02.)
① ②

Note: This list of archival documents contains in an unedited form any and all which mention #188901es [Yawl for #152p Cushing] even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

Images

Anon. "[Yawl for Cushing] [#188901es.]" Photograph (cropped detail), 1901.

Further Image Information

Created by: Anon.
Image Caption: [Believed to be #188901es Yawl for Cushing. Cropped detail of a photo.]
Image Date: 1901 ???
Published in: USS Cushing Association, http://www.usscushing.com, retrieved October, 12, 2007.
Image is copyrighted: No known copyright restrictions
Stebbins, Nathaniel L. "[Yawl for Cushing] [#188901es.]" Photograph (cropped detail), negative no. 3226, 1890.

Further Image Information

Created by: Stebbins, Nathaniel L.
Image Caption: [Believed to be #188901es Yawl for Cushing. Cropped detail of a photo.]
Negative Number: 3226
Image Date: 1890-8-14
Published in: Stebbins, N. L. The New Navy of The United States. New York, 1912.
Collection: Historic New England (SPNEA) Collection, GUSN 277818.
Image is copyrighted: No

Supplement

Research Note(s)

"This vessel's contract date was estimated from the original plan date. Plan 28-5 (formerly 75-11) from which this boat was built was drawn 1889-07. #152p Cushing (for which this vessel was built) was finished 1890-01-23. This boat's contract or building date is about 7 months before #152p Cushing was launched." (Source: van der Linde, Claas. October 26, 2009.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
