Herreshoff #189201es [Dinghy for #414s Wasp]



Name: [Dinghy for #414s Wasp]
Type: Coquina sailing dinghy
Designed by: NGH
Contract: 1892-5-10 ?
Construction: Wood
LOA: 14' 2" (4.32m)
Beam: 4' 5" (1.35m)
Centerboard: yes
Built for: Rogers, Archibald

See also:
#414s Wasp (1892)

Note(s): Vessel information is primarily but not exclusively from the HMCo Construction Record. Supplementary information when not cited here usually appears elsewhere in this record with a complete citation.


Model #4

Model number: 4
Model location: H.M.M. Model Room East Wall

Vessels from this model:
30 built, modeled by NGH
#189102es [Dinghy for #164p Javelin] (1891)
#189103es [Dinghy for #411s Gloriana] (1891)
#189201es [Dinghy for #414s Wasp] (1892)
#189202es [Dinghy for #435s Colonia] (1892)
#189302es [Dinghy for #437s Vigilant] (1893)
#189908es [Dinghy for #510s Petrel] (1899)
#189909es [Rowboat for #520s Athene] (1899)
#190302es [10ft Coquina Rowboat] (1903)
#190303es [Coquina Rowboat Job2441] (1903)
#190307es [Dinghy for #235p Mist] (1903)
#190421es [Dinghy for #621s Margaret] (1904)
#190511es [Coquina Rowboat Job3572] (1905)
#190517es [Dinghy for #638s Neola II] (1905)
#190604es [Coquina Rowboat Job3857] (1906)
#190704es [Dinghy for #666s Avenger] (1907)
#190905es [Dinghy for #552s Effort II] (1909)
#190906es [Dinghy for #594s Zara] (1909)
#190908es [Dinghy for #685s Adventuress] (1909)
#191002es [Dinghy for S. P. Colt] (1910)
#191106es [Dinghy for #692s Westward] (1911)
#404s Coquina (1889)
#419s Coquina 2nd (1892)
#474s Dude (1896)
#492s [Dinghy for #493s Jilt] (1898)
#498s Wiz [Whiz] (1898)
#500s [Dinghy for W. H. Buffington] (1899)
#522s Memo (1899)
#523s [As Coquina 2nd #419 7/8-scale] (1899)
#524s [As Coquina 2nd #419 7/8-scale] (1899)
#606s [Sailing Dinghy for H. Darlington] (1902)

Original text on model:
"COQUINA 1889 #404 1888
COQUINA 2nd 1892 #419
1896 #474 19 [sic, i.e. 16] 1\2 ft
827 lbs
Hull 279 centerboard rudder 10 oars 8
3 333 / 30 / 13 / 120 \ ballast & rig 140 310 \ 686." (Source: Original handwritten annotation on model. Undated.)

Model Description:
"#404 Coquina, 16'8" loa sailboat of 1889. Also used for #419 Coquina II of 1892 and, with modifications, for #474 Dude of 1896. See also first model for Coquina, seq 1225, not used." (Source: Bray, Maynard. 2004.)

Related model(s):
Model 1225 by NGH (1889?); sail, not built
Coquina (Study Model)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.



Research Note(s)

"14'2" Boat for Wasp - #414. 2 Boats for #435 [Colonia] and #437 [Vigilant] as in dotted lines. Raised - with deck at bow & stern. No centre board or mast. Made on moulds of 'Boat to Steamer No. 164' [Javelin] which are taken from Coquina by using 7/8 sp[unreadable]. Riser at end of deck at both ends to be straight across top and 1/4" higher than top of flanged eye [-] strong enough to rest boat on when upside down. Frame spaces 8 1/2", timbers 11/16" sq., planking 5/16" cedar. Stem hackmatac, stern white oak 15/16" thick, keel 1 1/4" deep with 3/8" lip [?] thwarts 13/16" thick mahogany. Thwarts stringers, white oak 1" x 3/8". Sheer-streak [sic] white oak 3 1/4" x 1" x 3/8". Gunwhale stringer 7/16" x 1 3/8". Floorboard 3/8" cedar. Grateings [sic] mahog[any] [as per notes on drawing 28-11]." (Source: van der Linde, Claas. October 26, 2009.)

"This vessel's contract date was estimated from the original plan date. Plan 28-11 (formerly 75-24) from which this boat was built was drawn 1892-05-10. #414s Wasp (for which this vessel was built) was contracted for 1891-09-02. This boat's contract or building date is 251 days after #414s Wasp was contracted for." (Source: van der Linde, Claas. October 26, 2009.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.


We are always interested in learning more about this vessel. If you want to discuss it or can share any additional information or images or to discuss a copyright concern, please do not hesitate to send an Email to the link below!
