HMCo #419s Coquina 2nd

Particulars

Construction_Record_Title.jpgName: Coquina 2nd
Type: Coquina sailing dinghy
Designed by: NGH
Contract: 1892-1
Delivered: 1892-6-7
Construction: Wood
LOA: 16' 8" (5.08m)
LWL: 16' 0" (4.88m)
Beam: 5' 0" (1.52m)
Draft: 1' 0" (0.30m)
Rig: Catyawl
Centerboard: yes
Ballast: None
Built for: Hollis, W. G. [Crossed out: N. G. Herreshoff]
Amount: $350.00
Note(s) in HMCo Construction Record: Mineapolis [sic].

Note(s): Vessel information is primarily but not exclusively from the HMCo Construction Record. Supplementary information when not cited here usually appears elsewhere in this record with a complete citation.


Model

Model #4

Model number: 4
Model location: H.M.M. Model Room East Wall

Vessels from this model:
30 built, modeled by NGH
#189102es [Dinghy for #164p Javelin] (1891)
#189103es [Dinghy for #411s Gloriana] (1891)
#189201es [Dinghy for #414s Wasp] (1892)
#189202es [Dinghy for #435s Colonia] (1892)
#189302es [Dinghy for #437s Vigilant] (1893)
#189908es [Dinghy for #510s Petrel] (1899)
#189909es [Rowboat for #520s Athene] (1899)
#190302es [10ft Coquina Rowboat] (1903)
#190303es [Coquina Rowboat Job2441] (1903)
#190307es [Dinghy for #235p Mist] (1903)
#190421es [Dinghy for #621s Margaret] (1904)
#190511es [Coquina Rowboat Job3572] (1905)
#190517es [Dinghy for #638s Neola II] (1905)
#190604es [Coquina Rowboat Job3857] (1906)
#190704es [Dinghy for #666s Avenger] (1907)
#190905es [Dinghy for #552s Effort II] (1909)
#190906es [Dinghy for #594s Zara] (1909)
#190908es [Dinghy for #685s Adventuress] (1909)
#191002es [Dinghy for S. P. Colt] (1910)
#191106es [Dinghy for #692s Westward] (1911)
#404s Coquina (1889)
#419s Coquina 2nd (1892)
#474s Dude (1896)
#492s [Dinghy for #493s Jilt] (1898)
#498s Wiz [Whiz] (1898)
#500s [Dinghy for W. H. Buffington] (1899)
#522s Memo (1899)
#523s [As Coquina 2nd #419 7/8-scale] (1899)
#524s [As Coquina 2nd #419 7/8-scale] (1899)
#606s [Sailing Dinghy for H. Darlington] (1902)

Original text on model:
"COQUINA 1889 #404 1888
COQUINA 2nd 1892 #419
1896 #474 19 [sic, i.e. 16] 1\2 ft
827 lbs
Hull 279 centerboard rudder 10 oars 8
3 333 / 30 / 13 / 120 \ ballast & rig 140 310 \ 686." (Source: Original handwritten annotation on model. Undated.)

Model Description:
"#404 Coquina, 16'8" loa sailboat of 1889. Also used for #419 Coquina II of 1892 and, with modifications, for #474 Dude of 1896. See also first model for Coquina, seq 1225, not used." (Source: Bray, Maynard. 2004.)

Related model(s):
Model 1225 by NGH (1889?); sail, not built
Coquina (Study Model)


Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.


Offsets

Offset booklet number(s): HH.4.64

Offset booklet contents:
#404, #418, [#419], #474 [15' 9" w.l. dandy Coquina, 25' w.l. finkeel sloop El Chico, 13' 6" w.l. spritsail boat Dude].


Source: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997, p. 32-43.

Raw Offset Info Database Entry

Microfilm Reel No. (Hart Nautical Offset Info): HAFH.4.4B
Box No. (Hart Nautical Offset Info): HAFH.4.4B
Acc. No. (Hart Nautical Offset Info): HH.4.64
Vessel Descr. (Hart Nautical Offset Info): #404, #418, [#419], #474 [15' 9" w.l. dandy Coquina, 25' w.l. finkeel sloop El Chico, 13' 6" w.l. spritsail boat Dude]

Text

Other Contemporary Text Source(s)

"... At Bristol, the Herreshoffs have sent the 16-foot cat yawl [#419s Coquina 2nd] to Minnetonka, the 17-foot fin [#421s Bee] to Auburn, N. Y., and the half-rater [#425s Wee Winn] to Southhampton." (Source: Anon. "Yachts and Yachtsmen." Boston Globe, June 26, 1892, p. 21.)

"The spring work at Bristol is about finished, only the large steel steam yacht [#172p Truant] remaining. Last week the the half-rater Wee Win [#425s] was sent to New York for shipment to England, a 17ft. fin-keel [#421s Bee] was sent to Auburn, N. Y., a 16ft. cat-yawl to Lake Minnetonka, Minn. [#419s Coquina 2nd], and a 23ft. cat-yawl to Conanicut Park [#424s Wraith]; while the 30ft. centerboard Edith M. [#426s] was launched." (Source: Anon. "Yacht News Notes." Forest and Stream, June 30, 1892, p. 621.)

Images

Supplement

From the 1920 and earlier HMCo Index Cards at the MIT Museum
  • Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.
From the 1931 HMCo-published Owner's List

Name: Coquina 2nd
Type: Dandy
Length: 16'
Owner: Hollis, W. G.

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

From the 1930s L. Francis Herreshoff Index Cards at the Herreshoff Marine Museum
  • Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.
From the 1953 HMCo Owner's List by L. Francis Herreshoff

Name: Coquina II
Type: 16' catyawl
Owner: W. G. Hollis
Row No.: 131

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

From the 2000 (ca.) Transcription of the HMCo Construction Record by Vermilya/Bray

Month: Jan
Year: 1892
E/P/S: S
No.: 0419
Name: Coquina 2nd
LW: 16' 0"
B: 5' 0"
D: 1' 0"
Rig: Dandy [?]
CB: y
Ballast: None
Amount: 350.00
Notes Constr. Record: Mineapolis [SIC]
Last Name: Hollis
First Name: W. [?]

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

Link to the Herreshoff Registry

The Herreshoff Registry can be particularly useful for researching the provenance of Herreshoff-built sailing vessels. Permission to link to the Registry is gratefully acknowledged!

Research Note(s)

"Plan 28-9 (formerly 75-26) from which this boat was built is dated 1892-01." (Source: van der Linde, Claas. October 26, 2009.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
