HMCo #523s [As Coquina 2nd #419 7/8-scale]

Particulars

Construction_Record_Title.jpgName: [As Coquina 2nd #419 7/8-scale]
Type: Coquina Sailing Dinghy
Designed by: NGH
Contract: 1899-5-8
Construction: Wood
LOA: 12' 6" (3.81m)
Beam: 4' 7" (1.40m)
Draft: 0' 8" (0.20m)
Rig: Cat Gaff
Sail Area: 100sq ft (9.3sq m)
Centerboard: yes
Ballast: None
Built for: Herreshoff, J.B. Francis [for Fred Herreshoff]
Amount: $150.00

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.


Model

Model #4Model number: 4
Model location: H.M.M. Model Room East Wall

Vessels from this model:
30 built, modeled by NGH
#189102es [Dinghy for #164p Javelin] (1891)
#189103es [Dinghy for #411s Gloriana] (1891)
#189201es [Dinghy for #414s Wasp] (1892)
#189202es [Dinghy for #435s Colonia] (1892)
#189302es [Dinghy for #437s Vigilant] (1893)
#189908es [Dinghy for #510s Petrel] (1899)
#189909es [Rowboat for #520s Athene] (1899)
#190302es [10ft Coquina Rowboat] (1903)
#190303es [Coquina Rowboat Job2441] (1903)
#190307es [Dinghy for #235p Mist] (1903)
#190421es [Dinghy for #621s Margaret] (1904)
#190511es [Coquina Rowboat Job3572] (1905)
#190517es [Dinghy for #638s Neola II] (1905)
#190604es [Coquina Rowboat Job3857] (1906)
#190704es [Dinghy for #666s Avenger] (1907)
#190905es [Dinghy for #552s Effort II] (1909)
#190906es [Dinghy for #594s Zara] (1909)
#190908es [Dinghy for #685s Adventuress] (1909)
#191002es [Dinghy for S. P. Colt] (1910)
#191106es [Dinghy for #692s Westward] (1911)
#404s Coquina (1889)
#419s Coquina 2nd (1892)
#474s Dude (1896)
#492s [Dinghy for #493s Jilt] (1898)
#498s Wiz [Whiz] (1898)
#500s [Dinghy for W. H. Buffington] (1899)
#522s Memo (1899)
#523s [As Coquina 2nd #419 7/8-scale] (1899)
#524s [As Coquina 2nd #419 7/8-scale] (1899)
#606s [Sailing Dinghy for H. Darlington] (1902)

Original text on model:
"COQUINA 1889 #404 1888
COQUINA 2nd 1892 #419
1896 #474 19 [sic, i.e. 16] 1\2 ft
827 lbs
Hull 279 centerboard rudder 10 oars 8
3 333 / 30 / 13 / 120 \ ballast & rig 140 310 \ 686." (Source: Original handwritten annotation on model. Undated.)

Model Description:
"#404 Coquina, 16'8" loa sailboat of 1889. Also used for #419 Coquina II of 1892 and, with modifications, for #474 Dude of 1896. See also first model for Coquina, seq 1225, not used." (Source: Bray, Maynard. 2004.)

Model Comment:
"Reference to Model 4 was added by CvdL because she was apparently also built as #419 Coquina 7/8-scale." (Source: van der Linde, Claas. 2008.)

Related model(s):
Model 1225 by NGH (1889?); sail, not built
Coquina (Study Model): Sailing Dinghy


Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.


Drawings

Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   HMCo #523s [As Coquina 2nd #419 7/8-scale] are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
  1. Dwg 130-054 (HH.5.10357): Sails > # 492 Violet (1898-01-28 ?)
  2. Dwg 080-067 1/2 (HH.5.05980): Sail and Rowboat Spars # 510, 522, 523 (1899-05-09)
Source: Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. Haffenreffer-Herreshoff Collection. Together with: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997. Together with: Numerous additions and corrections by Claas van der Linde.
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.

Documents

Nathanael G. Herreshoff

"[1899-06-21] Wed 21: Very fine & clear. Strong NW [wind]. Launched 3 of the (?) footers, at the cove. [Is this a reference to #522s, #523s, and #524s, three scaled-down Coquina row- and sail-boats?]" (Source: Herreshoff, Nathanael G. Diary, 1899. Manuscript (excerpts). Diary access courtesy of Halsey C. Herreshoff.)

Archival Documents

"N/A"

Note: This list of archival documents contains in an unedited form any and all which mention #523s [As Coquina 2nd #419 7/8-scale] even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.


Supplement

From the 1920 and earlier HMCo Index Cards at the MIT Museum
  • Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.
From the 2000 (ca.) Transcription of the HMCo Construction Record by Vermilya/Bray

Month: May
Day: 8
Year: 1899
E/P/S: S
No.: 0523
LW: 12'
B: 4' 6"
D: 8"
Rig: Cat
CB: y
Ballast: None
Amount: 150.00
Last Name: J.B.F.H. (Fred)

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

Research Note(s)

"N/A"

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
