HMCo #1032s Betty

Particulars

Construction_Record_Title.jpgName: Betty
Type: 12 1/2 Footer
Designed by: NGH
Setup: 1926-9-15
Finished: 1926-10-19 ?
Construction: Wood
LOA: 15' 6" (4.72m)
LWL: 12' 6" (3.81m)
Beam: 6' 0" (1.83m)
Draft: 2' 6" (0.76m)
Construction Class and Number: #1024-9
Rig: Gaff Sloop
Sail Area: 140sq ft (13.0sq m)
Keel: yes
Built for: Stone, Robert
Amount: $1,100.00
Note(s) in HMCo Construction Record: 12 1/2 footer 1024 class. #1024-9. Insured Sept 15/26. R[udolf] F[rederick] H[affenreffer] [apparently inspected finished boat] 10/19/26.

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.


Model

Model #716Model number: 716
Model location: H.M.M. Model Room North Wall Right

Vessels from this model:
409 built, modeled by NGH

Original text on model:
"12 1/2' Buzzards Bay boy class 24 boats 1915 scale 1/10 size three [sic, i.e. four? #806, #813, #815, #817?] boats 1916
16' w.l. Oyster Bay "Fish Class" 23 boats 1916 scale 1/12 size sections 1/13 lengths 3 1/2 added at bow on deck" (Source: Original handwritten annotation on model. Undated.)

Model Description:
"12'-1/2' lwl Buzzards Bay 12 1/2-class of 1915, HMCo's most popular creation with some 360 boats produced. Also, with change in scale and proportionally longer bow, the Fish class sloops of 1916 and beyond." (Source: Bray, Maynard. 2004.)

Related model(s):
Model XA2-1_01 by NGH (1914?); sail
Buzzards Bay 12 1/2
Model XA2-1_02 by NGH (1914?); sail
Fish Class


Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.


Offsets

Offset booklet number(s): HH.6.146-6

Offset booklet contents:
12 1/2-footer class, Fish class (Cape Cod Shipbuilding Embargoed)


Offset Booklet(s) in Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. (Restricted access --- see curator.)

Drawings

Main drawing Dwg 076-118 (HH.5.05569) Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   HMCo #1032s Betty are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
  1. Dwg 079-091 (HH.5.05900): Chain Plates & Mast-Band for Port Boat on "Roamer" (1902-05-03)
  2. Dwg 079-091 (HH.5.05901): Fittings for Port Boat on # 215 (1902-05-03)
  3. Dwg 130-124 (HH.5.10432); Sails > # 744 Design for Buzzard's Bay Boy's Boat (1914-10-11)
  4. Dwg 128-142 (HH.5.10269): Sails > Sails for No. 744 Class (1914-11-20)
  5. Dwg 081-111 (HH.5.06203): Spars for # 744 and Class (11 Boats), 12 1/2 Footer (1914-11-21)
  6. Dwg 081-111 (HH.5.06203.1): Spars for # 744 and Class (11 Boats), 12 1/2 Footer (1914-11-21)
  7. Dwg 065-064 (HH.5.04659); Rudder Hanging for # 743, Rudder and Hanging for # 744 Class (1915-02-15)
  8. Dwg 074-060 (HH.5.05348); Anchor for # 744 Class Made of Manganese Bronze (1915-03-30)
  9. Dwg 025-159 (HH.5.01916); List for # 744 Class, 12 1/2 Footers (1926-03-22)
  10. Dwg 148-000 (HH.5.12238); Construction Dwg > Herreshoff 12 1/2 Footer (ca. 1931)
  11. Dwg 076-118 (HH.5.05569); Construction Dwg > Herreshoff 12 1/2 Footer, 15'-8" O.A. x 12'-5" W.L. x 5'-10" Beam x 2'-5" Draft (1931-07-06)
  12. Dwg 076-118 (HH.5.05569.1); Construction Dwg > Herreshoff 12 1/2 Footer, 15'-8" O.A. x 12'-5" W.L. x 5'-10" Beam x 2'-5" Draft (1931-07-06)
  13. Dwg 128-142 [057-001] (HH.5.10270): Sails > Sails Plan 12 1/2 Footer Class (1934-06-04)
  14. Dwg 142-090 (HH.5.11837): Compartment Details for 12 1/2 Footers (1934-07-18)
  15. Dwg 130-124 (HH.5.10433); Sails > 12 1/2 Footer Class Gaff Rig Sail Plan (1938-02-19)
  16. Dwg 076-118 C (HH.5.06086): 12 1/2 Footer Class Gaff Rig Spar Details (1938-02-23)
  17. Dwg 076-118 C (HH.5.06086.1): 12 1/2 Footer Class Gaff Rig Spar Details (1938-02-23)
Source: Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. Haffenreffer-Herreshoff Collection. Together with: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997. Together with: Numerous additions and corrections by Claas van der Linde.
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.

Documents

Archival Documents

"[Item Transcription:] [Handwritten (in ink) note:] M Rating Design, based on model [Model 207] from which THISTLE [#1032s] was built, at scale 19/20 of measurement.
Length to be 8.5/12 of measurements
Breadths & depths 8/12 of measurements
Ratios. Lengths .708. Sections .442. Disp. .315
[Followed by list of particulars, always with two values, one in ink, and a second one penciled in and captioned 'Design to limits':]
Overall length 78.85; 81.0
L.W.L. 51.15; 55.
Qbl 50.50; 50.91
Qbl rule limit 49.3; 50.9
Beam 15.05; 15
Breadth l.w.l. 14.15; 14.1
Draft 9.3, Make = 10.25; 10.55
Displ[acement] 1395cuft = 1117^3; 1521 = 11.5^3
Freeboard 3.65+.2 = 3.85; 3.9
Freeboard rule limit = 3.8; 3.9
Wetted surface (approx[imate]) 895
S[ail area] for 46 rating = 52.9^2 = 2798; 53.3^2 = 2840 [Undated (on verso of printed Rhode Island Yacht Club Christmas Greetings card from 1920. Related to the M-boat designed from #1078s THISTLE's model sometime after THISTLE had been designed and was filed with other material related to that design]." (Source: Herreshoff, N.G. (creator). Handwritten Note. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDED1_00200. Folder [no #]. No date (After 1927-10).)


Note: This list of archival documents contains in an unedited form any and all which mention #1032s Betty even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

Further Reading
  • Bray, Maynard. "Restoration of 12 1/2 Footers. Part I." Wooden Boat #56, January/February 1984, p. 93-101. (1,293 kB)
    Document is copyrighted: Yes, used with permission. Copyright holder: Maynard Bray (text). Detailed Buzzards Bay 12 1/2 restoration step by step as performed by the Ballentine shop. Part I. Stem restoration, transom and frame replacement.
  • Bray, Maynard. "Restoration of 12 1/2 Footers. Part II." Wooden Boat #57, March/April 1984, p. 93-100. (1,036 kB)
    Document is copyrighted: Yes, used with permission. Copyright holder: Maynard Bray (text). Detailed Buzzards Bay 12 1/2 restoration step by step as performed by the Ballentine shop. Part II. Keel timber and coamings replacement.
  • Bray, Maynard (with photos by Benjamin Mendlowitz). "12 1/2 Footers." Nautical Quarterly, no. 37, Spring 1987, p. 47. (608 kB)
    Document is copyrighted: Yes, used with permission. Copyright holder: Maynard Bray (text), Benjamin Mendlowitz (photos). Short class portrait. Part of the larger article "Herreshoff Legacies."
  • Nagy, Steve. "The Herreshoff 12 1/2 Footer. Evolution Of The Class." In: Herreshoff Marine Museum (publ.). Proceedings. The 6th Classic Yacht Symposium. May 2-3, 2014. Bristol, RI, 2014, p. 1-23. (4,425 kB)
    Document is copyrighted: Yes. Copyright holder: Steve Nagy / Herreshoff Marine Museum. Short class history of the 12 1/2 as built by HMCo, Quincy Adams, Cape Cod Shipbuilding and others. Different models: Gaff, marconi, wishboom, Fishers Island. Detailed description of changes in configuration and equipment as boats were built over time. Identification guide for 12 1/2s missing their builder's plate. Photos. Original promotional material.

Supplement

From the 1931 HMCo-published Owner's List

Name: Betty
Type: J & M
Length: 12'6"
Owner: Stone, Robert

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

From the 1953 HMCo Owner's List by L. Francis Herreshoff

Name: Betty
Type: 12 1/2-footer
Owner: Robert Stone
Row No.: 910

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

From the 2000 (ca.) Transcription of the HMCo Construction Record by Vermilya/Bray

Year: 1928
E/P/S: S
No.: 1032
Name: Betty
OA: 15' 6"
LW: 12' 6"
B: 6' 0"
D: 2' 6"
Rig: J & M
Amount: 1100.00
Notes Constr. Record: 12 1/2 Footer. 1024 Class.
Last Name: Stone
First Name: Robert

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

From the 2007 12 1/2 Registry by Steve Nagy

Hull No.: 1032
Contract Date: 1928-07-03
Org. Name: Betty
Org. Owner: Robert Stone
Org. Rig: J&M

Source: Nagy, Steve. "The Herreshoff 12 1/2 Footer Registry." Version 2.0. August 2007. (http://h12.orrsford.com/H12_Registry_Ver_2-0.pdf, last visit May 23, 2008.)

Research Note(s)

"The HMCo Construction Record for this boat (and the entire #1024 class of 12 1/2s) does not show a contract date. Other boats listed on the same page of the Record were contracted for in 1928, leaving the false impression that this was also the case for the #1024 class. Close inspection, however, reveals thinly pencilled notes that this boat was insured already on September 15, 1926. HMCo usually insured boats when construction began and we may thus assume that the day when the boat was insured was very close to when it was set up, i.e. when construction began. The Construction Record also notes 'R.F.H. 10/26/19' which apparently signifies the date when Rudolf F. Haffenreffer inspected the finished boat." (Source: van der Linde, Claas. January 12, 2014.)

"Built in 34 days (setup to finished; equivalent to $32/day)." (Source: van der Linde, Claas. January 16, 2024.)

"Sail area approximately 140 square feet by rule." (Source: Herreshoff Manufacturing Company. Yachts by Herreshoff. The Herreshoff Manufacturing Company: Designers and Builders of Sailing and Power Craft since 1861. Bristol, Rhode Island, 1937.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
