Herreshoff #188401ep [Machinery only for St. Y. Satan]
Particulars
Type: Steam Engine Only
Finished: 1884
Construction: N/A
Displ.: 22,540 lbs (10,224 kg)
Propulsion: Steam, Herreshoff, Double exp., 2 cyl. (5" & 9" bore x 10" stroke)
Built for: N/A [W. O. Cutter owner in 1884]
Last reported: 1902 (aged 18)
Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.
Images
-
Further Image Information
Created by: Stebbins, Nathaniel L.
Image Caption: [Satan.]
Negative Number: 22
Image Date: 1884
Collection: Historic New England (SPNEA) Collection, GUSN 276581.
Image is copyrighted: No known copyright restrictions
Registers
1890-91 Manning's American Yacht List (#2510)
Name: Satan
Owner: W. O. Cutter; Port: Onset
Official no. 116070; Type & Rig Scw. Str. [Screw Steamer]
Tons Gross 11.27; Tons Net 8.40; LOA 50.0; LWL 47.0; Extr. Beam 10.4; Draught 4.5
Builder Wood Brothers; Designer J. B. Herreshoff; Built where East Boston; Built when 1884
Engine C[ompound] I[nverted] 2 Cy. 5 & 9 x 10. Ver[tical]. Tub[e Boiler]. 4' x 5', 1887.; Maker Herreshoff Mfg. Co. Kendall & Roberts.
1896 Manning's American Yacht List (#327)
Name: Satan
Owner: E. H. Noble, M.D.; Port: New Bedford, Mass.
Official no. 116070; Type & Rig Scw. Str. [Screw Steamer]
Tons Gross 11.27; Tons Net 8.41; LOA 50.0; LWL 47.0; Extr. Beam 10.4; Depth 4.5; Draught 4.5
Builder Wood Bros.; Designer J. B. Herreshoff; Built where East Boston, Mass.; Built when 1884
Engine C[ompound] I[nverted] 2 Cy. 5 & 9 x 10. Ver[tical]. Tub[e Boiler]. 4' x 5', 1887.; Maker Herreshoff Mfg. Co. Kendall & Roberts.
1902 Manning's American Yacht List
Name: Satan
Owner: E. H. Noble, M.D.; Port: New Bedford, Mass.
Official no. 116070; Type & Rig Scw. Str. [Screw Steamer]
Tons Gross 11.27; Tons Net 8.41; LOA 50.0; LWL 47.0; Extr. Beam 10.4; Depth 4.5; Draught 4.5
Builder Wood Bros.; Designer J. B. Herreshoff; Built where East Boston, Mass.; Built when 1884
Engine C[ompound] I[nverted] 2 Cy. 5 & 9 x 10. Ver[tical]. Tub[e Boiler]. 4' x 5', 1887.; Maker Herreshoff Mfg. Co. Kendall & Roberts
Source: Various Yacht Lists and Registers. For complete biographical information see the Herreshoff Catalogue Raisonné under Data Sources. Note that this section shows only snapshots in time and should not be considered a provenance, although it can help creating one.
Supplement
From the 1930s L. Francis Herreshoff Index Cards at the Herreshoff Marine Museum
- Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.
Research Note(s)
"It is possible that HMCo also delivered vessel plans for Satan as is indicated by the 1891 Manning's Yacht List. No information about this vessel nor its engine exists in Herreshoff records. The 1891 Manning's Yacht List described her steam engine as Herreshoff-built with 10" stroke, double expansion and 2 cylinders of 5" & 9" bore. The HMCo Construction Record appears to not list a single Herreshoff-built vessel with this type of engine, but it is believed that #52p Javelin was fitted with such an engine (see note in Javelin entry). Moreover, a period photo (Maynard Bray collection) of a steam engine and stamped 'Herreshoff M'f'g Co. Bristol, R.I. Builders of Steam Vessels, & Steam Machinery' was annotated by N. G. Herreshoff in March 1931 with 'An early compound engine 5in. & 9in. x 10in. in about 1880.' It appears that this photo shows the steam engine for Javelin or the one that Manning's Yacht List reported as having been fitted to Satan." (Source: van der Linde, Claas. June 5, 2018.)
"In the absence of better available data displacement was estimated by using the figure for Gross Register Tons (11.27) from the 1890-91 Manning's American Yacht List (Net Register Tons were reported as 8.4) and converting to lbs by dividing through 2000 (short tons). Note that this figure can only be a rough estimate because register tons as reported in Yacht Registers correlate only loosely with actual displacement figures." (Source: van der Linde, Claas. March 17, 2015.)
Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
Note
We are always interested in learning more about this vessel. If you want to discuss it or can share any additional information or images or to discuss a copyright concern, please do not hesitate to send an Email to the link below!
