Herreshoff #189301es [Cutter for #435s Colonia]
Particulars
Type: Yacht Tender
Designed by: NGH
Contract: 1893-5 ?
Construction: Wood
LOA: 18' 6" (5.64m)
Beam: 5' 1" (1.55m)
Rig: None (rowboat)
Built for: Rogers, Archibald [Syndicate]
See also:
Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.
Model
Model number: 701Model location: H.M.M. Model Room North Wall Right Door
Vessels from this model:
8 built, modeled by NGH
Original text on model:
"Cutter for 435, 437 (1893), 452 (1895), 18? (1896), 186 (1897), 499 (1898)" (Source: Original handwritten annotation on model. Undated.)
Model Description:
"Tenders for the America's Cup cutters Colonia, Vigilant, Defender and Columbia. Also for the steam yacht Vacuna and one unidentified vessel [possibly #184p Porter or #185p Dupont]." (Source: Bray, Maynard. 2004.)
Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.
Offsets
Offset booklet number(s): HH.4.086.4
Offset booklet contents:
# 18 1/2' boats for #435 and #437.
Offset Booklet(s) in Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. (Restricted access --- see curator.)
Drawings
![Main drawing Dwg 028-012 [075-032] (HH.5.02007)](../Images_Drawings/250px/HH.5.02007.jpg)
Explore all drawings relating to this boat.List of drawings:
Drawings believed to have been first drawn for, or being first referenced to
Herreshoff #189301es [Cutter for #435s Colonia] are listed in bold.
Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
-
Dwg 114-027 1/2 (HH.5.09524): 2 - 1 5/8" Davits for 84 W.L. Sailing Yacht # 429 (1893-04-01)
-
Dwg 028-012 [075-032] (HH.5.02007); Construction Dwg > 18 1/2 Foot Boat for Yachts Nos. 435 and 437 (1893-05-26)
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.
Documents
Archival Documents
"[Item Description:] Two sets of penciled pantograph hull sections of two different designs titled in right margin 'July 4th 1896. Figures for Capt. Converse for one 18ft 6in boat [and] one 14[ft] 3[in] boat for torpedo boats 6 & 7 [#189601es Cutter for #184p Porter, #189602es Cutter for #185p Dupont, #189603es Boat for #184p Porter, #189604es Boat for #185p Dupont]'. One set is marked 'Sections of cutter [from Model 701] designed for Nos 435 - 437 [#189301es Cutter for #435s Colonia and #189303es Cutter for #437s Vigilant]. Scale 1in' with calculations arriving at a displacement of 49.5cuft = 3180lbs and 'Disp[lacement] as per model 3180lbs. Est[imated] disp. of keel & deadwood 153[lbs]. [Sum] 3333[lbs]' and 'Estimates w[ei]ght of boat, oars & fittings 500lbs. Estimated weight of 17 persons 2833lbs. [Sum] 333[lbs]'. The other set is marked 'Sections of Rowboat, Regulation size [probably from Model 121]. Scale 1in' and calculations arriving at a displacement of 26.44cuft = 1700lbs and 'Estimated w[ei]ght of boats with oars & fittings 275lbs. Estimated w[ei]ght of 9 persons 1500lbs. [Sum] 1775[lbs]' and 'Disp[lacement] as per model 1700[lbs]. Disp[lacement] of Keel deadwood 75[lbs]. [Sum] 1775[lbs]'." (Source: Herreshoff, N.G. (creator). Pantograph Hull Sections. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE04_05990. Folder [no #]. 1896-07-04.)
① ②
Note: This list of archival documents contains in an unedited form any and all which mention #189301es [Cutter for #435s Colonia] even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.
Images
-
Further Image Information
Created by: Hemment, John C.
Image Caption: "Jun 29 1895. Capt. Hank Haff." [Though not identified by name we may safely assume that this is Colonia's Cutter because Hank Haff was captain of Colonia in 1895 and this photo perfectly matches details from the cutter's construction plan 028-012 (formerly 075-032).]
Negative Number: 134
Image Date: 1895-6-29
Collection: Herreshoff Marine Museum Collection, Hemment image number A14-0134.
Image is copyrighted: Yes, used with permission
Copyright holder: Herreshoff Marine Museum, Bristol, Rhode Island, www.herreshoff.org.
Supplement
Research Note(s)
"This vessel's contract date was estimated from the original plan date. Plan 28-12 (formerly 75-32) from which this boat was built was drawn 1893-05. #435s Colonia (for which this vessel was built) was contracted for 1892-12-13. This boat's contract or building date is about 5 months after #435s Colonia was contracted for." (Source: van der Linde, Claas. October 26, 2009.)
Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
