Model No. 214: Westward and Elena

Model by: NGH
Made when: September 1909
Stated model scale: 1/32
Model length (ca.): 50.8" (129.0cm)
Implied vessel LOA at 1/32 (ca.): 135' 5" (41.3m)
Power/Sail: S
Vessel Type: Schooner
Hull Configuration: Keel (1); Keel&Centerboard (1)
Model location: H.M.M. Model Room South Wall Center

Vessels from this model:
2 built, modeled by NGH

Original text on model:
"#692 September 1909 scale 3/8 frame space 20" WESTWARD
#706 December 1910 with cb Scale ditto for space and scale ELENA" (Source: Original handwritten annotation on model. Undated.)

Model description:
"96' lwl Westward, riveted steel schooner-yacht of 1910, and recently replicated in Holland as Eleanora. Also 96' lwl Elena of 1911 which was fitted with a centerboard." (Source: Bray, Maynard. 2004.)

Model discussion:
"One of Herreshoff's best known schooners was Westward which found its way to Britain and raced with the Big Class under the ownershipp of a Jersey man, Mr. TB Davis. Her plans now reside at the Massachusetts Institute of Technology, but the original model of Westward was given to Davis and his daughter when they visited Herreshoff on Rhode Island some time after Westward had won the King's Cup in 1935.
They had been given a tour of the model room by Herreshoff who told Mr. Davis he could have the model if he could pick it out from the many displayed there, which he did. This and other Westward memorabilia are on display in the Marine Museum in Jersey, Channel Islands. [Note: The presence of what appears to be the original model of Westward and Elena in the Model Room of the Herreshoff Marine Museum makes it unlikely that NGH gave away Westward's original model. Under date of September 23, 1934 NGH did, however, record pantograph hull sections of Westward's model in a form which strongly suggests that it was intended to facilitate the making of a model. It is this model which is believed to be in the collection of the Marine Museum in Jersey today. This model (acc. no. JERSM/1972/00241/014) is painted cream and dark red which also suggests that it is a presentation model and not the original design model.]" (Source: Ward, Peter. "Half Truths." In: Classic Boat, January 1997, p. 70.)
