Model No. 610: Navahoe

Model by: NGH
Made when: October 1892 (?)
Estimated model scale: 1/24
Model length (ca.): 61.8" (157.0cm)
Implied vessel LOA at 1/24 (ca.): 123' 7" (37.7m)
Power/Sail: S
Vessel Type: Cutter
Hull Configuration: Bulb&Centerboard
Model location: H.M.M. Model Room North Wall Left Door

Vessels from this model:
1 built, modeled by NGH

Original text on model:
"No. 429 NAVAHOE" (Source: Original handwritten annotation on model. Undated.)

Model description:
"84' lwl Navahoe, keel cutter of 1893." (Source: Bray, Maynard. 2004.)

Comment:
"Note that NGH design booklet entry dated September 30, 1892 refers to 'Navahoe. ... Calculations for final model of 84ft w.l. sloop for R. P. Carroll (#429), ...", suggesting that there must have been preliminary models. Note also that as early as February 1886, NGH had been working on a 84ft w.l. sloop as is evidenced by his notes in offset booklet HH.4.210." (Source: van der Linde, Claas. September 18, 2014.)
