Model No. 1122: [R-Boat (Study Model B)?]

Model by: NGH
Made when: October 1920 (??)
Estimated model scale: 1/16
Model length (ca.): 30.2" (76.8cm)
Implied vessel LOA at 1/16 (ca.): 40' 4" (12.3m)
Power/Sail: S
Vessel Type: R-Boat
Hull Configuration: Keel
Model location: H.M.M. Workshop South Wall Right

Original text on model:
"[Blank]" (Source: Original handwritten annotation on model. Undated.)

Model identification:
"Possibly newly identified model. This appears to be a model for an R-boat. In October/November 1920 NGH created a series of R-boat models for George Nichols, named Model A through E of which Model B has not been identified (and Model E is missing). This model may be Model B or be related to it. A plan (obj. no 2004.0001.0446, dated Oct. 15, 1920 and Nov. 7, 1920) in the Halsey C. Herreshoff Collection at the Herreshoff Marine Museum states that it is derived from Model B but differs in some respect from this model (even though its bow and forward keel profile are very similar). A set of penciled pantograph hull sections from the Halsey C. Herreshoff Collection at the Herreshoff Marine Museum titled 'Model B of Oct[ober] 15, 1920. Cut over July 12, 1929. 1st trial' also references Model B. (Compare this model with Model 1537 from 1929 which is labeled 'Study 1929 Scale ft' per 1ft' which shows great similarity and very similar length.)
This model clearly shows one or even two sections that have been glued on to the keel, indicating that it has been altered. Note also that the plan shows faint erased outlines of a slightly longer model with less draft onto which the current penciled profile is superimposed. Another plan in the Halsey C. Herreshoff Collection at the Herreshoff Marine Museum titled 'R-Class c.b. not used. Nov. 1920' appears to show an even better match for this model, even though it shows a centerboard boat, while this model has apparently been altered from centerboard to keel. Note that the Halsey C. Herreshoff Collection at the Herreshoff Marine Museum also holds a plan dated September 9, 1920 and titled "Center-board R Class. Design for F.J. Bedford" which appears to be rather similar in profile to this model, except for the shallower underwater body and centerboard." (Source: van der Linde, Claas. December 21, 2018.)

Related model(s):
Model 1125 by NGH??? (1919); sail Model 1122 by NGH (1920?); sail
Model 1130 by NGH (1920?); sail Model 1535 by NGH??? (1920?); sail Model 1115 by NGH (1920); sail, not built Model 1108 by NGH (1920); sail Model 1107 by ASdeWH (1920); sail Model 1114 by NGH (1921); sail Model 0225 by NGH (1925); #966s Grayling Model XA2-1_16 by NGH (1925); #932s Model XA2-1_17 by NGH??? (1926?); sail Model Ext07 by NGH (1925);
