Model No. 1227: Yacht Tender for Coconut Grove (Prelim.)

Model by: NGH
Made when: June 1927
Estimated model scale: 1/12
Model length (ca.): 8.0" (20.3cm)
Implied vessel LOA at 1/12 (ca.): 7' 12" (2.4m)
Power/Sail: S
Vessel Type: Hard-Chined Yacht Dinghy
Model location: H.M.M. Workshop West Wall Left

Vessels from this model:
Original text on model:
"8' 5" Yacht Tender
June 27, 1927
Depth reduced July 15 Sheer 1" Bottom 3/4" " (Source: Original handwritten annotation on model. Undated.)

Comment:
"See pantograph hull sections and profile in Halsey C. Herreshoff Collection at the Herreshof Marine Museum titled '8ft 5in Yacht tender of June 27 1927 and changed July 15, 3ft 3in wide and another model made July 15 [19]27 3ft 6in wide'." (Source: van der Linde, Claas. January 15, 2019.)

Model identification:
"Newly identified model. Reference to the hard-chined dinghy for towing to Coconut Grove #193003es was added by CvdL because its plan 028-065 was prepared at the same time (June 1927) as this model no. 25 and its preliminary model no. 1227 and because NGH wrote for 'towing ... to Coconut Grove" which clearly is a reference to his vacations spent there." (Source: van der Linde, November 6, 2010.)

Related model(s):
Model 0025 by NGH (1927); #192701es Model 1227 by NGH (1927); sail
