HMCo #427p APc3


Particulars

Construction_Record_Title.jpgName: APc3
Type: Navy Coastal Transport
Designed by: McInnis, Eldredge
Contract: 1942-2-19
Launch: 1942-8-26
Construction: Wood
LOA: 103' 2.5" (31.46m)
LWL: 98' 6" (30.02m)
Beam: 21' 2.5" (6.46m)
Draft: 8' 3.625" (2.53m)
Displ.: 112.0 short tons (101.6 metric tons)
Propulsion: Diesel, Superior, 400 h.p.
Propeller: 1 - 3 blade
Built for: U.S. Navy
Amount: $145,000.00
Note(s) in HMCo Construction Record: U.S. Navy Troop Transports

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.


Model

Model number: 3018
Model location: N/A (Missing, nonexistant or unidentified model)

Vessels from this model:
22 built, modeled by McInnis, Eldredge
#425p APc1 (1942)
#426p APc2 (1942)
#427p APc3 (1942)
#428p APc4 (1942)
#429p APc5 (1942)
#430p APc6 (1942)
#431p APc7 (1942)
#432p APc8 (1942)
#433p APc9 (1942)
#434p APc10 (1943)
#500p APc85 (1943)
#501p APc86 (1943)
#502p APc87 (1943)
#503p APc88 (1943)
#504p APc89 (1943)
#505p APc90 (1943)
#506p APc91 (1943)
#507p APc92 (1943)
#508p APc93 (1943)
#509p APc94 (1943)
#510p APc95 (1943)
#511p APc96 (1943)

Note: This model is missing, is nonexistant or has not been identified. The number of vessels built from it is only an estimate based on similar features, such as dimensions, rig, machinery, etc.


Offsets

Offset booklet number(s): HH.4.082

Offset booklet contents:
#413p, #414p, #411p, #412p, ['No 425' (sic, ie. #411p) Class Amc Coastal Transports']


Offset Booklet(s) in Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. (Restricted access --- see curator.)

Drawings

Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   HMCo #427p APc3 are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
  1. Dwg 000-000 [025-000] (HH.5.01978): List of Castings for 425- 434 Ap Boats (ca. 1942)
  2. Dwg 067-000 (HH.5.04804): Proposed Steering Gear for Apc Boats (1942)
Source: Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. Haffenreffer-Herreshoff Collection. Together with: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997. Together with: Numerous additions and corrections by Claas van der Linde.
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.

Documents

Other Herreshoff Family

"Model of AMc Mine Sweepers [preceding two words crossed out and replaced with] Transports, Apr[il] 1942.
Scale 3/8" = 1.
Templets[sic] made from Bureau of Ships Plans 446519 [and] 446513 and Eldridge-McInnis.
Design No. 287-C-728 Plan No 1.
In order to come fair the model differs from lines as follows:
Waterlines are fuller amidships with more tumble home.
Buttocks are raised forward of sternpost, deadwood faired.
Frame spaces 18.4".
Stations are 3-frame spaces or 4.6', except # 11 - # 11A which is 4-frame spaces or 6.132'.
Deduct 2 3/4" for planking.
Deduct 2 7/8" for deck.
Load W.L. is 10'-0" above base.
Stem as per Eldridge-McInnis plan E-McI. Hull No. 274, Sheet 1.
Bureau of Ships Plan No. 446513." (Source: Herreshoff, A. Sidney DeW.? [Penciled note in Offset Booklet HH.4.082.] Haffenreffer-Herreshoff Collection, MIT Museum, Cambridge, MA.)

Other Contemporary Text Source(s)

"The APC 3, third of its class to be completed at the Herreshoff Mfg. Company for the U S Navy, will be launched tomorrow at 10 a. m at the lower yard.
Miss Margaret Louise Hibbert, the daughter of Mr and Mrs. George Hibbert, 240 Hope street, will be the sponsor. Her father is the foreman of the cabinet shop at Herreshoffs and is a long-time employee of that company. Mr. and Mrs. Hibbert have two sons, both of whom are in the Navy.
The selection of Miss Hibbert to act as sponsor of the APC 3, was made as the result of a policy adopted recently by the Herreshoff Mfg. Company. A drawing by lot is made among the foremen, principal men and resident naval inspectors, and the wife or daughter of the winner becomes the sponsor of the ship to be launched.
The APC 3 is a special task naval vessel of which several are under construction at the Herreshoff yards." (Source: Anon. "Launching Tomorrow At Herreshoff's At 10 A. M." Bristol Phoenix, August 25, 1942, p. 1.)

"The launching of the APC 4 will take place tomorrow [August 29, 1942] at 9 o'clock at the lower yard of the Herreshoff Mfg. Company.
Mrs John Millar, wife of a construction foreman at Herreshoff's, will be the sponsor of the APC 4. Co-sponsors will be her two daughters, Barbara and Jane.
This marks the fourth of the special task naval vessels, known as the APC type, to be launched at Herreshoff's.
The APC 3 was launched Wednesday [August 26, 1942] morning with Miss Margaret L. Hibbert, daughter of George Hibbert, as sponsor." (Source: Anon. "APC 4 To Be Launched At Herreshoff's Tomorrow." Bristol Phoenix, August 28, 1942, p. 1.)

Other Modern Text Source(s)

"Class: APC-1
Design: Navy APC-1
Displacement (tons): 161 light, 258 lim.
Dimensions (feet): 103.25' oa, 98.2' wl x 21.25' e x 9.25' lim.
Original Armament: 4-20mm single
Later armaments: 2-20mm single (1943: APc 87-90, 93-98, 110-111)
Complement: 21 (1944)
Speed (kts.): 10
Propulsion (HP): 400
Machinery: Diesel, 1 screw
...
APc-3; [contracted: ] 19 Feb 42; [builder: ] Herreshoff Mfg; [keel laid: ] 3 Jun 42; [launched: ] 26 Aug 42; [commissioned: ] 11 Nov 42; [decommissioned: ] 26 Jan 46; [struck: ] 26 Feb 46; [disposed: ] 25 Feb 48; [fate: ] Maritime Commission / Delivery; [MA sale: ] 24 Feb 48; [note: ] Ex AMc-166. Sold (delivered) by MC to Foss Launch & Tug Co., Seattle, Wash. ..." (Source: Roberts, Stephen S. "Class: APC-1." Compiled October 26, 2008. http://www.shipscribe.com/usnaux/APC/APC01.html, retrieved October 25, 2011.)

Maynard Bray

"Twenty-two of these 'jacks of all trades' were built between October 1942 and July 1943 --- with an average of nearly one of these 103-footers each week. Each cost $145,750, and they appear to have been contracted for in two batches, with the lead ship [#425p] of the class (APc 1) included in the first batch of ten; APc 85 [#500p] through APc 96 [#511p] constituted the second batch. It was an impressive rate of production, especially so because the APcs were built concurrently with eight 71-foot British Vosper torpedo boats, which were built in the South Construction Shop." (Source: Bray, Maynard and Carlton Pinheiro. Herreshoff of Bristol. Brooklin, Maine, 1989, p. 226-227.)


Images

Supplement

From the 2000 (ca.) Transcription of the HMCo Construction Record by Vermilya/Bray

Year: 1942
E/P/S: P
No.: 427p
Name: APc3
OA: 103' 2 1/2"
LW: 98' 1 1/2"

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

Research Note(s)

"The design of the APc Coastal Transport Class was based on that of the Eldredge McInnis-designed 93ft AMc Minesweeper, lengthened by a 6ft plug. [Information based on a plaque at the Herreshoff Marine Museum.]" (Source: van der Linde, Claas. December 14, 2008.)

"Built in 188 days (contract to launch; equivalent to $771/day, 1191 lbs displacement/day)." (Source: van der Linde, Claas. January 16, 2024.)

"[Displacement 100 long tons.]" (Source: http://www.navsource.org/archives/09/23/23009.htm, retrieved March 29, 2011.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
