HMCo #329p Carola V

"[1919-02-25] Tue 25: Fine, calm. Vagrant [#719s Vagrant II] arrived to be hauled into south shop. No. 329 [Carola] launched from south shop." (Source: Herreshoff, Nathanael G. Diary, 1919. Manuscript (excerpts). Diary access courtesy of Halsey C. Herreshoff.)

"No. 329 [#329p].
115ft steam yacht for Mr. Richards.
Frame spaces 15 1/2".
Sheer heights to underside of deck.
Deduct for planking 1 7/16".
Deduct for timbers 2 3/8"." (Source: Herreshoff, N.G. [Penciled notes in Offset Booklet HH.4.052.] No date (ca. September 1917). Haffenreffer-Herreshoff Collection, MIT Museum, Cambridge, MA.)

"Carola V is the name of Commodore Leonard Richards's new yacht. This vessel is 115 feet long, 112 feet on the water-line, 15 feet 10 inches breadth and 6 feet draught. It is equipped with a triple-expansion engine and uses fuel oil. The yacht and engines were built by the Herreshoff Manufacturing Company from designs by N. G. Herreshoff. Commodore Richards will resume his cruising this year and may go to the St. Lawrence." (Source: Anon. "Spokes from the Rudder Wheel." Rudder, May 1919, p. 256.)

"A new 115-foot steam yacht building at Herreshoff's for Leonard Richards, N. Y. Y. C., was inspected by Mr. and Mrs. Richards last week. This craft, to be known as the Carola VI, is all planked and has some of the cabin houses erected. It is expected that the Carola will be launched in two weeks, and when in commission she will be commanded by William E. Torrey." (Source: Anon. "Notes from the Week's Log." Boston Globe, June 8, 1919, p. 60.)

"Carola V, Leonard Richards' new oil burning steam yacht, was given her trials in Narragansett Bay last week and the vessel will be turned over to her owner shortly." (Source: Anon. "Notes from the Week's Log." Boston Daily Globe, June 22, 1919, p. 61.)

"... Recently the new oil burning steam yacht Carola V, built by Herreshoffs for Leonard Richards of New York, was given a speed test in Narragansett Bay. Although the engines were not entirely limbered up, the craft exceeded 25 miles an hour. The Carola V, 115 feet in length, has much the appearance of a destroyer with excellent cabin appointments. ..." (Source: Anon. "Notes from the Week's Log." Boston Globe, July 13, 1919, p. 51.)

"The new steam yacht Carola V, owned by Leonard Richards, New York Yacht Club, of the destroyer type, which was built at Herreshoff's last Spring, arrived at Bristol last Wednesday from a lengthy cruise." (Source: Anon. "Notes from the Week's Log." Boston Daily Globe, September 21, 1919, p. 61.)

"United States Customs Service. Collection District No. 10, Port of New York. Notice is hereby given that under the Act of Feb. 19, 1920, and in pursuance of authority granted by the Commissioner of Navigation, on the application of Joseph Snyder, of New York, N. Y., the name of the steam yacht Carola, burden 100 gross tons, official number 218248, has been changed to Martrese." (Source: Durning, Harry M. Collector of Customs. "Change of Vessel's Name." Nautical Gazette, 1926, vol. 110, [p. 12?].)

"United States Customs Service. Collection District No. 10, Port of New York. Notice is hereby given that under the Act of Feb. 19, 1920, and in pursuance of authority granted by the Commissioner of Navigation, on the application of Allen K. Carter, the name of the steam yacht 'Navette,' burden 100 gross tons, official number 218248, has been changed to 'Aera'." (Source: Durning, Harry M. Collector of Customs. "Change of Vessel's Name." Nautical Gazette, 1933, vol. 123, [p. 32?].)

"... Official Number; Rig; Old Name; New Name; Gross; Home Port; Date of Change
218248; St.s.; Aera; Falcon; 68; New York, N.Y.; Apr. 4 [1937?] ..." (Source: Merchant Marine Bulletin, 1938, vol. 3-4, [p. 18].)

"N/A"

"[Item Transcription:] [Typewritten letter on 'Eleven Thomas Street New York' stationery:]
Dear Mr. Nat,-
Thank you for your letter of the 21st Inst.
I hope I can come to Bristol within the next two or three weeks.
You are correct in thinking that Mr. Slocum wants a heavily built craft [what eventually became #191901ep Unbuilt Steam Yacht for Thomas Slocum], and that she should be built to Lloyd's rules, I think I can get the blue-print showing the interior arrangements of the old 'RANGER', which will give us data to start from. She was carefully worked out to Mr. Slocum's ideas in many ways; as for instance, width of deck at the side of houses that would just fit a steamer-chair, etc.
I hope to get the question of an order for a new patrol boat settled within a few days.
Understand from Swasey that the Richards boat [#329p CAROLA V] is one that we can build at our leisure, [the remainder handwritten in ink] and as the Gov't now has power to commandeer shipyards think it is a matter of safety to be mostly engaged in work destined for their use.
Yours sincerely ..." (Source: Nichols, George. Letter to N.G. Herreshoff. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE04_07130. Folder [no #]. 1917-07-30.)
①

"[Item Description:] Penciled pantograph hull sections titled '#329 [CAROLA V]'. With calculations arriving at a displacement of 1960[cuft ? = 125440lbs ?] = 58.8[tons ?]. Marked '1918 ?' in upper margin (CAROLA V was designed in November and December 1917). On verso an unidentified sketch or section." (Source: Herreshoff, N.G. (creator). Pantograph Hull Sections. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE04_06830. Folder [no #]. 1917-11 ??.)
① ② ③

"[Item Description:] I hope to have #306 [SP-1841] ready to run again early next week, she is now hauled out, one cylinder is rebored and the other partly done, #312 [STINGER] is in the water and nearly ready to leave, #308 [SP-1841] should be ready in about ten days, #303p NAVETTE's superheater, French gov't has asked us to bid on large patrol boat, Sid and Winslow are working out a design, Richards is ready to sign up if we give him 19kn speed [this will be #329p CAROLA], store house is half finished and cottage is now on Brownell's place" (Source: Swan, James. Letter to N.G. Herreshoff. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MR_50840. Subject Files, Folder [no #]. 1917-11-19.)
① ②

"[Item Description:] machine shop is improving, #321 engines are now erected, Brechin has #323 nearly ready to frame, #321, had #312 [STINGER] running at the dock, the first 40ft launch [#324p] is practically completed, three others [#325p, #326p, #327p] are planked, and the 5th [#328p] and last will be in frame next week, the completed boat makes a very good appearance and will go overboard in a day or two, #306 [SP-1841] will hopefully be complete next week, design for the French [patrol] boat is as follows [150ft LOA, 18ft beam, other dimensions], will also bid on smaller 18kn boat, Swasey still seems confident to close up the Richards boat [this will be #329p CAROLA], have not yet received a cent on the 40 footers, bank account is getting pretty short, [financial summary by building no], risk of not completing the steel boats promptly, your young friend from Bermuda McCallan is here and working in Mr. Brechin's gang" (Source: Swan, James. Letter to N.G. Herreshoff. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MR_50860. Subject Files, Folder [no #]. 1917-12-01.)
① ② ③ ④

"[Item Description:] had successful trial of #306p [SP-1841], #309p [SP-1218 ] came in with damage from grounding and crew managed to inflict further damage, [C.F.] Adams was here last week, none of the other directors has been here except Swasey, the latter is still after the Richards [#329p CAROLA] and Stone [#374p ALERT] contracts, technical specifications for French patrol boats, are setting up the 'sample' 25ft destroyer launches [#330p], also have an order for a 12 1/2 footer [#824s], first 40ft launch [#324p C365] is in the water and has had a successful trial, first boiler was put into #321 [SP-2235] today, #323p [SP-2840] to be set up on Dec 17, machine shop problems, Bob Emmons apparently in Europe, #312p is now in Boston" (Source: Swan, James. Letter to N.G. Herreshoff. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MR_50900. Subject Files, Folder [no #]. 1917-12-11.)
① ② ③

"[Item Description:] Navy Dept. ordered ten aeroplane lighters [#191801es, #191802es, #191803es, #191804es, #191805es, #191806es, #191807es, #191808es, #191809es, #191810es], 58ft x 16ft, sort of a small floating dock arranged to carry an aeroplane, $15,000 each, built special construction shed [sketch], want six if possible by March 1, first class job for Brechin, will delay #323p [SP-2840] which is framed and being plated, #306p [SP-1841] and #308p [SP-2232] are finished and waiting for gov't action, Tod has paid for his boat [#308p SP-2232] in full, #321p [SP-2235] is almost done, one 40-fter [apparently #324p C365] has been delivered to Newport but ice is holding the other two [apparently #325p C366 and #326p C367] here and I had them picked up by shears and put on wharf, the last two [apparently #327p C368 and #328p C369] are nearly finished, they have proved expensive boats and we shall no more than make overhead on them, store house is done except cement work in vault, destroyer launch [#330p] is almost finished and is a fine little boat, hope we can build more like her, order for an aeroplane hull or pontoon [#341p NC-4], [Ernest] Alder has gone to Curtiss Works to observe and is now laying the boat down, work has commenced on Richards boat [#329p Carola], the RESOLUTE launch has been sent to Bob's [Emmons] ship the Mt. Vernon as tender" (Source: Swan, James. Letter to N.G. Herreshoff. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MR_50930. Subject Files, Folder [no #]. 1918-01-08.)
① ② ③ ④

"[Item Description:] shed for seaplane barges is complete, machine shop consultant, 4 steel boats [apparently #306p SP-1841, #308p SP-2232, #309p SP-1218, #321p SP-2235] have been ordered taken away by gov't but can't move due to ice, shall launch #322p [SP-2373] on Monday and then set up Richards boat [#329p Carola], #323p SP-2840 is about all plated" (Source: Swan, James. Letter to N.G. Herreshoff. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MR_50970. Subject Files, Folder [no #]. 1918-01-26.)
① ②

"[Item Transcription:] [Typewritten letter on 'Lawrence Gas Company, R.W. Emmons, 2D, Treasurer, 79 Milk Street, Boston, Massachusetts' stationery:] Your letter of January 1st [1920] I received more than a week ago. I have delayed answering it until after the New York Yacht Club meeting, which was held night before last, as George Cormack telegraphed and wrote you.
The Committee replied to Lipton they would agree to his terms, namely, to race, beginning July 15th off Sandy Hook, but declined to make any alteration in rig in the way of Marconi topmast. This being settled, George [Cormack] and I have got underway with the schedule for captain, mates and crew for Resolute. [Chris] Christiansen with John Christiansen, whom we had the first year will be our Captain and first mate [on #725s RESOLUTE]. We have already obtained some of our old men.
The question of tender still troubling us. Steamers like CAPE COD will cost to run this year nearly $45,0000 a piece for each boat, which seems a sinful waste of Syndicate money. Charlie [Adams] and I are both in favor or rechartering the QUEEN [#657s], and in order to obtain if necessary more room, building a house over her from the main deck forward in the line of a receiving ship. This will enable us to mess all the men at the same time and give us ample accommodations for sails, supplies and for ourselves. Such a lay-out together with Harold Vanderbilt's tender [#301p MAGISTRATE] would be adequate for our purpose. Nothing definite has been settled, but this is what Charlie and I lean towards. George [Cormack], however, is still in favor of steamers.
The Cup Committee have decided to begin the racing on May 2lst --- a series of 5 races to he held off New Haven; an interval then for alterations, refit, etc., and then a series to begin off Newport about June 4th and continue until the first of July. Newport races only to actually count for selection.
This being the schedule it is out opinion that RESOLUTE should be launched about May 1st, as with her crew on the spot it will not take long to rig her, and from experience of previous years, weather at that time is none too favorable anyway. I do not know how this will suit your plan, but I think if you plan to arrive about that time we can get on all right.
The new wooden mast for RESOLUTE has not been started and there is some discussion as to where to built it. Your ideas were that it should be built in the south shop, if I remember correctly, and unless I hear from you to the contrary I will have it constructed there. Chase has the rigging for same practically all completed. There is not much else to report regarding RESOLUTE.
George Nichols is to arrive in Boston for our Directors meeting next week, and at that time he and I will take up with Sidney the subject of making winches for him, as per an understanding you had with him just before you sailed.
Jim Swan has no doubt written you regarding all the other work in the shop; especially work on the schooner [#827s OHONKARA] seems to have gone on very satisfactorily.
The first little S boat is practically completed, and some of the proposed owners of same have made inspection.
All seem to be pleased with the boats with the exception of one point, and opinion has been so strongly expressed that I have taken it upon myself to alter the specifications as originally planned by you, and I trust you will understand and forgive me in case you have any feeling in the matter. The case is this. The present oak ribbon which you have designed and placed on the first boat with the hollow under side, in place of the usual pear-shaped shear streak, they all desire changed for the older method.
While I recognize your idea, which is a good one both as to cover board for the canvas deck and also the hollowed out underside for shedding water, it gives the boats a very heavy effect looked at from broadside or stern view, and I thought it best to meet their desires in the matter, and the other boats will be built as I stated above on the old method. The only other alteration was the slight tipping of the seats in the deep cockpit boats; the first boats seats are flat, and while comfortable enough in the forward part of the cockpit, are not as comfortable as if dipped in the after part.
Chase is going at the rigging for these boats and the first mast is all done. I will follow out your suggestion and have the boat launched and weighted according to your instructions, but if the weather holds mild, although it has been very cold recently, Charlie Adams and I propose to rig up, launch and try out the first boat under sail before the other sails are made, and I think between us we will discover anything that may not be just right. Arthur Adams, Charlie's brother has just ordered four more 12 1/2 footers, and as we were already building one, we have taken the order for the other four at $750 a piece.
We are in hopes of getting an order for a good-sized house boat to carry us through the spring and summer work. Swazey is on his way South to see two or three gentleman regarding same. We shall need this new work soon.
The expert accountants have been making the annual audit, but at the time of the stockholders meeting held last Thursday, complete figures were not in. I am sorry to have to tell you that their figures so far bring us out with a loss instead of a profit for the year. As soon as I get the final correct figures I will forward you a copy, but although Mr. Garfield, Charlie Adams and myself, as well as Young and Swan are convinced that the profit we should have showed is tied up somewhere in the inventory and we have not yet been able to dig it out. We have already dug out $6,000, and I am in hopes we may find other misrepresentations.
I am convinced our methods are all right, and our book-keeping system all right, and further that any Company which could have paid off $100,000 indebtedness as we did the past year is a good-going concern, and even if this year's statement shows us behind instead of ahead, I am confident we will only come out with all the better balance this coming year. The officers and directors of the previous year were all elected at the meeting, and we are to hold as i stated a Directors meeting Wednesday next.
You must be having splendid weather and a fine time, It seems hard to think of you sailing in summer clothes, while we are experiencing 5 below zero day before yesterday, and now a snow storm with a foot and a half on the ground.
The Alumni of Harvard have chosen me to be their chief Marshal on my Twenty-fifth anniversary this coming June.
This same honor was given to Charlie Adams on his Twenty-fifth, and on that day I am afraid the RESOLUTE will have to stop work --- otherwise my attention from now on will be largely given to her.
They are already at work on the SHAMROCK pearing off some of her fore-foot, and I believe further they are expecting to relay the deck. George [Nichols] will have a hard time to get his work [on VANITIE] done in the same yard, but I do not think we can possibly do anything more for him than we have agreed to. His present plans are, namely; shorten bowsprit and main boom while increasing the height of his rig a little, thereby reducing his sail area enough to reduce his time allowance 30 seconds. Charlie and I think he is working in the wrong way. We would both have left the base line as it is and increased the rig at least 500 sq. ft if not more, giving us more allowance, trying to come nearer to to SHAMROCK's rig. There it would give us a better line on how we will go with the latter. However, I do not think it makes much difference what he does, or what SHAMROCK does, for as Charlie says, if we cannot beat them both we had better quit racing for good.
With my very best wishes for a Happy New Year to you and Mrs. Herreshoff, and hoping to hear from you soon, and further trusting my delay in answering your letter is offset by what I have written, I am
Yours faithfully, ...
P.S.: Since writing I have been in communication with Mr. Kittredge the expert accountant and his statement is as follows; namely that if we fail to find any further discrepancy in the inventory to offset what loss the Company now shows as per figures sent you, there are two items to account for a large loss, namely: The Richards contract [#329p CAROLA] on which we allowed $3,000 for completion and delivery this year, has probably cost us, as figures will show, nearer $8,000. Then since you left, as probably Jim Swan has written the government has assessed their war tax against us on all contracts completed since that law was out into effect, excepting the Richards boat. These taxes amount to some $9,900, and we cannot include them in this years assets, for the reason that in the case of Harry Lippett [#368p MARY ANN], he has refused to pay his tax. In the case of the Sabine launch and the Codman launch [#342p, #343p, #344p or #345p?], as no account of this was made to them, it is the feeling of the Directors that we must pay the tax, although we may get Mr. Codman's. In the case of of Herrick [#311p APACHE and #371p GYPSY] and Crozier [#369p SUNFLOWER], Pinchon [#372p VASANTA] and the others, the matter has been brought to their attention I understand, and we should expect their taxes. Since, however, this question has arisen, we have had a legal clause drawn, and all contracts now go out from the Company's office including this clause and precluding any liability on the part of the Company being stuck for the taxes, as it states this must be paid before delivery is made.
Please do not worry yourself any over these financial details, however, as I think everything will come out all right in the end.
[Penciled PPS:] Enclosed is copy of Butler Duncan's letter just rec[eive]d regarding dates for trial races." (Source: Emmons, Robert W. Letter to N.G. Herreshoff. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MR_26390. Subject Files, Folder 6, formerly 90-95. 1920-01-17.)
① ② ③ ④ ⑤ ⑥ ⑦

"[Item Description:] Handwritten notebook titled on outer cover 'Droughting Room. Blue Prints Record' providing a list of drawings with information in columns titled 'Issued To', 'For Job', 'Date', 'Date Returned', '[Date] Destroyed', and 'Remarks'. Vessels mentioned are #1266s BELISARIUS, #1267 FROSTFISH, #395p Owner Launch for St.Y. VIKING, #1265s NITRAMON, #1204s SILVERHEELS, #1233s RAINBOW, #1276s PRIM, #1275s MITENA, #907s PLEASURE, #931s NASSAU, #711s VENTURA, #900s IRIS, #982s WATER LILY, #891s WILDFIRE, #1147s WEETAMOE, #954s MARY ROSE, #880s JOSEPHINE, #788s MANATEE, #1146s ENTERPRISE, #1212s TRONDA, #1282s 12 1/2 for H. V. Reed, #1302s Amphicraft for N. F. Ayer, #1304s Amphicraft for Charles A. Welch, #1286s 12 1/2 for Mr. Maitland Alexander, #1311s Amphicraft for Dr. Seth M. Milliken, #1313s Dinghy for #663s RAMALLAH ex-ISTALENA, #1314s HMCo Yard Skiff, #408s PELICAN, #1315s BRENDA, #396p Power Tender for FONTINALIS, #397p Power Tender for FONTINALIS, #329p CAROLA, #1318s Sailing Dinghy for Henry S. Morgan; #1316s NOVA, #1319s Tech Dinghy, #1317s MANDOO II, #405p Surfboat, #1379s Fish Class for H. M. Lautmann (MERRY HELL), #1385s TINKER TOO, and #1384s AVANTI. 23 pages were used. Undated, the dates range from October 1934 to September 1936." (Source: Herreshoff Manufacturing Co. (creator). Notebook. MIT Museum, Hart Nautical Collections, Haffenreffer-Herreshoff Collection Item HH.6.106. Box HAFH.6.3B, Folder Blue Print Record Book. No date (1934-10 to 1936-09).)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱

Note: This list of archival documents contains in an unedited form any and all which mention #329p Carola V even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

• Carola (HMCo-made index card)
• Carola (MIT Museum-made index card)
• Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.

Name: Carola
Type: Steam [sic, i.e. gasoline]
Length: 112'
Owner: Richards, Leonard

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

• Carola
• Martrese ex-Carola
• Carolta ex-Carola
• Varona ex-Carola
• Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.

Name: Carola
Type: 115' power using oil
Owner: Leonard Richards
Year: 1919
Row No.: 104

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

Year: 1917
E/P/S: P
No.: 329
Name: Carola (Martrese)
OA: 114'

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

"Steam engine rating 820hp from undated (1903 or later) diagram by N. G. Herreshoff titled 'Marine Engine. Weights and Prices' in the Halsey C. Herreshoff Collection at the Herreshoff Marine Museum." (Source: van der Linde, Claas. March 24, 2019.)

"Marine Engine of Open Type. 10 & 16 & 25 x 13 1/2, 460[rpm], 810[hp]." (Source: Herreshoff, N. G. Handwritten List of HMCo-Made Steam Engines. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum, MRDED1_00220. Undated, between 1903 and 1918.)

"N/A"

"In the absence of better available data displacement was estimated by using the figure for Net Register Tons (68) from the 1920 Lloyd's Register of American Yachts (Gross Register Tons were reported as 100) and converting to lbs by dividing through 2000 (short tons). Note that this figure can only be a rough estimate because register tons as reported in Yacht Registers correlate only loosely with actual displacement figures." (Source: van der Linde, Claas. March 17, 2015.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
