HMCo #1221s [Tender for #1226s Yawlcat]
Particulars
Name: [Tender for #1226s Yawlcat]Type: Frostbite Dinghy
Designed by: NGH
Contract: 1932
Construction: Wood
LOA: 11' 4" (3.45m)
Beam: 4' 6" (1.37m)
Rig: Cat
Centerboard: yes
Ballast: None
Built for: Herreshoff Mfg. Co. [Edward E. Mallinckrodt Jr.]
Amount: N/A
Note(s) in HMCo Construction Record: Sailing dinghy. Built for stock and used as tender for #1226 "Yawlcat"
See also:
Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.
Model
Model location: Private collection (John P. Morgan II in 1973)
Vessels from this model:
4 built, modeled by NGH
Original text on model:
"12ft sailing dinghie for Shuttle. NHG [sic, i.e. NGH]. Coconut Grove 1928." (Source: Original handwritten annotation on model. Undated.)
Model Comment:
"Reference to model Ext02 was added by CvdL because, as per the Maynard Bray Dinghy Database, plan 28-77.3 notes this dinghy to have been built on the molds of #192802es, the dinghy for Shuttle, which in turn was built from model Ext02." (Source: van der Linde, Claas. April 21, 2009.)
Drawings
Explore all drawings relating to this boat.List of drawings:
Drawings believed to have been first drawn for, or being first referenced to
HMCo #1221s [Tender for #1226s Yawlcat] are listed in bold.
Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
-
Dwg 028-077 (HH.5.02078); Construction Dwg > 11'-4" "Frost Bite" Dinghy [# 1221] (1932-02-15)
-
Dwg 028-077 A (HH.5.02079): Sails > Revised Sail Plan for 1220 (Tender for 1226) (1932-06-18)
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.
Documents
Other Contemporary Text Source(s)
"... In the small boat shed along with several Frostbite Dinghies [#1221s Tender for #1226s Yawlcat and #1220s Kid-Pleurisy], half a dozen Buzzard's Bay 12 1/2 Footers [of the #1197 class], two S boats [#1130s Aeolus and #1180s Penguin] and the last three of the dozen new Herreshoff 23 foot Class boats [probably #1223s Buza, #1224s Altair and the centerboard FI-23 #1225s Crusader] is a new all-teak Starboard launch-tender [#394p] for Mr. Alfred Loomis' 95 power yacht 'Katoura' [#391p] which is being commissioned for Summer service. ..." (Source: Anon. "Herreshoff Shops Hum with Boating Season Activities." Bristol Phoenix, May 17, 1932, p. 1.)
Supplement
From the 1920 and earlier HMCo Index Cards at the MIT Museum
- Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.
From the 2000 (ca.) Transcription of the HMCo Construction Record by Vermilya/Bray
Year: 1932
E/P/S: S
No.: 1221
OA: 11' 4"
B: 4' 6"
Rig: Cat
CB: y
Ballast: None
Notes Constr. Record: Sailing Dinghy. Used as tender fo #1226 "Yawlcat".
Last Name: Built for Stk
Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.
Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.
Research Note(s)
"HMCo Drawing 028-077 (HH.5.02078) shows this boat to have had rope-steering like a Coquina." (Source: van der Linde, Claas. May 17, 2019).
"Plan 28-77.3 from which this boat was built was drawn 1932-02-15. #1226s Yawlcat (for which this vessel was built) was contracted for ca. 1932-03-22." (Source: van der Linde, Claas. October 26, 2009.)
Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
Note
We are always interested in learning more about this vessel. If you want to discuss it or can share any additional information or images or to discuss a copyright concern, please do not hesitate to send an Email to the link below!
