HMCo #276p [Launch for Sch. Y. Intrepid III]

"[1911-04-06] Thu 6: Trying Intrepid's launches. New 25' one [#276p] very satisfactory. Old one [#575s ?] needs smaller screw.
[1911-05-25] Thu 25: Intrepid here in PM and got launch [#276p] built for her. T[hunder] & L[ightning] storm in PM." (Source: Herreshoff, Nathanael G. Diary, 1911. Manuscript (excerpts). Diary access courtesy of Halsey C. Herreshoff.)

"Ap[ril] 6, 1911
#276. 25ft launch of Intrepod.
Launch, new model 6ft 3in beam. Mahogany plank & teak deck & finish.
[Motor] Buffalo 10hp, 4 cyl[inder] 3 1/2 x 5. Screw 3 bl[ade] 20 1/4 x 21 [pattern] # 9806. W[ei]g[h]t complete [blank]. W[ei]g[h]t of hull & shaft only 1315lbs.
On 1/2 mile [course in] harbor. 5 [persons] onboard, calm.
Up 3m-29s. Dwon 3m-20s. Speed = 8.79[mph].
With one on board (Nat [NGH Jr]). Wind SSW 14[mph].
Up 2m-58s. Down 3m-5s. Speed = 9.9[mph].
[Followed by tabulated trial run data with mean speed being 9.87mph = 8.58kn]
[April 17, 1911]
Intrepid's Cutter which w[as] fitted with a Buffalo 2 cy[linder] 5hp motor after changing to new screw 18in x 16in(?) ran well and between 7 & 7 1/2 miles [per hour].
Weather conditions were not favorable for trial on course. Ap[ril] 17th." (Source: Herreshoff, N. G. Handwritten note in Trials Booklet '1898 - 1909' under date of April 6, 1911 and April 17, 1911. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum.)

"N/A"

"[Item Description:] Penciled pantograph hull sections and displacement curve titled 'No [blank]. 25ft Launch for Intrepid [#276p, Model 419]. Oct 20, 1910. scale 1in per ft. 24ft 0in w.l.'. With calculations arriving at a displacement of 3002lbs." (Source: Herreshoff, N.G. (creator). Pantograph Hull Sections. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE04_01170. Folder [no #]. 1910-10-20.)
①

"[Item Transcription:] Handwritten (mostly in pencil but also in ink) trials booklet titled '1898 - 1909'. Relevant contents:
§59: #276p [LAUNCH FOR SCH. Y. INTREPID] Trial Run mean speed 9.87mph (1911-04-06 & 1911-04-17)." (Source: Herreshoff, N.G. (creator). Trials Booklet. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE09_00060. Folder [no #]. 1898-09 to 1911-04.)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓ ㉔ ㉕ ㉖ ㉗ ㉘ ㉙ ㉚ ㉛ ㉜ ㉝ ㉞ ㉟ ㊱ ㊲ ㊳ ㊴ ㊵ ㊶ ㊷ ㊸ ㊹ ㊺ ㊻ ㊼ ㊽ ㊾ ㊿
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪

Note: This list of archival documents contains in an unedited form any and all which mention #276p [Launch for Sch. Y. Intrepid III] even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

• Intrepid (HMCo-made index card)
• Intrepid (MIT Museum-made index card)
• Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.

Name: Intrepid
Type: Gasoline
Length: 25'1"
Owner: Phoenix, Lloyd

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

• Intrepid
• Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.

Name: Intrepid
Type: 25' 1" tender
Owner: Lloyd Phoenix
Row No.: 299

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

Year: 1910
E/P/S: P
No.: 276
Name: Intrepid
OA: 25' 1"
LW: 24' 2"

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

"Power launch for Lloyd Phoenix' steel schooner yacht Intrepid III, designed by Beavor-Webb and built 1903 bei T. S. Marvel & Co. in Newburgh, New York, 171ft LOA, 127ft LWL, 28ft beam and 16ft draft." (Source: van der Linde, Claas. June 3, 2009.)

"Frame spaces 8". Stem - white oak. Keel - white oak 1 3/8". 3/8" below rabbit. False keel [oak] 1 3/8". ... Planking 1/2"-1/4" mahogany ovr 1/4" cedar. Teak sheer strake special metal protection ... Teak stern board 5/8" ? or 3/4". Deck beams white oak 5/8" x 1 3/8". Clamps 6 pine 1 7/8" x 1 7/8"." (Source: Herreshoff Manufacturing Company. [Note on plan 5-100 for #276p.] Bristol, October 15, 1910.)

"Note that the HMCo name index card for #276p Launch for Sch. Y. Intrepid lists September 10, 1908 (and not September 1910) as contract date. This is apparently an error and the correct contract date was probably September 10, 1910. See the note for #279p where a similar mistake was made but discovered and corrected." (Source: van der Linde, Claas. October 29, 2014.)

"Built in 257 days (contract to delivered; equivalent to 12 lbs displacement/day)." (Source: van der Linde, Claas. January 16, 2024.)

"Weight of completed hull, no machinery or rudder, 1315[lbs]." (Source: Herreshoff Manufacturing Company. Penciled note on Construction Plan 5-10 (HH.5.0328). October 15, 1910.)

"[Total displacement] 3002lbs." (Source: Herreshoff, N. G. Penciled note on Pantograph Hull Sections for #276p 25ft Launch for Intrepid. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum. October 20, 1910.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
