HMCo #333p [Crew Launch for #377p Ara]


Particulars

Construction_Record_Title.jpgName: [Crew Launch for #377p Ara]
Type: Destroyer Power Launch
Designed by: NGH
Contract: 1918 ?
LOA: 26' 2" (7.98m)
LWL: 24' 1" (7.34m)
Beam: 6' 6" (1.98m)
Draft: 2' (0.61m)
Displ.: 2,000 lbs (907 kg)
Propulsion: Gasoline
Built for: Dane, Ernest B.
Note(s) in HMCo Construction Record: Designed for use as tender on Destroyers. One taken by U.S.N., one used as tender for Resolute [ #725s], two used as tender for Ara [#377p], one ---

See also:
#192205es [Dinghy for #377p Ara] (1922)
#332p [Owner Launch for #377p Ara] (1918)
#377p Ara (1922)

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.


Model

Model #419Model number: 419
Model location: H.M.M. Model Room West Wall Left

Vessels from this model:
27 built, modeled by NGH
#192003ep [Owner Launch for Guinevere] (1920)
#192004ep [Crew Launch for Guinevere] (1920)
#276p [Launch for Sch. Y. Intrepid III] (1911)
#277p Isabel (1911, Extant)
#278p [Power Launch for #692s Westward] (1911)
#279p Premier (1911)
#281p Sterling (1911)
#282p [Launch for St. Y. Corsair III] (1911)
#283p [Launch for Aloha II] (1912)
#286p [Stock Launch] (1912)
#287p [Stock launch later Crew Launch for #722s Katoura] (1912)
#294p [Tender for St. Y. Noma] (1914)
#297p [Crew Launch for St. Y. Wayfarer] (1915)
#298p [Owner Launch for St. Y. Wayfarer] (1915)
#330p [Launch for U.S. Navy] (1918)
#331p [Launch for #725s Resolute] (1918, Extant)
#332p [Owner Launch for #377p Ara] (1918)
#333p [Crew Launch for #377p Ara] (1918)
#334p [Power Launch] (1918, Extant)
#342p [Stock Launch] (1918)
#343p [Stock Launch] (1918)
#344p [Stock Launch] (1918)
#345p [Stock Launch] (1918)
#367p [Launch for St. Y. Corsair III] (1919)
#381p [Launch for St. Y. Corsair III] (1925, Extant)
#395p [Owner Launch for St. Y. Viking] (1935)
#409p [Launch for St. Y. Corsair IV] (1939, Extant)

Original text on model:
"25' launch for INTREPID scale 1/12 1900" (Source: Original handwritten annotation on model. Undated.)

Model Description:
"25'1" loa gasoline launch of 1900 for the yacht Intrepid." (Source: Bray, Maynard. 2004.)

Model Comment:
"Reference to model 419 was added by CvdL because #333p was part of a group of five identical launches (#330p - #334p) which are all believed to be based on model 419 because plan 2-95 for #330p Tender for US Navy notes that that boat was to use 'moulds as for #283p (changed from #276p)' and #276p was the launch for which model 419 was originally made." (Source: van der Linde, Claas. October 29, 2014.)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.


Documents

Archival Documents

"[Item Description:] Hand-written table titled 'Casting List for Gov. Pontoons', which apparently is a reference to #191801es Seaplane Barge No. 17 (Org. No. #331p), #191802es Seaplane Barge No. 18 (Org. No. #332p), #191803es Seaplane Barge No. 19 (Org. No. #333p), #191804es Seaplane Barge No. 20 (Org. No. #334p), #191805es Seaplane Barge No. 21 (Org. No. #335p), #191806es Seaplane Barge No. 22 (Org. No. #336p), #191807es Seaplane Barge No. 23 (Org. No. #337p), #191808es Seaplane Barge No. 24 (Org. No. #338p), #191809es Seaplane Barge No. 25 (Org. No. #339p), and #191810es Seaplane Barge No. 26 (Org. No. #340p). Showing pattern names, pattern numbers and drawing numbers." (Source: MIT Museum, Hart Nautical Collections, Haffenreffer-Herreshoff Collection Item HH.6.097. Table. Box HAFH.6.3B, Folder Administrative - Notes. No date (ca1918 ?).)


"[Item Transcription:] [Handwritten draft, marked 'rough copy':] Mr. Swan says he has been talking with you over the wire and that Adm[ira]l Taylor will not approve of our plans for a chaser [#191802ep Unbuilt 200ft Submarine Chaser], until we send him the lines and a model is tried.
The lines (which is simply a copy of the lines he has and have already been thoroughly tried out) will be send as soon as traced off on Monday. But with his attitude about this I can see that it is the beginning of trouble we will have all through, and the outerfing[?] of the jealous feeling the Navy Dep. has always had against anything originated here.
We have had one dose of it already this spring with that half dozen Destroyer launches [#330p, #331p, #332p, #333p, #334p] which we built in good faith, and now have five of them on our hands.
If the Navy Department really have faith in our work and will buy this 200ft chaser from your syndicate [next six words crossed out] who will contract for it and who must must have faith us[?] as they would in ordering a Cup Defender, and also the Navy Dept. will aid us in getting material, if necessary --- all right and good!
But if the Navy Dept. is to dictate every step it is no job for the Herreshoff Mfg. Co. to undertake.
We must have a free hand in both design and work, otherwise it would be folly to undertake it.
We have seen nothing of Com. James yet. [Note: See also penciled note by NGH in Offset Booklet HH.4.047 (p. 24) 'June 15, 1998. Lines of Proposed 40ft. Aeroplane Rescue Boat at scale of 1in= 1ft, sent to Mr. Nichols to take to Washington &[?] have a model made from. Frame spaces 12in with one more frame added. Breadths and heights increased 3/2. Estimated displacement 10000'.]" (Source: Herreshoff, N.G. Letter (copy) to (Nichols), George. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MR_12080. Correspondence, Folder 36, formerly 191. 1918-06-01.)


Note: This list of archival documents contains in an unedited form any and all which mention #333p [Crew Launch for #377p Ara] even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.


Images

Supplement

From the 1920 and earlier HMCo Index Cards at the MIT Museum
  • Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.
From the 2000 (ca.) Transcription of the HMCo Construction Record by Vermilya/Bray

Year: 1917
E/P/S: P
No.: 333
OA: 26' 2"
LW: 24' 1"

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

Research Note(s)

"Weight 2700 #." (Source: Herreshoff, N. G. Trials Notebook. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum. Access courtesy Halsey Herreshoff.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.

Note

We are always interested in learning more about this vessel. If you want to discuss it or can share any additional information or images or to discuss a copyright concern, please do not hesitate to send an Email to the link below!
