Herreshoff #191501ep [Power Launch for #772s Mariette]


Particulars

Name: [Power Launch for #772s Mariette]
Type: Power Launch
Designed by: ASdeWH
Contract: 1915-11 ?
Job No.: 8421
Construction: Wood
LOA: 19' 4.5" (5.91m)
Beam: 5' 4" (1.63m)
Displ.: 1,500 lbs (680 kg)
Propulsion: Gasoline, Wisconsin; 4 cyl. Type QM. 3 1/4" x 5" (as per plan 2-78)
Built for: Brown, Jacob Fred.

See also:
#191503es [Sailing Cutter for #772s Mariette] (1915)
#191507es [Dinghy for #772s Mariette] (1915)
#772s Mariette (1916, Extant)

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.


Model

Model #411Model number: 411
Model location: H.M.M. Model Room West Wall Left

Vessels from this model:
12 built, modeled by ASdeWH
#191301ep [Owner Launch for #722s Katoura] (1913)
#191304ep [Power Launch for #719s Vagrant II] (1913)
#191501ep [Power Launch for #772s Mariette] (1915)
#191904ep [Power Launch for #827s Ohonkara] (1919)
#192001ep [Power Launch for #374p Alert] (1920)
#192002ep [Power Launch for #376p Esloma] (1920)
#284p [Power Launch for #719s Vagrant II] (1912)
#285p Bubble (1912)
#293p [Power Launch for #215p Roamer] (1913)
#295p [Power Launch for St. Y. Tarantula] (1914)
#296p [Launch for H. M. Co.] (1914)
#302p [Owner Launch for #722s Katoura] (1916)

Original text on model:
"BUBBLE (285) Scale 3/4" = 1' Dec. 1911 by Sidney KATOURA's launch 1913-14 (burned)
KATOURA's second launch 1916" (Source: Original handwritten annotation on model. Undated.)

Model Description:
"25'10" loa Bubble, gasoline launch of 1911." (Source: Bray, Maynard. 2004.)

Model Comment:
"Reference to model no. 411 was added by CvdL because this vessel was also described on plan 2-78 (power launch for #719s Vagrant) which was built from this model." (Source: van der Linde, Claas. October 27, 2014.)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.


Offsets

Offset booklet number(s): HH.4.040

Offset booklet contents:
#284, launch for Schooner #719 [Vagrant]([internal] job no. 7003).


Offset Booklet(s) in Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. (Restricted access --- see curator.)
Note: "Reference to offset booklet HH.4.040 was added by CvdL because this boat was built from the same construction plan as other sisterships that were specifically mentioned in it." (Source: van der Linde, Claas. April 24, 2021.)

Drawings

Main drawing Dwg 002-078 (HH.5.00080) Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   Herreshoff #191501ep [Power Launch for #772s Mariette] are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
  1. Dwg 002-078 (HH.5.00080): Construction Dwg > Gasoline Launch 19'-6" x 5'-4" for # 719 (1913-04-28)
Source: Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. Haffenreffer-Herreshoff Collection. Together with: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997. Together with: Numerous additions and corrections by Claas van der Linde.
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.

Images

Supplement

Research Note(s)

"Job # 8421 [ca. November 1915].
Launch for #772 MARIETTE (as in red)
Motor, Wisconsin 4cyl, Type Q.M. 3 1/4 x 5in
All seats put 3in lower and steering seat 4in aft.
Bulkjead with removable door on [frame station] 18.
Deck inside of coaming in engine space cut away.
Cockpit extended aft to after bulkhead." (Source: Herreshoff Manufacturing Company. [Note.] # 7003 Construction Plan 2-78 (HH.5.0080). April 28, 1913.)

"This entry was added to the HCR as per note on Mariette's construction plan 1-57 as well as a note on plan 2-78 (power launch for #719s Vagrant) which indicates that a power launch for Mariette with the same dimensions was built as job no. 8421 (estimated date November 1915)." (Source: van der Linde, Claas. October 26, 2014.)

"This vessel's contract date was estimated from the date Mariette's two other dinghies were contracted for. Plan 2-78 from which this boat was built was drawn 1913-03. #772s Mariette (for which this vessel was built) was contracted for 1915-10-07. Plan 2-78 (power launch for #719s Vagrant) shows this vessel as job no. 8421 which interpolates to an estimated date of November 1915, thus confirming the previous estimate. This boat's contract or building date is about 1 month after #772s Mariette was contracted for." (Source: van der Linde, Claas. October 27, 2014.)

"Weight with equipment 1500lbs." (Source: Herreshoff Manufacturing Company. [Note.] # 7003 Construction Plan 2-78 (HH.5.0080). April 28, 1913.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
