Herreshoff #188804es [Yawlboat for #151p Ballymena]


Particulars

Name: [Yawlboat for #151p Ballymena]
Type: Four-Oared Yawlboat
Designed by: NGH
Contract: 1888-6 ?
Construction: Wood
LOA: 21' 0" (6.40m)
Beam: 4' 10" (1.47m)
Built for: Brown, George S.

See also:
#188803es [Yawlboat for #151p Ballymena] (1888)
#151p Ballymena (1888)
#221p [Electric Launch for #151p Bellemere ex-Ballymena] (1902)

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.


Model

Model #15Model number: 15
Model location: H.M.M. Model Room East Wall

Vessels from this model:
5 built, modeled by NGH
#190301ep Neon (1903)
#188803es [Yawlboat for #151p Ballymena] (1888)
#188804es [Yawlboat for #151p Ballymena] (1888)
#192503es [Yawlboat for Vanitie] (1925)
#260p [Launch for G. M. Altham] (1907)

Original text on model:
"4 oared boat #151 BALLYMENA 1888 \ NEON 1903" (Source: Original handwritten annotation on model. Undated.)

Model Description:
"#151 Gig for steam yacht Ballymena of 1888. Also power launch Neon." (Source: Bray, Maynard. 2004.)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.


Offsets

Offset booklet number(s): HH.4.020.2

Offset booklet contents:
#151p (yacht tender), #190301ep Neon.


Offset Booklet(s) in Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. (Restricted access --- see curator.)
Note: "Reference to Offset Booklet HH.4.20.2 was added by CvdL as per entry in offset booklet: 'May 21st 1888. / Small boats -Str. no. 151 / Neon, 1903'." (Source: van der Linde, Claas. November 14, 2016.)

Drawings

Main drawing Dwg 028-004 [075-005] (HH.5.02000) Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   Herreshoff #188804es [Yawlboat for #151p Ballymena] are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
  1. Dwg 028-004 [075-005] (HH.5.02000); Construction Dwg > 21 ft. Yawl Boat for Steamer 151 (1888-06-05)
Source: Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. Haffenreffer-Herreshoff Collection. Together with: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997. Together with: Numerous additions and corrections by Claas van der Linde.
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.

Documents

Nathanael G. Herreshoff

"May 21, 1888.
Small boats for st[eame]r No. 151 [#151p Ballymena].
Model 21" x 4 3/4" wide x 2" deep. Scale 1/12th.
Deduct in making frames for planking 3/8"
... for timbers 3/4"
[Total to be decucted] 1 1/8".
Frames spaced 12" for 24ft boat
Frames spaced 11 1/2" for 23ft boat
Frames spaced 11" for 22ft boat
Frames spaced 10 1/2" for 21ft boat
Frames spaced 10" for 20ft boat." (Source: Herreshoff, N.G. [Penciled note in Offset Booklet HH.4.020.2.] Haffenreffer-Herreshoff Collection, MIT Museum, Cambridge, MA.)


Images

Supplement

Research Note(s)

"Yawlboat for the steel steam yacht Ballymena #151p. Two of these boats were built, as per a note in Offset Booklet HH.4.020.2." (Source: van der Linde, Claas. March 22, 2021.)

"This vessel's contract date was estimated from the original plan date. Drawing 028-004 [075-005] from which this boat was built was drawn 1888-06. #151p Ballymena (for which this vessel was built) was finished 1888-10-06. This boat's contract or building date is about 4 months before #151p Ballymena was launched." (Source: van der Linde, Claas. October 26, 2009.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
