HMCo #122p Lucile [Lucille II]

"[1887-10-20] Thu 20: Hauled up Lucile #122p at Popasquash.
[1889-03-19] Tue 19: ... Took Ladoga [#123p] & Lucile [probably #122p and not #110p] from Cove to wharf.
[1890-06-05] Thu 5: Launched Dolphin and Lucille [probably #122p and not #110p] from Pop[asquash] ways. ...
[1890-12-16] Tue 16: Hauled out Lucile [probably #122p and not #110p], Daisy [#133p], and Katydid [#165p]. ..." (Source: Herreshoff, Nathanael G. Diary, 1887 to 1890. Manuscript (excerpts). Herreshoff Marine Museum Collection.)

"St[eame]r no. 122. Flush deck. Length 90ft. Breadth 11f 4". Depth 7f 2".
Measurements f[ro]m model originally made for str no. 89 [#89p Orienta] after raising to depth for flush deck, and made with scale 1/16th frame spaces 15/16th of an inch - 67 + frame spaces.
Dist. f[ro]m center to center of frames 16".
Thickness of stem and keel 5 3/8 inches.
Thickness of planking 1 3/8" and 1 1/8" and 1".
Thickness of timbers 2" square (of 2 x 1 7/8")
Deduct for planking & timers 3 1/4 inches.
For fore and aft measurements use rule 16" long, divided into 15 parts." (Source: Herreshoff, N.G. [Penciled note in Offset Booklet HH.4.015.] Undated, ca. 1885. Haffenreffer-Herreshoff Collection, MIT Museum, Cambridge, MA.)

"Mean speed 12.10kn = 13.94m[iles] [during first trial run] [and, during second trial run] Mean speed 14.0kn = 16.15[miles].." (Source: Herreshoff, N.G. Note in handwritten experiments and trials booklet titled 'Herreshoff Mfg. Co. Experiments 1884 to 1889' dated May 21, 1885. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum.)

"The Herreshoff Company, at Bristol, R. I., are building ... a steam yacht for Mr. Charles Kellogg, of Athens, N. Y. She is to be 90 ft. over all. 85 ft. water-line, 11 ft. 6 in. beam, 7 ft. 6 in. deep, and 4 ft. 6 in. draught. She is to have a compound engine, 8 and 14 in. cylinder, and 14 in. stroke, supplied by a vertical coil boiler, 69 by 69 in." (Source: Anon. "New Yachts for March." The Spirit of The Times, April 11, 1885, p. 318.)

"Lucile, steam yacht, of Bristol.
Built at Bristol, RI, by Herreshoff Manufacturing Co., 1885.
24.11 tons; 84.6 ft. x 11.5 ft. x 7.9 ft. [Register length x breadth x depth.]
No mast, plain head, round stern.
Surveyed and measured, April 4, 1885." (Source: U.S. Customs Department, Bristol, R.I. Custom House Record Book, 1870s to 1904 (Collection of the Herreshoff Marine Museum), s.v. Lucile.)

"The steam yacht Lucille, 90 feet in length, built for Charles Kellogg, of Athens, Pa., was launched from the Herreshoff Co's shop Wednesday [April 8, 1885]. The keel of another vessel, 97 feet in length was laid immediately after the launching of the above." (Source: Anon. "Local Affairs." Bristol Phoenix, April 11, 1885, p. 2.)

"... No. 122, not yet named [and to be named Lucile], is building for Mr. Chas. Kellogg, of Athens, Pa., a fast cruising yacht for lake and coast work, designed to accommodate the owner's family. She is 90ft. long, 11ft. 6in. beam, 4ft. 6in. draft, engines (105 H. P.) 8 and 14x14in., with screw of 45in., and a guaranteed speed of 16 miles. At present she will carry no canvas, but will ultimately be schooner-rigged, with two masts." (Source: Anon. (W. P. Stephens). "The Herreshoff Works at Bristol." Forest and Stream, April 16, 1885, p. 236-237.)

"[Abstract of register or enrollment. Pos. 560:]
Lucile, steam yacht, of Bristol.
Built at Bristol, 1885.
24.11 tons; 47 ft. x 10.3 ft. x 4.2 ft [sic, tonnage is correct but dimensions appear to be too small] [Register length x breadth x depth.]
No specifications shown.
Enr[olled] and Lic[ensed] ([as] yacht) May 9, 1885. Owner: Herreshoff Manufacturing Company of Bristol. Master: Nathaniel Y. Herreshoff. ([Record at:] C[ustom] H[ouse, Providence]).
Enr[olled] and Lic[ensed] (temporary) ([as] yacht) May 24, 1886 (change of hailing port - New York). Owner: Charles Kellogg of New York, N.Y. Master: Charles Kellogg. ([Record at:] C[ustom] H[ouse, Providence]).
Enr[olled] and Lic[ensed] ([as] yacht) June 6, 1887 (change of hailing port - Bristol). Owner: Herreshoff Manufacturing Company of Bristol. Master: John B. Herreshoff.
Surrendered [license] July 1, 1887 at Plymouth. ([Record at:] C[ustom] H[ouse, Providence])." (Source: Survey of Federal Archives, Work Projects Administration. Ships Documents of Rhode Island. Bristol. Ship Registers and Enrollments of the Port of Bristol - Warren Rhode Island, 1941, s.v. Lucile.)

"... Lucille, Herreshoff No. 122, was lately tried on Narragansett Bay, and made 17 miles. Her length as already given is 90ft. ..." (Source: Anon. "Yachting Notes." Forest & Stream, May 14, 1885, p. 319.)

"... THE steam yacht Lucille, built by the Herreshoffs, for Mr. Charles Kellogg, of Athens. N. Y., made her trial trip in Narragansett Bay, May 4 [1885], and, over the measured mile, went at the rate of 17 miles per hour. She is 90 ft. long, 11 ft. 6 in. beam, 7 ft. 6 in. deep, and draws 4 ft. 6 in. ..." (Source: Anon. "Yachting." Spirit of the Times, May 16, 1885, p. 480.)

"The Herreshoff yacht Lucile, No. 122, left Bristol on May 23 [1883] and made the run in 12h. 53m., from the builders' yard to Poillon Bros.' yard in Brooklyn, an average of 14 miles. From Brooklyn she continued to Sing Sing where she was delivered to her owner, Mr. Chas Kellogg, of Athens, Pa, who will take her to Chesapeake Bay for some cruising. Messrs. Herreshoff have taken in part payment [for the yacht Lucile #122p] the yacht No. 110 built for Mr. Kellogg last season, as she was too small for his use. This yacht, 69ft. long, has a record of over 19 miles on a measured course. She is fully described in our advertising columns. ..." (Source: Anon. "Lucile." Forest and Stream, May 28, 1885, p. 359.)

"Editor Forest and Stream:
The steam yacht Lucille, Mr. Chas. Kellog, owner, left her anchorage at Seventy-second street, North River, Wednesday, June 10 [1885], with a few guests aboard, to witness the race expected between the passenger steamer Mary Powell and the Herreshoff's new steam yacht Stiletto, or No. 118. The Lucille belongs to the same family as the Stiletto, and was launched too late this spring to get into Olsen's List. She was built at Bristol by the Herreshoffs, and launched in April. She is 90ft. long, 11 1/2ft. beam, 4 1/2ft. draft, of 24.11 tons N. M., has two masts, and is supplied with Herreshoff's improved square boilers, maximum steam pressure 140 pounds. The engines are compound, two cylinders, 8x14 and 14x14, of 120 ind. H. P. The Lucille has the fine lines and sharp bow of these builders, flush deck and ample headroom below. The hull is divided in five water-tight compartments by iron bulkheads, with roomy cabin, staterooms, etc., furnished in mahogany. She is a most comfortable cruising yacht and speedy, having shown upwards of seventeen miles without crowding. ... DORSAL FIN." (Source: Anon. (Dorsal Fin.) [No title. (Letter to the Editor)] Forest and Stream, June 18, 1885, p. 418.)

"THE steam yacht Lucille, Mr. Chas. Kellogg's new Herreshoff No. 122, left Seventy second street, North River, eastward bound, for a cruise of two weeks on June 14 [1885].
A beautiful morning of bright sunshine which tempered a rather cool breeze from the southwest, made sitting on deck and watching the other craft passing- very pleasant. Vessels of all kinds covered the water, the excursion steamers and barges, with flags and streamers flying, were lying at the various piers, while pleasure seekers were crowding on board. The Battery Park was filling up with Sunday morning loungers as we passed, and on the seats the regular park tulips looked as comfortable and permanent as usual.
On past the Barge Office and up East River we steamed, and under the great bridge --- which looked like some mighty cobweb stretched across the sky-dodging ferryboats and craft of all sizes crossing and recrossing our course, until Blackwell's Island was passed: then turning into the eastern channel of Hell Gate, we threaded the eddies and currents or that dangerous locality, and out upon the broad, placid bosom of the Sound.
... We did not land at Newport, but kept on up the bay, and at 12:30 P. M. [on June 15, 1885] reached Bristol Harbor, and made fast to the Herreshoffs Company's pier. Some slight changes in the fittings on board being deemed desirable, while the workmen were engaged upon it we passed the time pleasantly in inspecting the new steam yacht Ladoga, which had been launched a few hours before our arrival, and in looking over again the famous yacht Stiletto, which lay at her moorings near by. ... THE MASTER'S MATE." (Source: Anon. ("The Master's Mate.") "Cruise Of The Lucille." Forest and Stream, July 9, 1885, p. 479-480.)

"Mr. Chas. Kellogg's steam yacht Lucile left her anchorage July 10 [1885] for a cruise in the St. Lawrence and lakes. She will go to Albany, and after lowering masts, etc. proceed, via Erie Canal and Lake Cayuga, to Ithaca, where she will take owner's family on board. Thence to Oswego and the lake to the Thousand Islands for an extended cruise." (Source: Anon. "Lucille." Forest and Stream, July 16, 1885, p. 500.)

"BRISTOL, R. I. --- At the yard of the Herreshoff Manufacturing Company are now laid up the Lucille No. 1 [#110p], Polly [#120p], Ossabaw [#101p], Albicore, Stiletto [#118p], Ladoga [#123p] and Lucille No. 2 [#122p]. The latter will have a new triple expansion engine. The Albicore, Com. Forbes, is up for general repairs." (Source: Anon. "Bristol." Forest and Stream, December 24, 1885, p. 436.)

"The following is a list of the steam yachts built by the Herreshoff Manufacturing Company of Bristol, R.I: ... Lucille, 90 feet by 11 1/2 feet, engine 8 inches and 14 inches by 14 inches; boiler, Herreshoff safety, 67 inches square; built 1885 for Charles Kellogg, Athens, Penn.; speed, 17 miles. ..." (Source: Jaffray, Edward S. "American Steam Yachting." Outing, April 1886, p. 23-25.)

"LUCILLE No. 2, steam yacht, has been sold by Herreshoff Bros, to G. W. Wright, of Duxbury, Mass." (Source: Anon. "Lucille." Forest and Stream, July 14, 1887, p. 544.)

"Lincoln C. Cummings, recently elected Commodore of the Portland Yacht Club, has purchased the Herreshoff flush-deck steam yacht Lucille from Henry R. Cramp or Boston. The Lucille has been fitted out in splendid style and will be the flagship of the Portland Yacht Club. [Note: Apparently a reference to Lucile #122p rather than Lucile #110p which was owned by Geo. W. Vanderbilt during the time in question.]" (Source: Anon. "Busy With The Yachts." New York Times, March 17, 1900, p. 8.)

"No. 6470 --- Beautifully modelled Herreshoff flush-deck steam yacht; 90 ft. o. a.; 12 ft. beam; outside lead ballast; mahogany dining room; pilot house of 14 feet; handsomely finished and furnished; galley under, with large cold blast refrigerator and buffet accommodations; saloon, 14 feet, paneled in mahogany and upholstered in velvet; French plate mirrors, wine and clothes lockers; two large and elegant staterooms; also lavatory connecting with saloon; has full suit sails, awnings, and boats; new Roberts safety boiler; Herreshoff triple expansion engines, cylinders, 7 1/2 inches x 12 inches x 19 inches and 10-inch stroke; very economical, powerful seaboat; speed, 15 miles natural draught; in perfect order, ready for sea. Address, L. C. Cummings, 24 Plum St., Porland [sic], Me." [Lucile No. 2 is not explicity identified in this ad but the vessel's dimensions, engine particulars, new Roberts Boiler, as well as the name of her seller, L. C. Cummings, identify her as #122p Lucille No. 2.] (Source: Rudder, March 1901, p. 149.)

"No. 20562 --- For Sale --- Attractive Herreshoff steam yacht, proper size for canal work; length o. a., 90 ft., breadth 12 ft., draught 5 ft. 6 in.; built 1885; has triple expansion engine, 7 1/2 inches, 12 inches and 19 inches, by 10 1/2 inch stroke; 250-h.p. Roberts boiler, new 1899; bunker capacity 8 tons; coal consumption 1 ton in 12 hours; speed 14 miles natural [draft], forced [draft] 17 1/2 miles; has flush deck with deck dining saloon forward in mahogany house; aft of deck house large bridge of mahogany, aft has large saloon, one double and one single stateroom, new deck in 1902; entirely re-furnished last year; complete inventory; everything in best of condition; owner desires cruising schooner. For full information, apply to Cox & Stevens, 68 Broad St., New York City. [Though not explicitly identified as Lucile, she can be identified, because she is the only 1885-Herreshoff-built steam yacht with a triple expansion engine of the dimensions provided.]" (Source: Rudder, March 1906, p. 240.)

"[Another for sale advertisement, this time by Henry Gielow but using the same photo.]" (Source: Anon. "For Sale". Rudder, March 1907, p. 265.)

"[Item Description:] Casting Book # 4, steamers #40p, #54p, #57p, #63p, #67p, #70p, #79p, #89p, #92p, #99p, #100p, #101p, #102p, #103p, #104p, #105p, #106p, #107p, #108p, #109p, #110p, #111p, #112p, #113p, #114p, #115p, #116p, #117p, #118p, #119p, #120p, #121p, #122p, #123p, #124p, #125p, #126p, #127p, #128p, #129p, #130p, #131p, #132p, #133p, #134p, #135p, #136p, #137p, #138p, #139p, #140p, #141p, #142p, #143p, #144p, #145p, #146p, #147p [castings by hull number; front page shows summary size and engine and boiler data for steamers 99 thru 146 as well as repair data for steamers #40p, #54p, #57p, #63p, #67p, #70p, #79p, #89p, #92p, #118p, and #128p]. Undated, vessels mentioned were built between 1878 and 1887. Dates mentioned for repairs range from 1885 to 1887. Note considerable informational overlap with Casting Book # 1, which as in this book also contains data for #99p through #116p, although it appears (!) that Book # 4 lists more patterns per boat than Book # 1. Likewise, considerable overlap with Casting Books # 2 and # 3 which also contain data for boats that are also listed in book # 4. It may well be that information in Book # 4 was copied from books # 1, # 2 and 3." (Source: MIT Museum, Hart Nautical Collections, Haffenreffer-Herreshoff Collection Item HH.6.120-07. Castings Book 4. Box HAFH.6.4B, Folder Casting Record Books Vessel Castings Book 4. No date (1878 to 1887).)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓ ㉔ ㉕ ㉖ ㉗ ㉘ ㉙ ㉚ ㉛ ㉜ ㉝ ㉞ ㉟ ㊱ ㊲ ㊳ ㊴ ㊵ ㊶ ㊷ ㊸ ㊹ ㊺ ㊻ ㊼ ㊽ ㊾ ㊿
①

"N/A"

"[Item Description:] Work order notebook [Titled Nathl G. Herreshoff, Esq., Bristol R.I.; 1882-1887, mostly signed by N.G.H., later ones by C.H.K.; material and item orders relating to #400s CONSUELO, #401s ROMP and steamers #89p, #99p, #100p, #101p, #102p, #104p, #105p, #106p, #110p, #111p, #113p, #118p, #119p, #120p, #122p, #123p, #140p, #146p; many orders from the marine store of A. B. Babbitt at Tiverton]." (Source: Herreshoff, N.G. (creator). Work Order Notebook. MIT Museum, Hart Nautical Collections, Haffenreffer-Herreshoff Collection Item HH.6.120-04. Box HAFH.6.4B, Folder Casting Record Books Sketch and Order Book 1882-1887 NGH CHK. 1882 to 1887.)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓ ㉔ ㉕ ㉖ ㉗ ㉘ ㉙ ㉚ ㉛ ㉜ ㉝ ㉞

"N/A"

"[Item Description:] Casting Book # 2, steamers #70p; #79p, #117p, #118p, #119p, #120p, #121p, #122p, #123p, #124p, #125p, #126p, #127p, #128p, #129p, #130p, #131p, #132p, #133p, #134p, #135p, #139p, [castings by hull number]. On last page handwritten note 'Commenced Work on Triple Cond[?] Eng. new one Nov 11/85. H com[?] on Nov 13/85 10 A.M. C.H.K.'. Undated, most vessels mentioned were built between 1885 and 1886. Note considerable informational overlap with Casting Book # 4, which also contains data for all of the boats mentioned in this book, although it may be (!) that Book # 4 lists more patterns per boat than Book # 2." (Source: MIT Museum, Hart Nautical Collections, Haffenreffer-Herreshoff Collection Item HH.6.120-05. Castings Book 2. Box HAFH.6.4B, Folder Casting Record Books Vessel Castings Book 2. No date (1885 to 1886).)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓

"[Item Description:] Penciled side-by-side half-sections and displacement curves. Titled 'LUCILE #122 [#122p]' with note 'Draft to base line 3f. Area water line 520.15sqft. Area [symbol] 20.16sqft. Displacement 949.05cuft [=60739lbs]. Surface of keel 198 1/2. Surface of rudder 16. Surface of hull 679.32'. Curves are labeled 'Wetted surface exclusive of keel 679.32sqft', 'Waterline 520.15sqft' and 'Disp[lacement] curve [?] 949.05cuft = 31tons'. Upside down is another set of superimposed half-sections and curves titled '39ft Launch. St[eame]r 128 [#128p Launch for U.S.S. Chicago]'. On verso is a third set of crossed-out superimposed half-sections and curves for an unidentified design titled '80ft w.l. Prem. [Preliminary?] model 3/8 scale. Before alteration'. The curve is marked '757.4cuft [=48474lbs] = 24.6 tons'. Undated (LUCILE was designed and built in the spring of 1885, the launch for Chicago in the fall of 1885)." (Source: Herreshoff, N. G. (creator). Side-by-side Half-Sections and Displacement Curves. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Acc. 2004.0001.0584. WRDT08, Folder 45. No date (1885-03 ?).)
① ② ③ ④

"[Item Transcription:] [Handwritten (in ink) letter on 'The Herreshoff Manufacturing Co, Established in 1861, Incorporated in 1879, Sole Manufacturers Of The Herreshoff Patent Safety Coil Boiler, Builders of Steam Vessels and Engines' stationery:] Bristol, R.I., June 25th 1885
Dear Daughter Kate,
I rec[eive]d yours of 23rd inst. yesterday. Glad you have been having such cool weather. I miss your daily call. Matters here go on as usual, am busy through the day, and every eve, go to ride with [HMCo secretary] Mr. [J.F.] Smith or [brother] James and sister Carrie. Was sorry you had the nose bleed so much. I think I will take you off on some short trips in the LUCILE [#122p] when you get back here.
You know the sea air has always agreed with us. Mrs. Furman & Daughter leave for home today. The Dunnel children are at Sisters, the two youngest expect to remain all summer.
I expect to hear from you again tonight.
Love from your Papa.
S [Sadie Herreshoff, for JBH]" (Source: Herreshoff, J.B. Letter to Herreshoff, Katherine Kilton. Herreshoff Marine Museum Collection Item LIB_6130. HMM Library Rare Books Room (Various), Folder [no #]. 1885-06-25.)
①

"[Item Transcription:] [Handwritten (in ink) letter on 'The Herreshoff Manufacturing Co, Established in 1861, Incorporated in 1879, Sole Manufacturers Of The Herreshoff Patent Safety Coil Boiler, Builders of Steam Vessels and Engines' stationery:] Bristol, R.I., June 27th 1885
Dear Daughter Kate,
I rec[eive]d your nice letter last eve. Glad you are having so pleasant a time. This cool weather will be nice for you. I passed a quiet Sunday, did not g out. Took a drive last eve. Today expect to go to Newport in the LUCILE [#122p]. ORIENTA [#89p] and AIDA [#92p ex-PERMELIA] still here.
Uncle Cha[rle]s commenced with a few boarders today, his house is completed & furnished. Bro. Francis & family are expected here on Fridays. I am as well as usual. Mrs. Smith will leave 'Prince'[?] with Mrs. Fish, if you do not return before she leaves. Strawberries nearly gone.
Hope to hear from you again soon.
Much love from your Papa, J.B.H.
S [Sadie Herreshoff, for JBH]" (Source: Herreshoff, J.B. Letter to Herreshoff, Katherine Kilton. Herreshoff Marine Museum Collection Item LIB_6150. HMM Library Rare Books Room (Various), Folder [no #]. 1885-06-30.)
①

"[Item Transcription:] [Handwritten (in ink) letter on 'The Herreshoff Manufacturing Co, Established in 1861, Incorporated in 1879, Sole Manufacturers Of The Herreshoff Patent Safety Coil Boiler, Builders of Steam Vessels and Engines' stationery:] Bristol, R.I., Aug[ust] 28th 1885
Dear Daughter Kate,
Your last [letter] rec[eive]d I am much pleased to hear from you as regularly. i was off in the LUCILE [#122p] all day yesterday, run up to Taunton and then over to Greenwich Bay. I expect to be off today to Newport & possibly over to the 'Pier'.
Sister Carrie is still quite poorly and is confined to her room. Mr. Isherwood is here for a few days. Went to drive last eve with Mr. I. & Mrs. Zeller. What cold weather we are having. Your Uncle Nat went off two days ago in the CONSUELO [#400s].
Mrs Smith has returned. We have not started the Shop yet, it seems very quiet.
I think the men are all ready for work next Monday. ope you are well. Wish you could be here to go with me today. Love from your Papa.
S [Sadie Herreshoff, for JBH]" (Source: Herreshoff, J.B. Letter to Herreshoff, Katherine Kilton. Herreshoff Marine Museum Collection Item LIB_6230. HMM Library Rare Books Room (Various), Folder [no #]. 1885-08-28.)
①

"[Item Transcription:] [Handwritten (in ink) letter on 'The Herreshoff Manufacturing Co, Established in 1861, Incorporated in 1879, Sole Manufacturers Of The Herreshoff Patent Safety Coil Boiler, Builders of Steam Vessels and Engines' stationery:] Bristol, R.I., Aug[ust] 29th 1885
Dear Daughter Kate,
Rec[eive]d yours yesterday. Aunt Nellie says the house she stopped at is the 'Mountain House' at Princeton, which is situated at the foot of the mountain.
I was off in LUCILE [#122p] yesterday with a few friends, gone from 10 a.m. till 5.30 P.M. At Newport a short time. Had a fine day. It was perfectly smooth outside.
I expect to be quite busy at the Shop next week, with new work ordered also drawings and estimates for more, my time will be fully taken up. Still I shall miss you and look forward to your return on the 8th. The children go in bathing as usual and will probably continue to two or three wees longer. Uncle Cha[rle]s has 11 boarders. Hope you will continue well. Love from your Papa.
J.B.H.
S [Sadie Herreshoff, for JBH]" (Source: Herreshoff, J.B. Letter to Herreshoff, Katherine Kilton. Herreshoff Marine Museum Collection Item LIB_6240. HMM Library Rare Books Room (Various), Folder [no #]. 1885-08-29.)
①

"[Item Transcription:] Penciled experiments booklet, untitled. Relevant contents:
§2: #122p LUCILE [LUCILLE II] Experiment (1885-11-06)
§3: #122p LUCILE [LUCILLE II] Experiment (1886-05-15)
§7: #122p LUCILE [LUCILLE II] Trial (1886-05-18)
§12: #122p LUCILE [LUCILLE II] Experiment." (Source: Herreshoff, N.G. (creator) and/or Herreshoff Manufacturing Co. (creator). Experiments Booklet. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE07_00060. Folder [no #]. 1885-11 to 1887-05.)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒

"[Item Transcription:] Handwritten (in ink and pencil) experiments and trials booklet titled 'Herreshoff Mfg. Co. Experiments 1884 to 1889. N.G. Herreshoff'. Relevant contents:
§11: #122p LUCILE [LUCILLE II] Trial Runs (1885-04-30 & 1885-05-01)
§14: #122p LUCILE [LUCILLE II] Trial Run (1885-05-21)
§16: #122p LUCILE [LUCILLE II] Trial Run 'New triple expansion engine.' (1886-05-08)
§17: #122p LUCILE [LUCILLE II] Prov. to Bristol & Dock Trial (1886-05-12 & 1886-05-15)
§20: #122p LUCILE [LUCILLE II] Free Run Trial 'Mean speed 13.83knots = 16 miles. … Total HP 164.07.' (1886-05-18)
§27: #122p LUCILE [LUCILLE II] Trial Run (1886-10-22)." (Source: Herreshoff, N.G. (creator). Trials Booklet. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE07_03520. Folder [no #]. 1884-05 to 1890-05.)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓ ㉔ ㉕ ㉖ ㉗ ㉘ ㉙ ㉚ ㉛ ㉜ ㉝ ㉞ ㉟ ㊱ ㊲ ㊳ ㊴ ㊵ ㊶ ㊷ ㊸

"[Item Description:] Penciled steam engine calculations titled 'Calculations for [brother] Francis for proposed dynamo engine. July 7, 1898' and beginning with 'Data. 7 1/2 - 11 1/4 & 19 x 10 1/2 gave following result on … trial (LUCILLE [#122p] 1886) … Indicated HP … Total 164.07 ... Same engine with 280rev, 165lbs ... = 137.5HP but with rev inceased to 407 = 200HP' followed by list of steam engine / revolutions / steam pressure combinations and various resulting horsepower figures." (Source: Herreshoff, N.G. (creator). Penciled Calculations. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE07_01970. Folder [no #]. 1898-07-07.)
①

Note: This list of archival documents contains in an unedited form any and all which mention #122p Lucile [Lucille II] even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

• Lucile (HMCo-made index card)
• Lucile (MIT Museum-made index card)
• Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.

Name: Lucile
Type: Steam
Length: 90'
Owner: Kellogg, Charles

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

• Lucile
• Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.

Name: Lucile
Type: 90' steam
Owner: Charles Kellogg
Year: 1885
Row No.: 386

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

Year: 1885
E/P/S: P
No.: 122
Name: Lucile
OA: 90'

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

"... Str. #122 - 90Ft. long. 7 1/2-12+19x10 1/2 Eng[ine]. L Sq[uare] [Boiler]. ... [The engine is the Lucile's second engine, fitted in May 1886.]" (Source: Anon. [Herreshoff Manufacturing Company. (N. G. Herreshoff?)] No Title. [Handwritten Notes on Outer Cover of Notebook.] No date [ca. late 1880s.] Notebook in the Haffenreffer-Herreshoff Collection, The Francis Russel Hart Nautical Collections, M.I.T. Museum, Cambridge, Mass., obj. no. HH.6.120.)

"Charles H. Kellogg, a mechanical engineer of Athens, Pennsylvania was the co-founder of the Union Bridge Company which became one of the largest builders of bridges in the U.S." (Source: van der Linde, Claas. May 2, 2008.)

"In the absence of better available data displacement was estimated by using the figure for Old Measurement Tons (41.9) from the 1885 Olsen's American Yacht List (New Measurement Tons were reported as 24.11) and converting to lbs by dividing through 2000 (short tons). Note that this figure can only be a rough estimate because register tons as reported in Yacht Registers correlate only loosely with actual displacement figures." (Source: van der Linde, Claas. March 17, 2015.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
