Herreshoff #187801es Duplex (No 6)

"[1878-02-28] Thu 28: [From Cash Account in 1878 NGH diary:] [Paid] A. S. Almy in full for [work on] catamaran hulls no 6 [#187801es Duplex] & 7 [#187805es Zarifa] $60.19.
[1878-08-09] Fri 9: [From Cash Account in 1878 NGH diary:] [Received] R[e]c[eive]d [from] Drexel Morgan Co. Draft on acc[oun]t Catamaran no. 6 [#187801es Duplex] Pds150 equivalent $729 gold. Deposited [at] N. Eagle [Bank] 729 gold." (Source: Herreshoff, Nathanael G. Diary, 1878. Manuscript (excerpts). Herreshoff Marine Museum Collection.)

"Later this year [1878], the catamaran DUPLEX (# 6) was built to be sent to England, but I didn't sail in her." (Source: Herreshoff, N. G. "Some of the Boats I Have Sailed In." Written 1934. In: Pinheiro, Carlton J. (ed.). Recollections and Other Writings by Nathanael G. Herreshoff. Bristol, 1998, p. 52.)

"Mr. N. J. [sic] Herreshoff, of Bristol, R. I., is building a catamaran, of the same size as the Tarantella, for parties in England. Sawyer, of this city, will make her sails, the rig also being the same as that of the Tarantella [#187704es]. The new double-huled catamaran will be 30 feet in length; mainboom 31 feet; jibboom, 27 feet; gaff, 15 feet 6 inches, and the mast, above deck, 29 feet 3 inches." (Source: Anon. "Yachting Notes." New York Herald, May 8, 1878, p. 4.)

"A catamaran boat built for parties in London, England, by the Herreshoffs of this town, has recently greatly astonished the natives in the mother country by her wonderful speed while scudding over the waters of the Thames." (Source: Anon. "Locals." Bristol Phoenix, August 3, 1878, p. 2.)

"[Item Description:] Penciled construction detail plan on smudged and creased paper titled 'N.G. Herreshoff. Bristol. Bolts for arms. Nos. 2 [#187703es JOHN GILPIN (No 2)] - 3 [#187705es TEASER (No 3)] - 4 [#187701es ARION (No 4)] - 5 [#187704es TARANTELLA (No 5)] - 6 [#187801es DUPLEX (No 6)] - 7 [#187805es ZARIFA (No 7)] - Hunkers[?] - 8 [#187903es LODOLA (No 8)]'. With notes '8 - 5/8in bolts (4 - 12 3/4in long, 4 - 15 1/4in long' and 'bolts bent to this angle' and 'short ones straight. All drilled for 7/32in bolts' and '1/4in for #1232' [indicating that this plan was also used in 1933 to build AMARYLLIS II]. On verso more unidentified penciled sketches and calculations. Undated (1877, with additions in 1878, 1879 and 1933)." (Source: Herreshoff, N.G. (creator). Penciled Detail Plan. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item WRDT03_00120. Folder [no #]. No date (between 1877-04 and 1877-07 with additions in 1878, 1879 and 1933).)
① ②

"[Item Description:] Penciled construction detail plan on smudged and creased paper titled 'Centreboard hanging for TARANTELLA. [In blue pencil:] Nos. 2 [#187703es JOHN GILPIN (No 2)] - 3 [#187705es TEASER (No 3)] - 4 [#187701es ARION (No 4)] - 5 [#187704es TARANTELLA (No 5)] - [in red pencil:] 6 [#187801es DUPLEX (No 6)] - 7 [#187805es ZARIFA (No 7)]'. With burnt hole --- probably when the plan came too close to the forge when making these parts. Undated (1877, with additions in 1878)." (Source: Herreshoff, N.G. (creator). Penciled Detail Plan. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item WRDT03_00150. Folder [no #]. No date (between 1877-04 and 1877-07 with additions in 1878).)
①

"[Item Description:] Penciled construction detail plan on smudged and creased paper titled 'Tillerstick TARANTELLA [#187704es]'. With notes 'Hickory tiller' and '[in blue pencil:] # 2 [#187703es JOHN GILPIN (No 2)] - 3 [#187705es TEASER (No 3)] - 4 [#187701es ARION (No 4)] - 5 [#187704es TARANTELLA (No 5)] - [In red pencil:] 6 [#187801es DUPLEX (No 6)] - 7 [#187805es ZARIFA (No 7)] - 8 [#187903es LODOLA (No 8)]'. With further notes in red pencil '15in long for # 8 [LODOLA]' and '15in for # 8. The two made together 120deg apart'." (Source: Herreshoff, N.G. (creator). Penciled Detail Plan. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item WRDT03_00190. Folder [no #]. No date (between 1877-04 and 1877-07 with additions in 1878 and 1879).)
①

"[Item Description:] Penciled construction detail plan on smudged and creased paper titled 'TARANTELLA [#187704es]. Ap[ril] 1877'. With notes 'Mast' and 'Back bone. Spruce 2in x 4in' and 'Iron 2in wide 1/4in thick 15in long' and 'One of this to be made into A' and '[in blue pencil:] # 2 [#187703es JOHN GILPIN (No 2)] - 3 [#187705es TEASER (No 3)] - 4 [#187701es ARION (No 4)] - 5 [#187704es TARANTELLA (No 5)] - [In red pencil:] 6 [#187801es DUPLEX (No 6)] - 7 [#187805es ZARIFA (No 7)] - 8 [#187903es LODOLA (No 8)]'. With further notes in red pencil 'Without eyes and strops for # 8 [LODOLA]'." (Source: Herreshoff, N.G. (creator). Penciled Detail Plan. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item WRDT03_00250. Folder [no #]. 1877-04 (with additions in 1878 and 1879).)
①

"[Item Description:] Penciled construction detail plan on smudged and creased paper titled 'Mast. TARANTELLA [#187704es]. Apr[il] 1877. Mast heel step'. With note '[In blue pencil:] Nos. 2 [#187703es JOHN GILPIN (No 2)] - 3 [#187705es TEASER (No 3)] - 4 [#187701es ARION (No 4)] - 5 [#187704es TARANTELLA (No 5)] - [In red pencil:] 6 [#187801es DUPLEX (No 6)] - 7 [#187805es ZARIFA (No 7)] - [In pencil:] Hunkers[?] [In red and black pencil:] - 8 [#187903es LODOLA (No 8)]'. With further notes in pencil ''3/8in steel. 7/16 iron. 1/2 for nos 6 and 7 [and] 8]' and Bobstay' and 'One of this' and 'Norway iron'. With a burned hole which looks like a forged part was held too close to the drawing to see if the correct angle had been forged. " (Source: Herreshoff, N.G. (creator). Penciled Detail Plan. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item WRDT03_00170. Folder [no #]. 1877-04 ( with additions in 1878 and 1879).)
①

"[Item Description:] Penciled construction detail plan on smudged, rolled and creased paper titled 'stem and sternpost. Catamarans Nos. 6 [#187801es DUPLEX] and 7 [#187805es ZARIFA]. 1878'. Part of a roll of seven 1870s catamaran drawings on very brittle brown paper that was too fragile to unroll and inspect." (Source: Herreshoff, N.G.. (creator). Penciled Drawing. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item WRDT03_00086. Folder [no #]. 1878 (before 1877-06).)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧

"[Item Description:] Penciled construction detail plan on brown paper titled 'Amidships joint. Catamarans nos. 2 [#187703es JOHN GILPIN (No 2)] - 3 [#187705es TEASER (No 3)] - 4 [#187701es ARION (No 4)] - 5 [#187704es TARANTELLA (No 5)] in 1877 - 6 [#187801es DUPLEX (No 6)] - 7 [#187805es ZARIFA (No 7)] - Hunkers[?] in 1878 - 8 [#187903es LODOLA (No 8)] [in] 1879'. (Undated, filed with other plans from 1877 for TARANTELLA, but style and condition of this plan plus reference to modern ball joint pattern 12252 from August 1933 indicate that NGH created this plan in 1933 for #1232s AMARYLLIS 2)." (Source: Herreshoff, N.G. (creator). Penciled Detail Plan. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item WRDT03_00200. Folder [no #]. No date (1933-08 ?).)
①

Note: This list of archival documents contains in an unedited form any and all which mention #187801es Duplex (No 6) even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

"Exported to England." (Source: van der Linde, Claas. May 2, 2008.)
