HMCo #294p [Tender for St. Y. Noma]

"[1914-04-10] Fri 10: Very fine & cool. Ice formed. Temp[erature in] AM [is] 32deg. NW to SW [wind]. Nomahal [sic, i.e. probably Noma] here for launch built last winter [#294p Tender for Vincent Astor's steam yacht Noma]. Vincent Astor, Geo. Cormack & Bob Emmons here in PM. George & Bob stay over night." (Source: Herreshoff, Nathanael G. Diary, 1914. Manuscript (excerpts). Diary access courtesy of Halsey C. Herreshoff.)

"Feb. 6, 1914
#294
30ft-0in x 7ft-4in Steam launch for Vincent Astor, 3 1/2in x 5in x 8in [bore] x 4 1/2in [stroke] tripple exp[ansion] engine, with kerosine burner under boiler.
She was put overboard at about 9 a.m.. Steam up about 10 a.m. after a little trouble with leaky valves, and stiff pumps. Made several runs over the Poppasquash Course with four on board including Mr. McAustin (Chef Engineer of NOMA) and a man from Tams Lemoine and Crane.
Could make the safety valve blow with throttle wide open giving a speed of about 11.7 mi[les] per h[ou]r. It was necessary to use the jet when running above about 10 mi. per hr. in order to prevent smoking.
5 gallons of kerosine ran her just about 1 hour without the jet and running between 9 and 10 miles per hour.
She was hauled out again at about 2 p.m.
Steam can be raised in about 10 min[utes] from time of lighting match." (Source: Herreshoff, N. G. (?) Handwritten note in Experiments Booklet '1911 Trial Trips and Experiments' under date of February 6, 1915. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum.)

"... No. 294 [#294p] - 1914. 30ft Steam Lauch, Oil burning for V. Astor. 2423.49 [Time & Materials] + 33 1/3 [% Shop Overhead] x 50% [Profit Margin] = [$]4845.48. [Time & Mat.:] 2423.49. [Contract Price:] 4875.00 ..." (Source: Herreshoff, N.G. Penciled untitled calculations, apparently made to determine appropriate profit margins for future cost estimates, after the death of his brother J.B. Herreshoff. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum. Undated, between 1915 (when #313p, the latest boat on this list, was built) and 1919 (when #367p CORSAIR, the first launch not on this list, was built and a price for her had to be determined).)

"... The power dinghy built for Vincent Astor's steam yacht Noma was the first boat launched at Herreshoff's this year. After a trial, when the little craft showed two knots in excess or the contract, she was shipped to New York. The only object showing above the boat's coaming is the brass smoke-stack. ..." (Source: Anon. "Notes from the Week's Log." Boston Globe, February 15, 1914, p. 39.)

"... Mr. Vincent Astor has purchased from the Herreshoff Mfg. Co. a new 30-foot oil-burning launch, which he is going to use as a tender for his steam yacht Noma. ...[It is unclear if this is a reference to #294p Tender for St. Y. Noma or to another Herreshoff launch that was sold to Astor after #294 had been built.]" (Source: Anon. "Some Recent Yacht Sales." Yachting, April 1914, p. 239.)

"[Item Transcription:] [Penciled calculations, apparently made by NGH to determine appropriate profit margins for future cost estimates, after the death of JBH:]
No. 313 [#313p] - 1915. 26ft Steam Lauch for CAROLA. 2255.93 [Time & Materials] + 33 1/3 [% Shop Overhead] x 50% [Profit Margin] = [$]4511.86. [Time & Mat.:] 2255.93. [Contract Price:] 4500.00
No. 294 [#294p] - 1914. 30ft Steam Lauch, Oil burning for V. Astor. 2423.49 [Time & Materials] + 33 1/3 [% Shop Overhead] x 50% [Profit Margin] = [$]4845.48. [Time & Mat.:] 2423.49. [Contract Price:] 4875.00
No. 274 [#274p] - 1910. 27ft Steam Lauch for Bath Iron Works. 2485.64 [Time & Materials] + 33 1/3 [% Shop Overhead] x 30% [Profit Margin] = [$]4308.45. [Time & Mat.:] 2485.64. [Contract Price:] 4300.00
No. 270 [#270p] - 1909. 27 1/2ft Steam Lauch for H.A.C. Taylor. 2293.59 [Time & Materials] + 33 1/3 [% Shop Overhead] x 40% [Profit Margin] = [$]4271.37. [Time & Mat.:] 2293.59. [Contract Price:] 4250.00
No. 298 [#298p] - 1914. 32ft Motor Launch for WAYFARER. Premier Motor. 3045.99 [Time & Materials] + 33 1/3 [% Shop Overhead] x 30% [Profit Margin] = [$]5257.72. [Time & Mat.:] 3045.99. [Contract Price:] 5250.00
No. 297 [#297p] - 1914. 30ft Motor Launch for WAYFARER. Stirling Motor. 2327.49 [Time & Materials] + 33 1/3 [% Shop Overhead] x 37% [Profit Margin] = [$]4251.54. [Time & Mat.:] 2327.49. [Contract Price:] 4250.00
No. 282 [#282p] - 1911. 35ft Motor Launch. 45/65 Sterling. CORSAIR. 3514.72 [Time & Materials] + 33 1/3 [% Shop Overhead] x 44% [Profit Margin] = [$]6748.26. [Time & Mat.:] 3514.72. [Contract Price:] 6750.00
No. 277 [#277p] - 1911. 30ft Motor Launch ISABEL (for LCL [L.C. Ledyard] by J.B. Webb). 2573.00 [Time & Materials] + 33 1/3 [% Shop Overhead] x 75% [Profit Margin] = [$]5903.67. [Time & Mat.:] 2573.00. [Contract Price:] 6000.00
No. 273 [#273p] - 1910. 30ft Motor Launch for M.F. Plant (Premier). 2576.78 [Time & Materials] + 33 1/3 [% Shop Overhead] x 60% [Profit Margin] = [$]5497.14. [Time & Mat.:] 2576.78. [Contract Price:] 5500.00
No. 278 [#278p] - 1910. 35ft Motor (Ideal) stock boat sold to WESTWARD. 2114.46 [Time & Materials] + 33 1/3 [% Shop Overhead] x 40% [Profit Margin] = [$]3947.00. [Time & Mat.:] 2114.46. [Contract Price:] 4000.00
No. 265 [#265p] - 1908. 34ft Motor (Premier) [for] NORTH STAR. 2259.20 [Time & Materials] + 33 1/3 [% Shop Overhead] x 18% [sic, i.e. 6% Profit Margin] = [$]3199.04. [Time & Mat.:] 2259.20. [Contract Price:] 3200.00
No. 283 [#283p] - 1911. 30ft Motor (Premier) [for] ALOHA A.C. James. 2974.84 [Time & Materials] + 33 1/3 [% Shop Overhead] x 45% [Profit Margin] = [$]5751.35. [Time & Mat.:] 2974.84. [Contract Price:] 5750.00
No. 292 [#292p] - 1912. 40ft Motor (8 cyl Sterling) [for] F.L. Dunne. 4630.47 [Time & Materials] + 33 1/3 [% Shop Overhead] x 55% [sic, i.e. 30% Profit Margin] = [$]8019.64. [Time & Mat.:] 4630.47. [Contract Price:] 8000.00
No. 296 [#296p] - 1914. 30ft Motor Launch (Stillson) Stock HMCo inventoried at 3,500. 2185.60 [Time & Materials] + 33 1/3 [% Shop Overhead] x 20% [Profit Margin] = [$]3496.95. [Time & Mat.:] 2185.60
No. 291 [#291p] - 1912. 50ft Motor Launch (2 Sterlings) Admirals Barge USN. 8141.40 [Time & Materials] + 33 1/3 [% Shop Overhead] x 18% [Profit Margin] = [$]12[8]08.57. [Time & Mat.:] 8141.40. [Contract Price:] 12000.00
No. 295 [#295p] - 1914. 19 1/2ft Motor Launch (Model E Sterling) W.K. Vanderbilt. 1240.68 [Time & Materials] + 33 1/3 [% Shop Overhead] x 22% [Profit Margin] = [$]2018.17. [Time & Mat.:] 1240.68. [Contract Price:] 2000.00
[Time & Materials:] 44757.68 [sic, i.e. 44857.68]. [Contract Price:] 80625.00
[p. 2]
[Unreadable]
Time & Material for 15 boats cost 44,757.68
adding 33 1/3% average for shop 14,919.23
makes shop cost 59,676.91
To equal contract price have to add about 35% = 20886.91733
Total 80,563.82. [Undated, between 1915 (when #313p, the latest boat on this list, was built) and 1919 (when #367p CORSAIR, the first launch not on this list, was built and a price for her had to be determined).]" (Source: Herreshoff, N.G. (?) (creator). Cost Estimate. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDED1_00160. Folder [no #]. No date (between 1915 and 1919 ?).)
① ②

"[Item Transcription:] Handwritten (in ink) trials booklet titled '1911. Trial Trips and Experiments'. Relevant contents:
§19: #294p [TENDER FOR ST. Y. NOMA] Trial Run best speed 11.7mph (1914-02-06)." (Source: Herreshoff, N.G. (creator) and Herreshoff, A. Sidney deW. (creator). Trials Booklet. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE07_04280. Folder [no #]. 1911-06 to 1926-05.)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓ ㉔ ㉕ ㉖ ㉗ ㉘ ㉙ ㉚ ㉛ ㉜ ㉝ ㉞ ㉟ ㊱ ㊲ ㊳ ㊴ ㊵ ㊶ ㊷ ㊸ ㊹ ㊺ ㊻ ㊼ ㊽ ㊾ ㊿
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨

Note: This list of archival documents contains in an unedited form any and all which mention #294p [Tender for St. Y. Noma] even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

• Tender for St Y Noma (HMCo-made index card)
• Tender for St Y Noma (MIT Museum-made index card)
• Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.

Name: Norma
Type: Steam
Length: 30'3"
Owner: Astor, Vincent

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

• Tender for steam yacht Noma
• Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.

Name: Norma
Type: 30' 3" steam tender for yacht "Nourmahal"
Owner: Vincent Astor
Year: 1916
Row No.: 482

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

Year: 1913
E/P/S: P
No.: 294
Name: Noma
OA: 30' 3"

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

"Owner's steam launch." (Source: van der Linde, Claas. [Information based on plan titles.] January 31, 2009.)

"Frame space 9 1/2in used figures for #276 [#276p Launch for S. Y. Intrepid] with scale 14/[?] for breadth and depth.
Sheer same as #277 [#277p Isabel] except being raised for'd of [station] # 3. ..." (Source: Herreshoff Manufacturing Company. [Notes on Plan 2-84 (Construction Plan for Steam Launch for St. Y. Noma). Bristol, RI, December 29, 1913.)

"Steam engine rating 48hp from undated (1903 or later) diagram by N. G. Herreshoff titled 'Marine Engine. Weights and Prices' in the Halsey C. Herreshoff Collection at the Herreshoff Marine Museum." (Source: van der Linde, Claas. March 24, 2019.)

"Marine Engine of Inclosed Type. 3 1/2 & 5 & 8 x 4 1/2, 825[rpm], 48[hp]." (Source: Herreshoff, N. G. Handwritten List of HMCo-Made Steam Engines. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum, MRDED1_00220. Undated, between 1903 and 1918.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
