HMCo #1093s [Sailing Dinghy for George M. Pynchon]

Particulars

Construction_Record_Title.jpgName: [Sailing Dinghy for George M. Pynchon]
Later Name(s): Liberte
Type: Colonia Sailing Dinghy
Designed by: NGH
Contract: 1928-1-12
Delivered: 1928-5-1
Construction: Wood
LOA: 15' 6" (4.72m)
Rig: Sloop
Centerboard: yes
Ballast: None
Built for: Pynchon, George M[allory]
Amount: $1,200.00
Note(s) in HMCo Construction Record: Sailing dinghy. Taken by [#372p] Vasanta. Delivery May 1/28.
Current owner: Peter and Michelle Mann (rebuilt boat), Herreshoff Marine Museum (leftovers of old boat), Middletown, RI (last reported 2023 at age 95)

See also:
#192002es [Lifeboat for #372p Vasanta] (1920)
#372p Vasanta (1920)

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.


Model

Model #18Model number: 18
Model location: H.M.M. Model Room East Wall

Vessels from this model:
36 built, modeled by NGH
#190201ep [Electric Launch for #213p Quickstep] (1902)
#190602ep [Power Tender for #658s Irolita II] (1906)
#191002ep [Power Tender for #692s Westward] (1910)
#191902ep [Power Lifeboat for #329p Carola V] (1919)
#191903ep [Power Tender for #369p Sunflower] (1919)
#192201ep [Power Lifeboat for #329p Carola V] (1922)
#192202ep [Power Tender for #379p Mariette] (1922)
#190101es [Sailing Dinghy for #213p Quickstep] (1901)
#191101es [10ft Rowboat Job6258] (1912)
#191108es [Dinghy for #709s Joyant] (1911)
#191204es [Dinghy for #711s Ventura] (1912)
#191206es [Dinghy for #712s Spartan] (1912)
#191208es [Dinghy for #713s Iroquois II] (1912)
#191210es [Dinghy for #714s Pleione] (1912)
#191212es [Dinghy for #715s Grayling] (1912)
#191214es [Dinghy for #716s Samuri] (1912)
#191216es [Dinghy for #717s Barbara] (1912)
#191218es [Dinghy for #720s Acushla] (1912)
#191220es [Dinghy for #721s Carolina] (1912)
#191307es [Sailing Cutter for #719s Vagrant II] (1913)
#191503es [Sailing Cutter for #772s Mariette] (1915)
#191705es [Lifeboat for #303p Navette] (1917)
#191902es [Sailing Cutter for #827s Ohonkara] (1919)
#191905es [Lifeboat for #329p Carola V] (1919)
#192005es [Sailing Lifeboat for Guinevere Job10839] (1920)
#192102es [Dinghy for #867s Ventura] (1921)
#192104es [Sailing Lifeboat for #267p Enaj III] (1921, Extant)
#192204es [Sailing Cutter for #215p Roamer] (1922)
#192501es [Sailing Cutter for Katoura II] (1925)
#192602es Garryowen [Garry Owen] (1926, Extant)
#217p Maisie (1902)
#218p Carmen (1902)
#221p [Electric Launch for #151p Bellemere ex-Ballymena] (1902)
#568s [Sailing Dinghy for St. Y. Colonia] (1901)
#1093s [Sailing Dinghy for George M. Pynchon] (1928, Extant)
#1094s [Sailing Dinghy for I. B. Merriman] (1928)

Original text on model:
"Sailing dingy for COLONIA July 1901 1/12
Numbers 217 and 218 (1903) frame spaces 8 1/2" instead of 7 1/2" raised 1/2" stem 6" aft flared out to 5' 5" beam Model cut away forward and remeasured before #218 set up Dec. 1901
1923 (01?) sailing cutter for ROAMER 1925 sailing cutter for Rob. Tod 1926 sailing dinghy for Charles Goodwin." (Source: Original handwritten annotation on model. Undated.)

Model Description:
"#568 17'3" loa sailing dinghy of 1901 for the cutter Colonia. Also, with modifications, #217 Maisie and #218 Carmen, 20 loa electric launches of 1901, sailing cutter for the steam yacht Roamer, sailing cutter for the schooner Katoura, and sailing dinghy for Charles Goodwin." (Source: Bray, Maynard. 2004.)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.


Drawings

Main drawing Dwg 028-066 [076-161] (HH.5.02065) Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   HMCo #1093s [Sailing Dinghy for George M. Pynchon] are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
  1. Dwg 028-066 [076-161] (HH.5.02065); Construction Dwg > No. 1093, 15'-6" Sailing Cutter for Mr. George M. Pynchon (1927-12 ?)
  2. Dwg 128-107 (HH.5.10235): Sails > Sails 15 1/2' Sailing Tender (1928)
Source: Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. Haffenreffer-Herreshoff Collection. Together with: Hasselbalch, Kurt with Frances Overcash and Angela Reddin. Guide to The Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass., 1997. Together with: Numerous additions and corrections by Claas van der Linde.
Note: The Haffenreffer-Herreshoff Collection is copyrighted by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass. Permission to incorporate information from it in the Herreshoff Catalogue Raisonné is gratefully acknowledged. The use of this information is permitted solely for research purposes. No part of it is to be published in any form whatsoever.

Documents

Nathanael G. Herreshoff

"Aug 22 1928. N.G.H.
Recommended to Mr. Pynchon for a reduction of sail area, which he desired to have done near[?] his home.
Shorten mast 15in by cutting off at heel. Resplice shrouds & jib stay at lower end to shorten 15in and jib stay 14in, or so they will be right for the shortened mast.
Cut off mainsail at the luff 13in parallel. This will make hoist 20in shorter and allow boom hanging to be 5in higher from hull than present and give that much better headroom.
The boom can be 13in shorter. Cut aft end. Cut off jib at the foot 15in along the leach and 12in along the luff. Give the foot 1 1/2in roach, deepest 1/3rd from tack to clew.
The jibboom can be shortened 3in, cut aft end." (Source: Herreshoff, N.G. Penciled note on plan HH.5.02065 (028-066): Rowing Boats > 15'-6" Sailing Cutter. Haffenreffer-Herreshoff Collection, MIT Museum. August 22, 1928.)


Supplement

From the 1920 and earlier HMCo Index Cards at the MIT Museum
  • Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.
From the 1931 HMCo-published Owner's List

Type: Sail Dinghy
Length: 15'6"
Owner: Pynchon, George M.

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

From the 1930s L. Francis Herreshoff Index Cards at the Herreshoff Marine Museum
  • Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.
From the 1953 HMCo Owner's List by L. Francis Herreshoff

Name: N/A
Type: 15' 6" sailing dinghy
Owner: George M. Pynchon
Row No.: 809

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

From the 2000 (ca.) Transcription of the HMCo Construction Record by Vermilya/Bray

Month: Jan
Day: 12
Year: 1928
E/P/S: S
No.: 1093
OA: 15 1/2'
Rig: J ¦ M
CB: y
Ballast: None
Amount: 1200.00
Notes Constr. Record: Sailing Dinghy . Taken to Vansanta (?).
Last Name: Pynchon

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

Research Note(s)

"[Note in Hart Nautical plans database: Formerly drawing (76-161). For Geo. Pynchon, from moulds of # 562 [sic, i.e. 568 (Sailing dinghy for St. Y. Colonia)] w/ frame spaces 6 3/4". Dec. 1927.]" (Source: van der Linde, Claas. October 26, 2009.)

"Restored by IYRS in 2019/2020. Due to very deteriorated condition of the boat most everything had to be rebuilt/replicated. Original builder's plate has survived. Boat won 'Professionally Restored Winner' Prize in 2021 Mystic Seaport WoodenBoat Show." (Soure: van der Linde, Claas. October 9, 2021.)

"The carcass of the original boat was donated in 2024 to the Herreshoff Marine Museum. Which boat is now the original? The rebuilt one with all the original fittings and the original builder's plate or the left over remainders of the old boat?" (Source: van der Linde, Claas. July 10, 2024.)

"Plan 28-66 (formerly 76-161) from which this boat was built was drawn 1927-12." (Source: van der Linde, Claas. October 26, 2009.)

"Built in 110 days (contract to delivered; equivalent to $11/day)." (Source: van der Linde, Claas. July 10, 2024.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
