Herreshoff #186703es Hartford

"Hartford [later Polly ???] [#186703es ???]: 23ft Length on deck. 9ft Breadth extreme. 7ft 6in Centreboard length. 7ft Centreboard from woodends. No bowsprit. 23ft 6in Mainsail foot. 18ft Mainsail hoist. 11ft 6in Mainsail head. 28ft 3in Mainsail leech. 368sqft Mainsail area. No jib. No gafftopsail. No jibtopsail. [It is not clear if Hartford and Polly are identical. They have similar dimensions, are believed to have been built in the same year and nothing is known about Hartford in later years while nothing is known about Polly in earlier years. Note, that Hartford was apparently rigged as a catboat while Polly was rigged as a sloop, though with her mast far forward.]" (Source: Herreshoff, N.G. and/or other Herreshoff family members. Handwritten table listing early Herreshoff-built boats and their dimensions up to 1870. No date (1870 or later). Halsey C. Herreshoff Collection at the Herreshoff Marine Museum, MRDE03.)

"[Item Description:] Handwritten (in ink and pencil) table providing what amounts to be the earliest Herreshoff construction record with detailed dimensional data (Name, Owner, Length on deck, Length on water, Breadth extreme, Depth, Deadrise per foot, Width of stern, Sheer, Freeboard at bow, stern and lowest place, Centreboard length, Centreboard from woodends, Centre of mast from woodends, Bowsprit out board, Mainsail foot, hoist, head, leech, and area, Foresail foot, hoist, head, leech, and area, Jib foot, hoist, leech, and area, Gafftopsail foot, luff, leech, and area, Fore-gafftopsail foot, luff, leech, and area, Jibtopsail foot, hoist, leech, and area and Notes ) for Julia [#185602es], Sprite [#186001es], Kelpie 1st [#186301es], Magic [#186404es], Toad [#186411es], Prudence [#186406es], Patience [#186405es], Hope [#186402es], Faith [#186401es], Qui Vive [#186407es], Kelpie 2nd [#186403es], Teazer [#186410es], Secret [#186408es], Fish Boats [#186505es, #186506es, #186507es, #186508es, #186509es, #186510es, #186511es, #186512es], Fish Boats [#186513es, #186514es, #186515es, #186516es, #186517es, #186518es], Fanchon [#186501es], Angie [#186503es], Haidee [#186604es], Ariel [#186601es], Psyche [#186605es], Fannie 1st [#186603es], Violet [#186606es], Fish Boats [#186607es, #186608es], Fish Boats [#186609es, #186610es, #186611es, #186612es, #186613es, #186614es], Lively Whale [later Daisy ???] [#186707es ???], Fannie 2nd [#186702es], Hartford [later Polly ???] [#186703es ???], Sadie [#186704es], Clytie [#186701es], Waterfall [N/A], Bristol [#186801es], Ione [#187003es], Poppasquash [#186502es], Etta [N/A], Oysterboats [#186710es, #186711es], Spring Green [#186709es], Pellican [#186708es], Henrietta [N/A], Meteor [N/A], Fatter[?] [N/A], Annie Moies [#1p], Charlotte [#186803es], Annie [#186905es], Hildegard [#186808es], Thetis [#186705es], Clio [#187101es], Fleetwing [N/A], White Straw[?] [N/A], [Mignone] [#186904es], Fish Boats [square stern, 1868] [N/A], Sadie [#N/A (dupl. listing)], Fannie [N/A], Bunsby [#186802es], Orion [#186903es], Breeze [N/A], Nimbus [#186805es], Alice [crossed out, this MIGHT be Bessie] [#187001es], Viking [#187008es], [Ianthe] [#187002es], [Surf] [#187007es], [Georgie Miller] [#187011es], and [Pink] [#187010es]. Undated, the latest vessel on the list was built in 1870." (Source: Herreshoff, N.G. (?) (creator) or other Herreshoff family members (?) (creator). Construction Record. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE03_01410. Folder [no #]. No date (ca 1870).)
① ② ③ ④ ⑤ ⑥

"[Item Transcription:] Bristol, R.I. June 25th [18]74
Dear Brothers [Nat and Lewis in France],
I have been trying to write you for the past two weeks --- have been busy for the past two weeks, but am now more at leisure. We rec[eive]d Lewis' letters to Sister Carrie two days ago.
You have probably decided we[?] think[?] how you will pass your time for the few months remain[in]g in Europe. Your proposed trip in the small boat [#187406es RIVIERA] has caused a good deal of talk & feeling among your relatives here: All I can say is respecting that you & Lewis are the most competent to judge for yourselves, in relation to it, and I think will not needlessly expose yourselves.
Have been talking with Mother in regard to funds for your use. Mother expects to send in a day or two ab[ou]t[?] $100. We think that the $270 Mother sent about the latter part of May will be all that you [p. 2] require on the Continent.
I expect you will occupy at least one month in England & Scotland before returning home.
Sadie & I have placed $100[?] in the Saving Bank, which we shall be most happy to send you at any place you may designate. I should think you would need it by the time you arrive in England. It is for both of you.
Then I will also send $100 from elsewhere[?]: So do not try to economize too close or shorten y[ou]r tour.
You must all be having rather a pleasant & happy time.
Your letters are always interesting & eagerly read by us all.
Do not forget to write one a falnight[?] during your tour.
Now I must tell you how we are at home.
Brother Charles and the family [p. 3] are all well. Aunt Anna & Sister Sally are well. Aunt Sarah recov[erin]g[?] from a recent nervous attach. Papa & Mama & all here are well except for Stanton [Chesebrough] who has not been quite so well the few past days.
Bro James started off yesterday on an excursion to Montauk, expected back in ab[ou]t ten days. I called Ms. Haughton three days ago. Said she had just written you. Stopped at Corliss & one[?] hauled the new pumping engine he had just made to play with: Some very good and some very poor features about it: There is the usual trouble too much fiction. We completed the Steamer 'WM. SPICER' [#13p] on the last day of June: She worked well, every way, except the condenser which was 3[?] 2in[?] half[?] pipes alongside of her hull. The exhaust steam chose very foolishly to pass thru the upper pipe, which after all is very natural. I had to take it all off & make a condenser in our usual manner. The boiler seems to be capable of supply[in]g all the steam required & that [p. 4] without foaming. We made a few trials of her speed, found 40lbs would run her ten miles an hour, 52lbs 11 miles an hour. I think with 85 or 90 she would easily run 13. She is a very pretty boat & I think nearer right than others built for the business. We sold the CREST [#12p] to a Mr. Potter of N[ew] York who will use her at his residence on the Shrewsbury river. She left here on the 11t. Capt Denum who came with us from Springfield last year took her on alone, the same made a satisfactory run. Now I must tell you about the new [Coil] Boiler. We made one & used it in the CREST about one month. The upper 1/2 inch pipe, then 3/4, & the[?] the lower 1 in. pipe encased by a sheet iron drum 28 in. diam[eter] & about the same height. Our first trial in the boat was to run her in the harbor about one hour with a steam pressure of 1 to 200 lbs, you can imagine the speed. She was used ab[ou]t every day & the greatest speed obtained with 140lbs, 11 miles an hour & 110 lbs 10 miles per hour. [p. 5] The boiler is undoubtedly a great success, it seems to work equally well with all kinds of water, the cylinders run longer without oil than ever before & did not wear at all or grunt. The only difficulty seemed to be the proper amount of feed water which must vary according to the heat from the furnace. Me or James have got up something, a pocket which the steam passes thru from the worm [i.e the coil] & then[?] is superheated from the remaining lower coils, a floating ball with pks[?] let out the surplus water & also regulates the feed water. I shall have the boiler completed with the attachment, also another engine finished up with metal piston & stem[?] packing, to put into a boat 30 ft. long, 4 ft wide, 18 in deep. W[eigh]t of machinery 500[?] lbs & w[eigh]t of boat 500[?] lbs. We expect to run our 32 in. wheel 500 turns per min[ute] & keep a pressure of 110 lbs, using salt water, no condenser or water tank required. [This appears to be a reference to what will become the 48ft VISION, the first boat built with a coil boiler but VISION had already been mentioned in earlier letters as a 50ft boat.] Can we get a speed of 18 miles per hour?
We expect to have the boat completed by Aug[us]t[?]. We are just finish[in]g the R.[?] Island boat [apparently #187402es ASPHODEL] & expect to beat[?] the JULIA [#187004es] next week. [p. 6] Mr. Reynolds has tried his new steam boat at Phil[adelphi]a & runs her at the rate of 20 miles per hour. The trial was made last Saturday.
When you come back we want you both to take hold with us and make something out of Jim's new invention. There is room enough for you both.
The HARTFORD [#186703es] is launched & Pa & I[?] are now going off to race with her. Stanton [Chesebrough] is much better to day than he was yesterday. Love to our kind cousins C & H. We feel very grateful to them for their kindness to you. Pas strawberries are now ripe and very nice. Wish we could send you some.
Yours with love, both from Sadie & your aff[ectionate] brother John B. Herreshoff.
Katie often speaks of you both. We had a pleasant visit from Geo[rge] P[hillips] & wife.
[The same pages contain a second two-page letter under different date:]
Bristol R.I. May 29 / [18]74
Dear Brothers
Your letters were received in due time and have been gladly perused by all of us --- they are full of interest.
I wrote you a long letter about the middle of April [1874-04-12 and 1874-04-19] giving you a description of the steamer [#13p WILLIAM SPICER] I have been building. Think you should have got it before Nat's last letter was mailed. We launched the WM. SPICER Tuesday P.M. May 26th with quite a number on board, mother, leng[?] Lizzie & Sally, Francis, Geo[rge] Phillips & wife, Grace & her father & Mrs. Locke being among them. She was launched with all the machinery on board and all the piping up. We made our trial trip in her this P.M. She is a great success, all the machinery and joints being right the first time. She is [p. 2] fitted as follows --- boiler 5 x 9ft, main engine 14 x 16 inches, screw 57 inches 4 blades, hoisting engine 3 1/2 x 7, being a Sturtvant blower with 7[?] inch pipe and an auxiliary pump. Water tank of iron contains about 3 h[un]d[re]ds[?]. Safety valves, one 1 1/2 inch common & one 2 1/2 inch Slip[?] Locke[?] valve. Condense pipes, brass, three in number, 2 inch inside, most of the small piping is brass, according to Lewis' request.
The result of our trial this P.M. was with 40 lbs pressure, 120 rev[olutions], 1/2 mile course with head tide, three min & 6 seconds. The blower works admirably, could have driven the boat with it so to have run the boat 13 m[iles] per hour, I think. Will write you about the next trial which will be on Tuesday next, when the boat will be ready for delivery. Yours John." (Source: Herreshoff, J.B. Letter to Herreshoff, Lewis and Herreshoff, N.G. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MR_07470. Correspondence, Folder 25, formerly 212. 1874-05-25 and 1874-06-25.)
① ② ③ ④

Note: This list of archival documents contains in an unedited form any and all which mention #186703es Hartford even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

• Polly
• Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.

Name: Polly
Type: 21' 2" sloop
Owner: Homer W. Hervey [sic, Hervey was owner in 1884 as per American Yacht List 1884]
Year: 1867
Row No.: 535

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

"Dimensions from 1885 Olsen's American Yacht List when this boat is believed to have been named Polly. See also slightly differing dimensions from Herreshoff, N.G. and/or other Herreshoff family members. Handwritten table listing early Herreshoff-built boats and their dimensions up to 1872. No date (1872 or later). Halsey C. Herreshoff Collection at the Herreshoff Marine Museum, MRDE03, which also provides sail dimensions. Note that it is not proven that Hartford and the later Polly are identical." (Source: van der Linde, Claas. March 19, 2019.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
