HMCo #220p Atala

"July 2, 1902.
Trial of st[eam] Launch #220 [Atala]
28ft Launch - same as #199 [which was built from model 424] - for Mr. Grosbeck
On 1/2 mile course at Harbor, wind NNW about 10 miles, 3 on boat, with equipment and moderate am[oun]t of coal.
[Followed by tabulated trial run data with mean speed being 14.99mph (= 13.03kn)]
Everything worked well except water guage broke in 1st run, and engineer Robertson was a little hampered with water level." (Source: Herreshoff, N. G. Handwritten note in Trials Booklet '1898 - 1909' under date of July 2, 1902. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum.)

"220 [#220p]. 28ft. 14.98[mph = 13.02kn]." (Source: Herreshoff, N. G. Penciled Note on Verso of Envelope titled 'Trials of 26[ft], 28[ft] & 30[ft] Launches. 1898 - 1912. N.G.H.'. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum. No date, September 28, 1920 or later.)

"... The new mahogany steam launch Marlow, built for a yachtsman at Buffalo at the Herreshoff shops, was tried the first of the week and developed a speed of 16 knots per hour. She is 28 feet in length. She has been shipped to Buffalo." [Note: The identity of this steam launch is unclear. Atala is the only steam lauch which fits the size and timeframe.] (Source: Anon. "Notes for Yachtsmen." New York Times, July 7, 1902, p. 8.)

"[Item Description:] Handwritten notebook. This booklet had two lives: In 1907-1908, 1908-1909 and 1909-1910 it was used for winter storage records, listing name of boat, owner, storage location, billed amount, and dates of storage. Listed were for the winter of 1907/1908: #235p MIST, ORIANA, #571s LARIKIN, EAGLET, #453s VAQUERO II, #580s TRIVIA, #663s ISTALENA, COSSACK, #666s AVENGER, #220p ATALA (for sale), #207p MIRAGE, #224p EUGENIA, #146p AUGUSTA, #247p SEA URCHIN, #105p COSETTE, ARLINE, #213p FLORENCE, #208p FLORETTE, #249p SISILINA, #591s IROLITA, #481s SPALPEEN, DUCHESS, #669s ELEANOR, #460s KILDEE, #647s CAPRICE, #408s PELICAN, #243p SWIFTSURE, #617s COCK ROBIN, #177p VANISH, #446s ALERION, and #591s IROLITA I, for the winter of 1908/1909: #666s AVENGER, #663s ISTALENA, #481s SPALPEEN, #580s TRIVIA, #617s COCK ROBIN, COSSACK, #177p VANISH, #242p #242, #243p SWIFTSURE, SKIP, #446s ALERION, CHEWINK II, DUCHESS, #571s LARIKIN, #460s KILDEE, #679s PEPITA, EAGLET, #408s PELICAN, #453s VAQUERO, #146p AUGUSTA, #224p EUGENIA, COYOTE, #264p SARAH WEBB, #207p MIRAGE, ARLINE, #213p FLORENCE, #208p FLORETTE, #249p SISILINA, #591s IROLITA I, CASSANDRA 27ft Launch, and #263p CASSANDRA 34ft Launch, and for the winter of 1909/1910: #252p WANECHE (no further boats were listed). At some later time, the same book was turned upside down and inscribed with a new title in ink '200Ft Submarine Destroyer [#191802ep Unbuilt 200ft Submarine Chaser]. Data + Calculation Book. Herreshoff Mfg Co.' on its now-new front cover (formerly its back cover), followed by weight data estimates and calculations for this submarine destroyer." (Source: Herreshoff Manufacturing Co. (creator). Notebook. MIT Museum, Hart Nautical Collections, Haffenreffer-Herreshoff Collection Item HH.6.087. Box HAFH.6.2B, Folder Submarine Destroyer 200-Footer. 1907-1908, 1908-1909, 1909-1910, 1918-06.)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓ ㉔ ㉕ ㉖

"[Item Transcription:] Handwritten (mostly in pencil but also in ink) trials booklet titled '1898 - 1909'. Relevant contents:
§24: #220p ATALA Trial Run best mean speed 14.99mph [= 13.03kn] (1902-07-02)." (Source: Herreshoff, N.G. (creator). Trials Booklet. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE09_00060. Folder [no #]. 1898-09 to 1911-04.)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓ ㉔ ㉕ ㉖ ㉗ ㉘ ㉙ ㉚ ㉛ ㉜ ㉝ ㉞ ㉟ ㊱ ㊲ ㊳ ㊴ ㊵ ㊶ ㊷ ㊸ ㊹ ㊺ ㊻ ㊼ ㊽ ㊾ ㊿
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪

"[Item Transcription:] [Penciled trial run summary on verso of envelope to NGH in Bristol, R. I. postmarked September 27, 1920:] Trials of 26[ft], 28[ft] & 30[ft] Launches. 1898 - 1912. N.G.H.
197 [#197p]. 26ft. 13.10[mph = 11.38kn]. 225lbs.
198 [#198p]. 26ft. 12.49[mph = 10.85kn].
199 [#199p]. 28ft. 13.02[mph = 11.31kn]. 210lbs.
199 [#199p]. 28ft. 16.02[mph = 13.92kn]. 240lbs.
202 [#202p]. 30ft. 15.35[mph = 13.34kn]. 235lbs.
202 [#202p]. 30ft. 15.50[mph = 13.47kn]. 245lbs.
200 [#200p]. 28ft. 14.35[mph = 12.47kn].
201 [#201p]. 28ft. 14.25[mph = 12.38kn].
214 [#214p]. 26ft. 14.60[mph = 12.69kn]. 240lbs.
214 [#214p]. 26ft. 13.47[mph = 11.71kn]. about 235lbs.
220 [#220p]. 28ft. 14.98[mph = 13.02kn].
227 [#227p]. [30ft]. 13.82[mph = 12.01kn].
?. 28ft. 14.50[mph = 12.60kn].
239 [#239p]. 28ft. 13.22[mph = 11.49kn]. Required 10k[nots].
?. 26ft. 12.50[mph = 10.86kn].
239 [#239p]. 28ft. 12.40[mph = 10.78kn]. Not full speed.
246 [#246p]. 28ft. 13.55[mph = 11.77kn].
?. 28ft. 14.46[mph = 12.57kn].
275 [#275p]. 28ft. 10.80[mph = 9.38kn]. Not full speed.
274 [#274p]. 27ft. 14.66[mph = 12.74kn]. [More calculations on other side.] [Note: Every launch listed above was built from Model 424 --- as if this was an attempt to assess the speed of launches built from this model and thus judge the capabilities of the model.]" (Source: Herreshoff, N. G. (creator). Penciled Note. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE03_03510. Folder [no #]. No date (1920-09-28 or later).)
① ②

Note: This list of archival documents contains in an unedited form any and all which mention #220p Atala even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

• Atala (HMCo-made index card)
• Atala (MIT Museum-made index card)
• Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.

Name: Itala [sic, i.e. Atala]
Type: Steam
Length: 28'
Owner: Grosbeck, H. J.

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

• Atala
• Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.

Name: Itala [sic, i.e. Atala]
Type: 28' steam
Owner: H. J. Grosbeck
Year: 1906
Row No.: 313

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

Year: 1902
E/P/S: P
No.: 220
Name: Atala
OA: 28'
LW: 27' 9"

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

"Steam engine rating 48hp from undated (1903 or later) diagram by N. G. Herreshoff titled 'Marine Engine. Weights and Prices' in the Halsey C. Herreshoff Collection at the Herreshoff Marine Museum." (Source: van der Linde, Claas. March 24, 2019.)

"Marine Engine of Inclosed Type. 3 1/2 & 5 & 8 x 4 1/2, 825[rpm], 48[hp]." (Source: Herreshoff, N. G. Handwritten List of HMCo-Made Steam Engines. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum, MRDED1_00220. Undated, between 1903 and 1918.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
