HMCo #604s Papoose III

"[1903-04-01] Wed 1: Very fine. W to N moderate [wind] & clear. Turned over #604 [Papoose III] the last of 13 Bar Har[bor] class. ...
[1903-05-02] Sat 2: Fine & cold. Temp[erature] 33deg. early and ice formed 1/4in. thick. Took #604 [Papoose II], the last of the 13 Bar Harbor class to the cove." (Source: Herreshoff, Nathanael G. Diary, 1903. Manuscript (excerpts). Diary access courtesy of Halsey C. Herreshoff.)

"Nos. 592 to 604 inclusive [#592s, #593s, #594s, #595s, #596s, #597s, #598s, #599s, #600s, #601s, #602s, #603s, #604s].
Bar Harbor Class.
Frame spaces 12 1/2".
Planking 1 1/8".
Timbers moulded 1 1/2" at head increasing 1/8 per foot.
Sided 1 7/8".
Keel steamed or bent 2 7/8" think[?]." (Source: Herreshoff, N.G. [Penciled note in Offset Booklet HH.4.139.] No date [ca. October 1902]. Haffenreffer-Herreshoff Collection, MIT Museum, Cambridge, MA.)

"A contract for sixteen [sic, i.e. thirteen] sloop yachts of the thirty foot class was received this week by the Herreshoffs. The boats are to be of one design and are to be drawn by lot next spring. It is to be known as the Bar Harbor class and the yachts will be constructed in the building now in process of construction on the east side of Hope street, opposite the construction shops." (Source: Anon. "Bristol and Vicinity." Bristol Phoenix, October 3, 1902, p. 2.)

"BAR HARBOR, Sept 20 [1902]. --- ... Prospects for the yachting fraternity next season are excellent. There is to be a single-design class built which will be uniform in every particular, the various members to draw for their boats. Those who will build are V. Everett Macy, A. J. Cassatt, W. G. Ladd, H. L. Eno, Edgar Scott, Edward Morrell, R. Horace Gallatin, H. M. Sears, W. C. Allison, J. M. Sears, Antonio Y. Stewart, and T. G. Condon." (Source: Anon. "Bar Harbor Happenings." New York Times, September 21, 1902.)

"Work has begun on the first of the new class of 30-footers known as the Bar Harbor class. These boats are to be built in the new shop constructed this fall directly opposite the old construction shop. There are to be fourteen of these boats built from the same mould, and will be drawn by lot in the spring." (Source: Anon. "Yachting." New York Tribune, November 16, 1902, p. 10.)

"Papoose No. 3, sloop, of Bristol.
Built at Bristol, RI, by Herreshoff Manufacturing Co.
10.46 gross tons, 8.71 net tons; 36.4 ft. x 10.4 ft. x 5 ft. [Register length x breadth x depth.]
One deck, one mast, overhanging head, overhanging stern.
Surveyed and measured, March 30, 1903." (Source: U.S. Customs Department, Bristol, R.I. Custom House Record Book, 1870s to 1904 (Collection of the Herreshoff Marine Museum), s.v. Papoose No. 3.)

"[License issued to vessel under 20 tons. Pos. 211:]
Papoose No. 3, sloop, of Bristol.
Built at Bristol, 1903.
8.71 tons; 36.4 ft. x 10.4 ft. x 5 ft. [Register length x breadth x depth.]
No specifications shown.
Lic[ensed] ([as] yacht) May 6, 1903. Owner: Herreshoff Manufacturing Company of Bristol. Master: N. G. Herreshoff.
Surrendered [license] June 12, 1903 at New York. ([Record at:] C[ustom] H[ouse, Providence])." (Source: Survey of Federal Archives, Work Projects Administration. Ships Documents of Rhode Island. Bristol. Ship Registers and Enrollments of the Port of Bristol - Warren Rhode Island, 1941, s.v. Papoose No. 3.)

"... C. W. Estabrook for the past eight years in the brokerage department of Swasey, Raymond & Page, has severed his connection with that firm and has opened a general marine brokerage office at 38 Broad st [Boston]. The following sales are reported through that office: ... the Bar Harbor 31-footer Papoose III by A[lbert] B. Freeman of Boston to Eugene T. Connolly of Beverly farms ..." (Source: Anon. "Notes from the Week's Log." Boston Globe, September 10, 1911, p. 53.)

"... The yachts took part in the regatta of the Eastern Y. C. off Marblehead on Tuesday, August 8th [1916], and had to battle with one of the worst thunder squalls of the season. The storm lasted a long time, and Britomarte of Class P, and Leenane [#604s] and Zara [#594s], of the Bar Harbor 31-footers, were dismasted, and Stranger and Meemer were forced to withdraw. ... Manataqua won in Class Q; Huskie II in Class R; Mildred IV [#596s] in the Bar Harbor Class. In spite of the storm and high sea, the small craft did remarkably well, and every boat was handled with rare skill. ..." (Source: Anon. "Marblehead And Its Enthusiastic Yachtsmen." Rudder, September 1916, p. 408.)

"N/A"

"[Item Description:] Penciled pantograph hull sections titled 'Bar Harbor class [#592s, #593s, #594s, #595s, #596s, #597s, #598s, #599s, #600s, #601s, #602s, #603s, #604s]. 2nd model [Model 713]. 1st trial. Sc[ale] 3/4. Sept[ember] 25 1903 []sic, i.e. 1902'. With calculations arriving at a displacement of 337.5cuft [= 21600lbs]." (Source: Herreshoff, N.G. (creator). Pantograph Hull Sections. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE04_03990. Folder [no #]. 1902-09-25.)
①

"[Item Description:] Penciled pantograph hull sections with radials titled 'Bar Harbor Class. # 592 to 604 inclusive [#592s, #593s, #594s, #595s, #596s, #597s, #598s, #599s, #600s, #601s, #602s, #603s, #604s]. From finished model. Oct[ober] 2, 1902. Scale 1/16. W.l. 30ft 9in'. With tabulated calculations distinguishing between 'displacement body part' and 'displacement total' and arriving at a total displacement of 330.5cuft = 21160lbs." (Source: Herreshoff, N.G. (creator). Pantograph Hull Sections. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE04_04130. Folder [no #]. 1902-10-02.)
①

"[Item Description:] Penciled pantograph lead sections titled 'Nos. 592 to 604 inclusive [#592s, #593s, #594s, #595s, #596s, #597s, #598s, #599s, #600s, #601s, #602s, #603s, #604s]. Oct[ober] 7, 1902. 1/8 size'. With calculations (marked 'By planimeter') and note 'Required lead casting of 10000lbs with c.g. [at] 55.4[%] of w.l. = 17.05ft aft ...'. With note 'Dec[ember] 11, 1902. #592. With all w[ei]g[h]ts represented proved too deep in water and 1045lbs removed, was then 30ft 10 3/4in w.l. Have decided to take a piece of equal thickness off top of lead = 2 3/8in' and calculations to derive this amount." (Source: Herreshoff, N.G. (creator). Pantograph Lead Sections. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE04_09280. Folder [no #]. 1902-10-07.)
① ②

"[Item Description:] HMCo Plan HH.5.02171 (029): Blueprint general arrangement plan with plan view and inboard profile titled 'Preliminary Plan of Bar Harbor Cruising Class [#592s, #593s, #594s, #595s, #596s, #597s, #598s, #599s, #600s, #601s, #602s, #603s, #604s]. Herreshoff Mfg. Co. Bristol, R.I. Scale 1/4in = 1ft. Oct[ober] 9, 1902'." (Source: Herreshoff Manufacturing Co. (creator). Blueprint. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Acc. 2004.0001.0028. WRDT08, Folder 3, formerly MRDE08. 1902-10-09.)
① ②

"N/A"

"[Item Description:] Handwritten (in ink) rating rule-related table on two pages with dimensions LOA, LWL, overhang fore & aft, mean length, freeboard fore & center & aft, breadth deck & w.l., draft, cube-root (displacement), 1st mast mean length, 1st to 2nd mast, J, P1, H1, B1, G1, V1, T1, P2, P2a, H2, B2, Q2, Y2,T2, sail area, sqrt(SA), sqrt(SA - NYYC Rule) for #605s RELIANCE, #499s COLUMBIA, #725s RESOLUTE, #529s MINEOLA, #663s ISTALENA, #666s AVENGER, New York 50s (#711s, #712s, #713s, #714s, #715s, #716s, #717s, #720s, #721s), #411s GLORIANA, #685s ADVENTURESS, #617s COCK ROBIN II, #586s NELLIE, #709s JOYANT, #708s CORINTHIAN, #670s SENECA, Bar Harbor 31s (#592s, #593s, #594s, #595s, #596s, #597s, #598s, #599s, #600s, #601s, #602s, #603s, #604s), New York 30s (#626s, #627s, #628s, #629s, #630s, #631s, #632s, #633s, #635s, #636s, #637s, #638s, #639s, #640s, #642s, #643s, #647s, #648s), Newport 29s (#727s, #728s, #737s), #691s MORE JOY, #446s ALERION II, Buzzards Bay 550s (#733s, #734s, #736s, #738s, #741s), #617s COCK ROBIN II, #493s JILT, #732s SADIE, #460s KILDEE, Buzzards Bay 15s (#503s Class), Buzzards Bay 12 1/2s (#744s Class), #703s FLYING CLOUD, #669s ELEANOR, #722s KATOURA, #692s WESTWARD, #657s QUEEN, #719s VAGRANT II, #698s VAGRANT, #663s ISTALENA, and #743s HASWELL. With penciled note 'Measurements in ft & inches. Results in ft & decimals'. Undated (the youngest boat on this list is from 1914/1915 and this was probably prepared in preparation for NGH's sail area rating rule of 1914/1915)." (Source: Herreshoff, N.G. (creator). Handwritten Table. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE15_00100. Folder [no #]. No date (1914 / 1915 ?).)
① ②

"[Item Description:] Printed pamphlet titled 'Annual Dinner. Bar Harbor 31 Foot Association. January 3, 1917 at the Engineers Club Boston'. With photos of the 'Flight' [#600s, winner of the 1915 Championship], 'Stephen J. Connolly (Alibi Steve), President' [owner of #604s Leenane ex-Papoose III], 'H.B. Whittier, First President of the Association, formerly owner of CRICKET [#602s], FLIGHT [#600s], ZARA [#594s] and Honorary Member of the Association', 'A. P. Moses, Second President of the Association, owner of MILDRED IV [#596s ex-BAT] and active in yacht racing for twenty-fize years', J.V. Santry 'Third President of the Association, and owner of the FLIGHT [#600s], the Youth of the Class. Erstwhile winner of all championships of 1916', and 'Arthur Ginn, Secretary and Treasurer, the man who kept the Association going and has held his offce since the formation of the Association. He is not permitted to resign, as the directors believe they know when they have a good thing'." (Source: Bar Harbor 31 Foot Association (creator). Printed Pamphlet. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum Item MRDE08_02190. Folder [no #]. 1917-01-17.)
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬

Note: This list of archival documents contains in an unedited form any and all which mention #604s Papoose III even if just in a cursory way. Permission to digitize, transcribe and display is gratefully acknowledged.

• Bray, Maynard. "Two Views of the Herreshoff Bar Harbor 31s." Day, Fritz and Frances. "Desperate Lark." Bray, Maynard. "Holding the Shape the Herreshoff Way." Wooden Boat #45, March/April 1982, p. 68-74. (520 kB)
  Document is copyrighted: Yes, used with permission. Copyright holder: Maynard Bray (text). Bar Harbor 31 class portrait with special emphasis on #602s Desperate Lark ex Cricket and detailed description of why Herreshoff boats have been able to hold their shape better over time than many other yachts.

• Papoose III (HMCo-made index card)
• Papoose III (MIT Museum-made index card)
• Note: The vessel index cards comprise two sets of a total of some 3200 cards about vessels built by HMCo, with dimensions and information regarding drawings, later or former vessel names, and owners. They were compiled from HMCo's early days until 1920 and added to in later decades, apparently by Hart Nautical curator William A. Baker and his successors. While HMCo seems to have used only one set of index cards, all sorted by name and, where no name was available, by number, later users at MIT apparently divided them into two sets of cards, one sorted by vessel name, the other by vessel number and greatly expanded the number of cards. Original HMCo cards are usually lined and almost always punched with a hole at bottom center while later cards usually have no hole, are unlined, and often carry substantially less information. All cards are held by the Francis Russell Hart Nautical Collections of the MIT Museum in Cambridge, Mass.

Name: Papoose III
Type: J & M DH
Length: 30'9"
Owner: Macy, V. E.

Source: Herreshoff Manufacturing Company. "A Partial List of Herreshoff Clients." In: Herreshoff Manufacturing Company. Herreshoff Yachts. Bristol, Rhode Island, ca. 1931.

• Papoose III
• Leenane ex-Papoose III
• Badger ex-Papoose III
• Spindrift ex-Papoose III
• Papoose
• Note: The L. Francis Herreshoff index cards comprise a set of some 1200 cards about vessels built by HMCo, with dimensions and / or ownership information. Apparently compiled in the early 1930s, for later HMCo-built boats like the Fishers Island 23s or the Northeast Harbor 30s are not included. Added to in later decades, apparently by L. F. Herreshoff as well as his long-time secretary Muriel Vaughn and others. Also 46 cards of L. F. Herreshoff-designed vessels. The original set of index cards is held by the Herreshoff Marine Museum and permission to display is gratefully acknowledged.

Name: Papoose
Type: 31' cutter
Owner: Victor E. Macy
Year: 1903
Row No.: 507

Source: Herreshoff, L. Francis. "Partial List of Herreshoff-Built Boats." In: Herreshoff, L. Francis. Capt. Nat Herreshoff. The Wizard of Bristol. New York, 1953, p. 325-343.

Month: Oct. [sic, i.e. no month]
Day: 3 [sic, i.e. no day]
Year: 1902
E/P/S: S
No.: 0604
Name: Papoose III
LW: 30' 9"
B: 10' 4"
D: 7' 3"
Rig: J & M
K: y
Ballast: Lead O.
Amount: $4960.00
Notes Constr. Record: Bar Harbor class
Last Name: Macy
First Name: V. E.

Source: Vermilya, Peter and Maynard Bray. "Transcription of the HMCo. Construction Record." Unpublished database, ca. 2000.

Note: The transcription of the HMCo Construction Record by Peter Vermilya and Maynard Bray was performed independently (and earlier) than that by Claas van der Linde. A comparison of the two transcriptions can be particularly useful in those many cases where the handwriting in the Construction Record is difficult to decipher.

"V. Everit Macy, the owner of Papoose III, was the brother of Kate Macy Ladd, who in turn was married to W. G. Ladd, the owner of the Bar Harbor 31 Cricket." (Source: van der Linde, Claas. April 22, 2013.)

"LOA 48ft 9in from pencilled note on construction plan 76-46." (Source: van der Linde, Claas. April 25, 2013.)

"Sail no. BH-4." (Source: van der Linde, Claas. October 20, 2015.)

"Launch date signifies the date vessel was taken to cove." (Source: van der Linde, Claas. November 4, 2011.)

"Built in 211 days (contract to launch; equivalent to $24/day, 100 lbs displacement/day)." (Source: van der Linde, Claas. January 16, 2024.)

"Sail area 1492 sqft from rating rule-related table handwritten (in ink) by N. G. Herreshoff on two pages with multiple dimensions for the most important Herreshoff-designed yachts in the Halsey C. Herreshoff Collection at the Herreshoff Marine Museum. MRDE15, Folder [no #]. Undated (the youngest boat on this list is from 1914/1915 and this was probably prepared in preparation for NGH's sail area rating rule of 1914/1915)." (Source: van der Linde, Claas. September 16, 2020.)

"Displacement 330.5 cu.ft. [= 21,152 lbs] from untitled two-page rating-rule-related table handwritten (in ink) by N. G. Herreshoff with multiple dimensions for the most important Herreshoff-designed yachts. Halsey C. Herreshoff Collection at the Herreshoff Marine Museum. MRDE15, Folder [no #]. Undated (the most recent boat dates 1914/1915 and the table was probably prepared in preparation for NGH's sail area rating rule of 1914/1915)." (Source: van der Linde, Claas. September 16, 2020.)

"Designed disp. on 30ft-9in W.L., 21415 lbs." (Source: Herreshoff Manufacturing Company. Penciled note on construction plan 76-46.)

Note: Research notes contain information about a vessel that is often random and unedited but has been deemed useful for future research.
