HMCo #499s Columbia


Particulars

Construction_Record_Title.jpgName: Columbia
Type: America's Cup Defender
Designed by: NGH
Contract: 1898-9-28
Launch: 1899-6-10
Construction: Bronze
LOA: 131' 0" (39.93m)
LWL: 89' 9" (27.36m)
Beam: 24' 0" (7.32m)
Draft: 19' 9" (6.02m)
Rig: Cutter
Sail Area: 13,880sq ft (1,289.5sq m)
Displ.: 163.9 short tons (148.7 metric tons)
Keel: yes
Ballast: Lead
Built for: Iselin, C. Oliver [Syndicate, J. P. Morgan]
Amount: $90,000.00
Last year in existence: 1915 (aged 16)
Final disposition: Sold for scrap in winter of 1914/1915.

See also:
#189801es [Cutter for #499s Columbia] (1898)
#189902es [Dinghy for #499s Columbia] (1899)
#190311es [Dinghy for #499s Columbia] (1903)

Note: Particulars are primarily but not exclusively from the HMCo Construction Record. Supplementary information not from the Construction Record appears elsewhere in this record with a complete citation.


Model

Model #705Model number: 705
Model location: H.M.M. Model Room North Wall Right

Vessels from this model:
1 built, modeled by NGH
#499s Columbia (1899)

Original text on model:
"COLUMBIA 1898-99 Scale 3/8 Dinghy #48" (Source: Original handwritten annotation on model. Undated.)

Model Description:
"89'9" lwl Columbia, keel cutter and America's Cup defender of 1899." (Source: Bray, Maynard. 2004.)

Note: Vessels that appear in the records as not built, a cancelled contract, a study model, or as a model sailboat are listed but not counted in the list of vessels built from a model.


Offsets

Offset booklet number(s): HH.4.111.1; HH.4.111.2; HH.4.111.3; HH.4.111.4

Offset booklet contents:
#499 #529 [lead ballast keel offsets and calculations for America's Cup defender Columbia and NYYC 70 class cutter Mineola et al];
#499 [America's Cup defender Columbia];
#499 [America's Cup defender Columbia];
#499 (14' lifeboat and 14 1/2' gas launch), 11 1/2' rowboat ([internal] job no. 6259), #624 (10'8" dinghy), 12 1/2' rowboat.


Offset Booklet(s) in Haffenreffer-Herreshoff Collection. Francis Russell Hart Nautical Collections, MIT Museum, Cambridge, Mass. (Restricted access --- see curator.)

Drawings

Main drawing Dwg 001-022 (HH.5.00434) Explore all drawings relating to this boat.

List of drawings:
   Drawings believed to have been first drawn for, or being first referenced to
   HMCo #499s Columbia are listed in bold.
   Click on Dwg number for preview, on HH number to see at M.I.T. Museum.
  1. Dwg 083-019 (HH.5.06376): Booby Hatch for Str. 153, 155, 172 (1888)
  2. Dwg 077-013 (HH.5.05615): 46' W.L. Cutter Turnbuckles (1891-03-27)
  3. Dwg 077-058 (HH.5.05661): Boat Boom Hangings (ca. 1892)
  4. Dwg 087-003 (HH.5.06875): Swivels for 499 Also Life Line Stanchions Spin. Head (ca. 1892)
  5. Dwg 087-018 [082-018] (HH.5.06891): Upper Mast Head Band for 84' W.L. Sailing Yacht # 429 (1892-12-05)
  6. Dwg 089-001 (HH.5.07046): Bob Stay Gear for 84' W.L. Sailing Yacht # 429 (1892-12-17)
  7. Dwg 089-002 (HH.5.07047): Turn Buckles to Be Forged of Mild Steel for 84' W.L. Sailing Yacht # 429 (1892-12-17)
  8. Dwg 087-004 (HH.5.06876): Boom Hanging and Fife Rail for 84' W.L. Sailing Yacht # 429 (1892-12-29)
  9. Dwg 087-071 (HH.5.06945): Details for 84' W.L. Sailing Yacht # 429 (1893-02-25)
  10. Dwg 089-013 (HH.5.07058): Turn Buckles for Sailing Yacht # 435 (1893-02-25)
  11. Dwg 114-027 (HH.5.09523): Boat Davits 2 Sheets 1 3/8"D. & 1 5/8" Dia (1893-04-01)
  12. Dwg 114-027 1/2 (HH.5.09524): 2 - 1 5/8" Davits for 84 W.L. Sailing Yacht # 429 (1893-04-01)
  13. Dwg 089-089 (HH.5.07111): Mast Truss for # 435 and 452 (1893-07-15)
  14. Dwg 089-054 (HH.5.07078A): Spreader Socket (ca. 1895)
  15. Dwg 089-019 (HH.5.07063): Upper Mast Head Band # 452 (1895-02-04)
  16. Dwg 089-011 (HH.5.07056): Top Mast Heel Band and Support (1895-02-16)
  17. Dwg 089-012 (HH.5.07057): Lower Masthead Band for # 452 (1895-02-16)
  18. Dwg 089-014 (HH.5.07059): Bowsprit End No. 452 (1895-02-17)
  19. Dwg 089-082 (HH.5.07104): Mast Head Work of Steel for 84' W.L. Sailing Yacht (1895-02-17 ?)
  20. Dwg 089-031 (HH.5.07075): 4'-4" x 5" Coaming & Hatch (1895-04-17)
  21. Dwg 089-032 (HH.5.07076): 30" x 30" Coaming and Racing Hatch for # 452 (1895-04-20)
  22. Dwg 089-033 (HH.5.07077): 30" x 37" Coaming and Racing Hatch for # 452 (1895-04-20)
  23. Dwg 089-034 (HH.5.07078): Butternut Skylights for # 452 (1895-04-20)
  24. Dwg 074-018 (HH.5.05302): Sheaves for Block List # 452 (1895-04-27)
  25. Dwg 089-041 (HH.5.07085): Galvanized Steel Forgings for # 452 (1895-05-01)
  26. Dwg 089-046 (HH.5.07090): Main Sheet Traveler and Boom Span Connection (1895-05-08)
  27. Dwg 089-045 (HH.5.07089): Boom Crotch for 429 (1895-05-15 ?)
  28. Dwg 089-047 (HH.5.07091): Rigging Details for Sailing Yachts No. 429, 435 and 437 (1895-05-16 ?)
  29. Dwg 089-050 (HH.5.07074A): For # 452 [Detail of Topmast Spreader] (1895-05-27)
  30. Dwg 089-088 (HH.5.07110): Rigging Details (Shackles (Scotchman) (1895-05-27)
  31. Dwg 089-055 (HH.5.07079A): General Arrangement > For # 452 [Companionway] (1895-06-01)
  32. Dwg 049-041 (HH.5.03718): Bilge Pump for 452 and 499 (1895-06-03)
  33. Dwg 112-050 (HH.5.09343): Capstan for Defender No. 452 (1895-06-04)
  34. Dwg 089-057 (HH.5.07081A): Spreaders for Bowsprits Shrouds (1895-06-06)
  35. Dwg 089-052 (HH.5.07076A): Pin Rails for No. 452 (1895-06-08)
  36. Dwg 089-051 (HH.5.07075A): Jib Sheet Leader & Jib Lift Rope Thimble (1895-06-12)
  37. Dwg 089-060 (HH.5.07084A): # 452 [Hatch] (1895-06-15)
  38. Dwg 112-026 (HH.5.09316): Wire Cable Stopper of Al-Bz for 452 (1895-06-21)
  39. Dwg 089-064 (HH.5.07087A): Skylight Lift for # 452 (1895-07-18)
  40. Dwg 089-075 (HH.5.07099): Steel Gaff for # 452 (1895-08-03)
  41. Dwg 089-068 (HH.5.07091A): Strap for Heel of Club Topsail Yard # 452 (1895-08-11)
  42. Dwg 089-073 (HH.5.07097): Change in Lever Band for 452 Defender (1895-08-22)
  43. Dwg 000-000 [030-000] (HH.5.02281): Docking Detail, Keel (ca. 1898)
  44. Dwg 090-003 (HH.5.07140): Plan of Spars for Shop # 499 (ca. 1898)
  45. Dwg 090-001 (HH.5.07138): Construction Dwg > Plating Plan of No. 499 (1898-10-14)
  46. Dwg 090-002 (HH.5.07139): Plan of Spars for Ordering # 499 (1898-10-25)
  47. Dwg 090-009 (HH.5.07146): 2nd Mast Band for # 499 of Nickel Steel (1898-10-27)
  48. Dwg 090-008 (HH.5.07145): Upper Mast Band for # 499 Nickel Steel (1898-11-01)
  49. Dwg 090-010 (HH.5.07147): 3rd Mast Band and Fore Stay Support for # 499 (1898-11-02)
  50. Dwg 090-011 (HH.5.07148): Lower Mast Head Band for # 499 Nickel Steel (1898-11-04)
  51. Dwg 090-012 (HH.5.07149): Lower Mast-Band for 499 (1898-11-15)
  52. Dwg 090-035 (HH.5.07172): Mast Head (1898-12 ?)
  53. Dwg 090-004 (HH.5.07141): Rudder Post for # 499 (1898-12-01)
  54. Dwg 090-005 (HH.5.07142): Miscellaneous Plates for # 499 [Various Lists] (1898-12-09)
  55. Dwg 090-006 (HH.5.07143): Bow and Bowsprit Gear # 499 (1898-12-12)
  56. Dwg 090-130 (HH.5.07253): List of Forgings for Spars and Rigging for # 499 (1898-12-22)
  57. Dwg 090-130 (HH.5.07253.1): List of Forgings for Spars and Rigging for # 499 (1898-12-22 ?)
  58. Dwg 090-130 (HH.5.07253.2): List of Forgings for Spars and Rigging for # 499 (1898-12-22 ?)
  59. Dwg 090-007 (HH.5.07144): Keel for [?] 499 (1898-12-24)
  60. Dwg 037-066 (HH.5.02803): Castings for Mast Bands for # 499 (1898-12-27)
  61. Dwg 090-017 (HH.5.07154): Details Steering Gear Rudder Bearing (1898-12-30)
  62. Dwg 090-016 (HH.5.07153): Steering Gear Details Quadrant # 499, 551, 590 (1898-12-31)
  63. Dwg 089-106 (HH.5.07127): Rings for Steel Mast for Defender (1899)
  64. Dwg 090-062 (HH.5.07198): Block List # 499 (ca. 1899)
  65. Dwg 090-132 (HH.5.07254): # 499 Stirrup Iron (1899)
  66. Dwg 090-131 (N/A): List of Castings for Riggings See Also Book of Casting (1899-01 ?)
  67. Dwg 127-067 (HH.5.09935.6): Sails > Sails for No. 499 (1899-01)
  68. Dwg 090-019 (HH.5.07156): Details Steering Gear Foot for 16" Dia Column (1899-01-03 ?)
  69. Dwg 090-020 (HH.5.07157): Details of Steering Gear # 499 Housing for Top Gears (1899-01-03 ?)
  70. Dwg 090-018 (HH.5.07155): Details Steering Gear Bevel Gears (1899-01-04)
  71. Dwg 090-013 (HH.5.07150): Details of Reverse Angles Wooden Floors and Steel Tie Plates (1899-01-05)
  72. Dwg 090-014 (HH.5.07151): Details of Riveting for # 499 (1899-01-07)
  73. Dwg 090-021 (HH.5.07158): Detail Steering Gear # 499 Friction Clutch (1899-01-07 ?)
  74. Dwg 089-085 (HH.5.07107): Steel Mast for # 452 Defender Joint Plan for Straight Position of Mast 21 1/2" Outside Dia. (1899-01-09)
  75. Dwg 090-022 (HH.5.07159): Detail Steering Gear # 499 Pinion 2 1/2 Teeth 12 (1899-01-10)
  76. Dwg 090-027 (HH.5.07164): Martingale Support for # 499 (1899-01-10)
  77. Dwg 090-023 (HH.5.07160): Detail Steering Gear # 499 Rudder Indicator (1899-01-11)
  78. Dwg 090-024 (HH.5.07161): Detail Steering Gear # 499 Shafts (1899-01-11)
  79. Dwg 090-015 (HH.5.07152); General Arrangement of Steering Gear for # 499 (1899-01-12)
  80. Dwg 090-025 (HH.5.07162): [Shell Plating List] (1899-01-14)
  81. Dwg 090-026 (HH.5.07163): Martingale for Bobstay and Scotchman for Tops Yard and Club (1899-01-16)
  82. Dwg 090-032 (HH.5.07169): Rudder & Fittings (1899-01-17)
  83. Dwg 090-028 (HH.5.07165): List of Frames Deck Beam etc. for # 499 (1899-01-18)
  84. Dwg 090-029 (HH.5.07166): Sketch of Bolts for Wooden Floors (1899-01-18)
  85. Dwg 089-084 (HH.5.07106): Throat Block Crane on Steel Mast for Defender (1899-01-19)
  86. Dwg 090-030 (HH.5.07167): Crotch Spreader for Forestay for # 499 and Topmast Cone (1899-01-19)
  87. Dwg 090-031 (HH.5.07168): Bowsprit Fid for # 499 and Jib Buff Rope Thimbles (1899-01-20)
